| Ref | Part Number | Description |
|---|
| 1 |
710-09816 |
BOLT M6x22 Price: $2.45 |
| 2 |
951-15352 |
VALVE COVER Price: $17.52 |
| 3 |
951-15576 |
VALVE COVER GASKET Price: $8.76 |
| 4 |
951-11981A |
ROCKER ARM ASSEMBLY Price: $35.16 |
| 5 |
951-12269 |
EXHAUST VALVE ADJUSTER Price: $5.48 |
| 6 |
951-14911A |
VALVE SPRING SEAT Price: $4.64 |
| 7 |
951-15356 |
VALVE SPRING Price: $4.91 |
| 8 |
921-04914 |
INTAKE MANIFOLD GASKET 9Q78 Price: $8.76 |
| 9 |
951-15373 |
INTAKE VALVE Price: $18.44 |
| 10 |
710-10634 |
BOLT M10x1.25x87 Price: $1.58 |
| 11 |
951-11965B |
PUSH ROD GUIDE Price: $5.75 |
| 12 |
951-14912A |
VALVE CAP Price: $3.03 |
| 13 |
951-11964A |
INTAKE VALVE SEAL Price: $9.96 |
| 14 |
951-15374 |
EXHAUST VALVE Price: $21.94 |
| 15 |
751-20112 |
BOLT M6x10 Price: $2.45 |
| 16 |
651P08037 |
CYLINDER HEAD BAFFLE (LH) Price: $20.13 |
| 17 |
751-20110 |
NUT M6 Price: $2.45 |
| 18 |
651P08837 |
AIR CLEANER INTAKE MANIFOLD This part replaces 651-08837. Price: $12.99 |
| 19 |
921-04990 |
AIR FILTER HOUSING GASKET Price: $6.88 |
| 20 |
651P08830 |
THROTTLE BODY This part replaces 651-08830. Price: $321.99 |
| 21 |
921-04991 |
CARBURETOR GASKET Price: $6.88 |
| 22 |
951-15879 |
INSULATOR Price: $9.16 |
| 23 |
751-21193 |
STUD M6-1 X 105 Price: $3.58 |
| 24 |
751P22802 |
INTAKE MANIFOLD This part replaces 751-22802. Price: $64.99 |
| 25 |
710-10715 |
BOLT M8x48 Price: $1.58 |
| 26 |
751P20252 |
CLAMP Price: $2.45 |
| 27 |
751P22803 |
HIGH PRESSURE FUEL HOSE This part replaces 751-22803. Price: $1.49 |
| 28 |
651P08834 |
FUEL INJECTOR (LH) This part replaces 651-08834. Price: $68.99 |
| 29 |
710-10854 |
SCREW M4 X 12 Price: $1.49 |
| 30 |
651P08838 |
FUEL INJECTOR (RH) This part replaces 651-08838. Price: $68.99 |
| 31 |
710-05003A |
BOLT M6-1 x 18 Price: $3.11 |
| 32 |
751P20250 |
QUICK DISCONNECT FUEL LINE Price: $4.75 |
| 33 |
735P07281 |
HIGH PRESSURE FUEL HOSE This part replaces 735-07281. Price: $1.49 |
| 34 |
735P07282 |
FUEL HOSE SLEEVE This part replaces 735-07282. Price: $1.49 |
| 35 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) Price: $6.35 |
| 36 |
751P22661 |
CYLINDER HEAD (LH) This part replaces 751-22661. Price: $106.99 |
| 37 |
715-04097A |
DOWEL PIN 12x20 Price: $4.64 |
| 38 |
921-04967 |
CYLINDER HEAD GASKET Price: $13.13 |
| 39 |
951-05422 |
PISTON RIN SET Price: $24.21 |
| 40 |
951-11632A |
PISTON PIN SNAP RING Price: $3.53 |
| 41 |
911-06733 |
PISTON PIN Price: $5.90 |
| 42 |
951-15385 |
PISTON ASSEMBLY Price: $40.38 |
| 43 |
951-05376 |
CONNECTING ROD Price: $109.76 |
| 44 |
921-04936 |
EXHAUST GASKET Price: $7.02 |
| 45 |
751-20061 |
STUD M8 X 34 Price: $2.39 |
| 46 |
951-15922 |
SHROUD Price: $9.61 |
| 47 |
751-20117 |
BOLT M6x12 Price: $2.45 |
| 48 |
951-15355 |
PUSH ROD Price: $5.78 |
| 49 |
915-05026 |
DOWEL PIN Price: $4.40 |
| 50 |
651P08747 |
ELECTRIC STARTER Price: $228.95 |
| 51 |
751P22229 |
STARTER RELAY SUPPORT BRACKET Price: $3.17 |
| 52 |
625P09264 |
REGULATOR This part replaces 625-09264. Price: $72.99 |
| 53 |
751-20029 |
BOLT M6x16 Price: $2.45 |
| 54 |
710-10674 |
BOLT M8x10 Price: $1.58 |
| 55 |
651P08835 |
CRANKCASE This part replaces 651-08835. Price: $417.99 |
| 56 |
710-10714 |
BOLT M10x1x10 Price: $1.58 |
| 57 |
736-05221 |
WASHER 20.5X1.5X18 Not Available Price: |
| 58 |
710-10635 |
BOLT M8x16 Price: $1.58 |
| 59 |
751P21008 |
LIFT HOOK Price: $4.77 |
| 60 |
651P08839 |
IGNITION COIL (RH) This part replaces 651-08839. Price: $38.99 |
| 61 |
726-05583 |
CABLE TIE Price: $1.49 |
| 62 |
950-06314 |
IGNITION COIL SPACER Price: $5.47 |
| 63 |
751-22857 |
STUD Price: $1.49 |
| 64 |
951-15398 |
BREATHER REED ASSEMBLY Price: $5.25 |
| 65 |
951-15399 |
BREATHER REED BRACKET Price: $5.35 |
| 66 |
951-15811 |
BREATHER COVER GASKET Price: $8.76 |
| 67 |
951-15810 |
BEATHER COVER Price: $15.94 |
| 68 |
751P21250 |
FLYWHEEL OUTLET SHIELD Price: $4.17 |
| 69 |
651P08840 |
WIRE HARNESS This part replaces 651-08840. Price: $144.99 |
| 70 |
735P07283 |
BREATHER HOSE This part replaces 735-07283. Price: $3.49 |
| 71 |
937-05067 |
OIL SEAL 38 x 58 x 8 Price: $13.55 |
| 72 |
751P16106 |
FLYWHEEL Price: $301.54 |
| 73 |
936-05110 |
WASHER 20.5 x 5 x 40 Price: $5.34 |
| 74 |
712-06522 |
NUT M20x1.5 Price: $3.17 |
| 75 |
651P08841 |
FLYWHEEL FAN This part replaces 651-08841. Price: $18.99 |
| 76 |
710-09995 |
SELF TAPPING BOLT 5.5x25 Price: $2.45 |
| 77 |
751P22681 |
FLYWHEEL FAN SHROUD This part replaces 751-22681. Price: $9.99 |
| 78 |
751-20124 |
BOLT M6x25 Price: $2.45 |
| 79 |
651P08842 |
CHARGING COIL This part replaces 651-08842. Price: $61.99 |
| 80 |
751-20113 |
BOLT M6x28 Price: $2.45 |
| 81 |
651P08843 |
IGNITION COIL (LH) This part replaces 651-08843. Price: $38.99 |
| 82 |
651P08755 |
BLOWER HOUSING This part replaces 651-08755. Price: $32.99 |
| 83 |
736-05109 |
WASHER Price: $5.34 |
| 84 |
712-04276A |
ACORN NUT M6-1 Price: $5.38 |
| 85 |
937-05145 |
AIR FILTER ELEMENT Price: $27.55 |
| 86 |
712-06841 |
WING NUT M10 Price: $1.58 |
| 87 |
931-05665 |
AIR FILTER COVER ASSEMBLY Price: $43.06 |
| 88 |
951-15444 |
SEAL Price: $5.48 |
| 89 |
921-04887 |
CRANKCASE GASKET Price: $20.90 |
| 90 |
715-05064 |
PIN 8X12 Price: $3.33 |
| 91 |
951-15366 |
CRANKSHAFT ASSEMBLY Price: $377.43 |
| 92 |
751P10307A |
WOODRUFF KEY Price: $2.01 |
| 93 |
736-05187 |
WASHER - 38.5X1.0X54 Price: $3.71 |
| 94 |
651P08767 |
ROCKER ARM ASSMBLY (LOWER) Price: $38.15 |
| 95 |
941-05213 |
CAMSHAFT BEARING Price: $9.78 |
| 96 |
951-15375 |
CAMSHAFT ASSEMBLY Price: $157.36 |
| 97 |
651P08836 |
CRANKCASE BASE This part replaces 651-08836. Price: $152.49 |
| 98 |
751P20888A |
DRAIN PLUG Price: $2.98 |
| 99 |
937-05190 |
OIL SEAL 38 x 58 x 8 Price: $16.38 |
| 100 |
751P20788 |
OIL FILTER ADAPTER Price: $2.63 |
| 101 |
951-12690 |
ENGINE OIL FILTER Price: $15.89 |
| 102 |
751-22852 |
HEX FLANGE BOLT M6 X 65 Price: $1.49 |
| 103 |
951-05450B |
DIPSTICK Price: $29.58 |
| 104 |
951-15590 |
CRANKCASE OIL PASSAGE PIN Price: $3.25 |
| 105 |
951-15589 |
O-RING 13.2X2.65 Price: $3.50 |
| 106 |
736-05199 |
THRUST WASHER 17.4X25.9X1.0 Price: $3.58 |
| 107 |
951-15383 |
OIL PUMP SCREEN Price: $10.52 |
| 108 |
751-22799 |
STEEL BALL M9.5 Price: $1.58 |
| 109 |
932-05534 |
OIL PUMP SPRING Price: $4.49 |
| 110 |
715-04088A |
DOWEL PIN Price: $2.97 |
| 111 |
921-04916 |
OIL PUMP GASKET Price: $5.60 |
| 112 |
951-05449 |
OIL PUMP ASSEMBLY Price: $68.93 |
| 113 |
751P22682 |
CYLINDER HEAD (RH) This part replaces 751-22682. Price: $106.99 |
| 114 |
651P08832 |
AIR DEFLECTOR This part replaces 651-08832. Price: $16.99 |
| 115 |
951-11622A |
FLEXIBLE CLAMP Price: $3.42 |
| 116 |
751P20988 |
LIFT HOOK Price: $7.76 |
| 117 |
951-14091A |
PLUG Price: $2.68 |
| 118 |
735P07304 |
NEGATIVE PRESSURE FUEL HOSE This part replaces 735-07304. Price: $1.99 |
| 119 |
751P22453 |
FUEL PUMP Price: $28.47 |
| 120 |
651P08845 |
ELECTRIC FUEL PUMP This part replaces 651-08845. Price: $133.99 |
| 121 |
651P08846 |
EVAP HOSE This part replaces 651-08846. Price: $4.49 |
| 122 |
951-11700A |
CARBURETOR HOSE CLAMP Price: $3.60 |
| 123 |
735P05142A |
FUEL HOSE Price: $6.43 |
| 124 |
951-15587 |
CONNETING ROS BEARING Price: $12.96 |
| 125 |
735P07291 |
FUEL PUMP HOSE 6.3X12.5X190 This part replaces 735-07291. Price: $1.49 |
| 126 |
651P08833 |
MOUNTING PLATE /HEAT SHIELD This part replaces 651-08833. Price: $16.99 |
| 127 |
625P09265 |
TEMPERATURE SENSOR HARNESS This part replaces 625-09265. Price: $9.49 |
