| Ref | Part Number | Description |
|---|
| 1 |
576480002 |
PLATE, HEIGHT INNER ORG Price: $84.99 |
| 2 |
576480102 |
PLATE, HEIGHT OUTER ORG Price: $59.99 |
| 3 |
593634102 |
PLATE.PNT.PILLOW.BLOCK.EDIP This part replaces 525822201. Price: $2.99 |
| 4 |
576646701 |
PLATE, SPRING ANCHOR Price: $7.99 |
| 5 |
576485802 |
Spacers This part replaces 576485801. Price: $3.99 |
| 6 |
576623102 |
Spacers This part replaces 576623101. Price: $3.99 |
| 7 |
576623002 |
Spacers This part replaces 576623001. Price: $2.99 |
| 8 |
596839401 |
Spacers This part replaces 510362501. Price: $5.99 |
| 9 |
510408302 |
Pedals This part replaces 510408301. Price: $27.99 |
| 10 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 10 |
98-9713 |
WATER FLANGE ASM Price: $199.09 |
| 11 |
510406802 |
Latch This part replaces 510406801. Price: $19.99 |
| 12 |
576638901 |
LEVER, TRANSPORT RELEASE Price: $19.99 |
| 13 |
583623801 |
SHAFT.DECK.LIFT.FT This part replaces 576479201. Price: $219.99 |
| 14 |
576479901 |
SHAFT, LIFT LEFT REAR Price: $89.99 |
| 15 |
576479401 |
SHAFT, LIFT RIGHT REAR Price: $89.99 |
| 16 |
510089401 |
BUSHING, FLANGE 1.25 X 1.0 Price: $17.99 |
| 17 |
510023902 |
BLOCK, PILLOW Price: $11.99 |
| 18 |
576676601 |
SPRING, EXTENSION Price: $22.99 |
| 19 |
510376601 |
SPRING, TORSION Price: $2.99 |
| 20 |
510089802 |
Rods This part replaces 510089801. Price: $119.99 |
| 20 |
98-9580 |
PIPE-RETURN, WATER Price: $4.01 |
| 21 |
576622602 |
Strap This part replaces 576622601. Price: $299.99 |
| 22 |
510106501 |
ASSEMBLY, STRUT Price: $99.99 |
| 23 |
596919401 |
Pins This part replaces 510090101. Price: $4.99 |
| 24 |
510016502 |
Pins This part replaces 510016501. Price: $7.99 |
| 25 |
515988202 |
Pins This part replaces 515988201. Price: $37.99 |
| 26 |
576485602 |
Pins This part replaces 576485601. Price: $4.99 |
| 27 |
539124704 |
COTTER PIN 1/8 X 2 This part replaces 539102889. Price: $2.99 |
| 28 |
596583901 |
Bolts This part replaces 539990730. Price: $2.99 |
| 29 |
596789601 |
Bolts This part replaces 525828901. Price: $3.99 |
| 30 |
105-3747 |
PLUG Price: $3.62 |
| 30 |
574210602 |
Screws This part replaces 574210601. Price: $2.99 |
| 31 |
525612802 |
Screws This part replaces 525612801. Price: $2.99 |
| 32 |
576621602 |
Screws This part replaces 576621601. Price: $1.99 |
| 33 |
577098301 |
HHFS 3/8-16 X 2.25 GD 8 This part replaces 574496901. Price: $5.99 |
| 34 |
525822101 |
HHFS 3/8-16 X 3.5 GD 5 ZD Price: $4.99 |
| 35 |
525464701 |
HHFS 5/16-18 X 3/4 Price: $2.99 |
| 36 |
525829001 |
HHFS 5/8-11 X 3.0 GD 8 ZD Price: $27.99 |
| 37 |
595901501 |
Bolts This part replaces 539990208. Price: $3.99 |
| 38 |
576479002 |
Hardware This part replaces 576479001. Price: $5.99 |
| 39 |
516035502 |
Bolts This part replaces 516035501. Price: $4.99 |
| 40 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 40 |
99-3583 |
GASKET Price: $1.92 |
| 41 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 43 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 44 |
532429164 |
NUT.PUSH.625 This part replaces 539109304. Price: $4.99 |
| 45 |
525829102 |
Nuts This part replaces 525829101. Price: $2.99 |
| 46 |
522705201 |
RING, E, 7/16 Price: $2.99 |
| 50 |
98-9638 |
GASKET-FLANGE, WATER Price: $3.74 |
| 60 |
98-7692 |
BOLT Price: $0.92 |
| 70 |
98-9356 |
BOLT Price: $2.06 |
| 80 |
98-9578 |
PIPE-RETURN, WATER Price: $11.28 |
| 90 |
98-9579 |
BAND-PIPE Price: $5.22 |
| 100 |
98-7778 |
THERMOSTAT ASM Price: $61.89 |
| 110 |
104-4804 |
OUTLET-WATER Price: $58.99 |
| 120 |
105-3748 |
GASKET-THERMOSTAT Price: $4.31 |
| 130 |
98-7777 |
BOLT Price: $1.56 |
| 140 |
98-9719 |
THERMOSWITCH Price: $98.79 |
| 150 |
99-8379 |
PIPE-WATER Price: $105.37 |
| 160 |
107-9091 |
PIPE-WATER Price: $32.93 |
