| Ref | Part Number | Description |
|---|
| 1 |
05244B |
Housing, Bearing Not Available This part replaces 05244A. Price: |
| 2 |
918-0281A |
Bracket Assembly, Auger Brake This part replaces 618-0281A. Price: $60.14 |
| 3 |
684-0090B-0637 |
IMPELLER ASSEMBLY(POWDER BLACK) Not Available This part replaces 684-0090A. Price: |
| 4 |
710-1880 |
SCREW 5/16-18 x .750 This part replaces 710-0371. Price: $4.02 |
| 5 |
710-0451 |
Carriage Bolt 5/16-18 x .750" Price: $3.53 |
| 6 |
710-0459A |
Hex Screw, Special 3/8-24 x 1.5" Price: $6.50 |
| 7 |
710-0528 |
Hex Screw 5/16-18 x 1.25" Price: $3.90 |
| 8 |
710-0604A |
Self-Tapp. Screw 5/16-18 x .625" Price: $3.96 |
| 9 |
710-0891 |
Shear Bolt 5/16-18 x 1.75" Price: $6.58 |
| 10 |
711-0640 |
Stud Price: $7.03 |
| 11 |
911-0677 |
Ferrule This part replaces 711-0677. Price: $15.59 |
| 12 |
712-0116 |
Jam Nut 3/8-24 Price: $3.95 |
| 13 |
712-0429 |
Hex Lock Nut 5/16-18 Price: $3.56 |
| 14 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 15 |
714-0104 |
Hairpin Clip Price: $3.90 |
| 16 |
714-0126 |
Key Price: $4.05 |
| 17 |
714-0135 |
Key Price: $4.05 |
| 18 |
715-0118 |
Spiral Pin Price: $10.94 |
| 19 |
731-1696B |
Adapter, Chute, 6" This part replaces 731-1696. Price: $80.08 |
| 20 |
732-0858 |
Extension Spring Price: $23.03 |
| 21 |
936-0119 |
LOCK WASHER 5/16 This part replaces 736-0119. Price: $4.29 |
| 23 |
736-0169 |
Lock Washer Price: $3.33 |
| 24 |
736-0174 |
Wave Washer Price: $5.94 |
| 25 |
736-0242 |
Beleville Washer Price: $3.75 |
| 26 |
736-0250 |
Flat Washer Price: $3.90 |
| 27 |
936-0271 |
SPRING WASHER .317 X .625 X .020 This part replaces 736-0271. Price: $3.93 |
| 28 |
936-3008 |
Flat Washer, .344 x .750 x .120 This part replaces 736-3008. Price: $6.24 |
| 29 |
N/A |
UNKNOWN |
| 30 |
738-0281 |
Shoulder Screw Price: $9.16 |
| 31 |
941-04024 |
Bearing, Self Aligning This part replaces 741-04024. Price: $56.93 |
| 32 |
941-0170 |
Bearing, Flange w/Flats This part replaces 741-0192. Price: $17.84 |
| 33 |
941-0475 |
BUSHING .380 ID This part replaces 741-0475. Price: $3.74 |
| 34 |
741-0494 |
Flange Bushing Price: $3.64 |
| 35 |
747-0980A |
AUGER IDLER ROD Not Available This part replaces 747-0980. Price: |
| 36 |
954-0222A |
V Belt,1/2 x 44 This part replaces 754-0222A. Price: $37.46 |
| 37 |
756-0178 |
Flat Idler Price: $17.64 |
| 38 |
756-0243 |
Pulley Price: $88.02 |
| 39 |
784-0385D |
Bracket, Auger Idler This part replaces 784-0385A. Price: $26.17 |
| 40 |
784-5076-0637 |
Bracket, Gear Housing Support This part replaces 784-5076. Price: $40.77 |
| 41 |
784-5123-0637 |
BRACKET-CHUTE CRAN This part replaces 784-5123. Price: $15.67 |
| 42 |
784-5710-0637 |
Plate, Gear Housing Support This part replaces 784-5710. Price: $7.41 |
| 43 |
784-5711-0637 |
CHUTE BRACKET Not Available This part replaces 784-5711. Price: |
| 44 |
618-0436 |
AUGER GEARBOX ASSEMBLY Not Available Price: |
| 48 |
784-5697 |
Slide Shoe Price: $39.82 |
| 49 |
937-3000 |
GREASE FITTING This part replaces 7373000. Price: $4.04 |
| 50 |
738-0492 |
Spiral Axle Price: $180.88 |
| 51 |
736-0105 |
Bell Washer Price: $3.96 |
| 52 |
784-0315A-0637 |
BEARING HOUSING Not Available This part replaces 784-0315. Price: |
| 53 |
790-00280-0637 |
Shave Plate, 45" This part replaces 784-5696B. Price: $53.38 |
| 54 |
710-0389 |
Carriage Screw Price: $3.89 |
| 55 |
710-3168 |
Carriage Bolt Price: $3.61 |
| 56 |
712-0798 |
Hex Nut 3/8-16 Price: $3.86 |
| 57 |
710-1260A |
Screw, 5/16-18 x .75 Price: $3.34 |
| 58 |
712-0717 |
INSERT NUT 3/8-16 Not Available Price: |
| 59 |
931-2643 |
Chute Cleanout Tool This part replaces 731-2643. Price: $16.68 |
| 60 |
731-11421 |
Cleanout Tool Mount This part replaces 731-2635. Price: $9.83 |
| 61 |
748-1117 |
Support Tube Price: Call Us |
