| Ref | Part Number | Description |
|---|
| 2 |
680Z00532 |
CONTROL PIVOT WELDMENT Price: $52.60 |
| 3 |
680E00543 |
BELLCRANK ASSEMBLY Price: $42.65 |
| 4 |
680Z00548A |
CRUISE CONTROL ASSEMBLY Price: $85.33 |
| 8 |
703E11298 |
CONTROL PANEL Price: $42.65 |
| 10 |
703-26608 |
UPPER HANDLE COVER Price: $56.84 |
| 11 |
703E26743 |
BACK PLATE This part replaces 703-26743. Price: $17.04 |
| 12 |
710-0216 |
HEX SCREW 3/8-16 x .75 Price: $3.93 |
| 13 |
710-0276 |
CARRIAGE BOLT 5/16-18 x 1.00 Price: $3.68 |
| 14 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 15 |
710-0451 |
CARRIAGE BOLT 5/16-18 x .75 Price: $3.53 |
| 16 |
710-0528 |
SCREW 5/16-18 x 1.25 GR5 Price: $3.90 |
| 17 |
710-06684 |
SCREW (5/16-24:3.00:GR5) Price: $8.52 |
| 18 |
710-06707 |
SCREW (5/16-18:1.7) Price: $4.57 |
| 19 |
710-0703 |
SCREW 1/4-20 x .75 GR5 Price: $3.66 |
| 20 |
710-1238A |
SCREW 5/16-18 x .875 GR5 HXFLG HD This part replaces 710-1238. Price: $3.74 |
| 21 |
710-1652 |
SCREW 1/4-20X.625 Price: $3.86 |
| 22 |
710-3022 |
SCREW 3/8-16 x 2.75 GR5 Price: $4.09 |
| 23 |
710-3168 |
CARRIAGE BOLT 3/8-16 x 1.00 GR5 Price: $3.61 |
| 24 |
711-06797A |
FURRLE (.328 ID x .250) Price: $22.82 |
| 25 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 26 |
712-04064 |
FLANGE LOCK NUT Price: $3.64 |
| 27 |
712-04065 |
NUT Price: $3.68 |
| 28 |
712-04150 |
NUT Price: $3.74 |
| 29 |
712-04217 |
FLANGE LOCK NUT Price: $3.75 |
| 30 |
712-0711 |
HEX JAM NUT 3/8X24 Price: $3.90 |
| 31 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 32 |
712-3025 |
HEX JAM NUT 5/16-24 GR 5 Price: $6.24 |
| 33 |
915-0221 |
DOWEL PIN Price: $3.93 |
| 34 |
720-05159 |
GRIP (1.0 ID x 5.5 x .065) Price: $8.16 |
| 35 |
720-05161 |
KNOB (5/16-24) (LH) Price: $12.27 |
| 36 |
720P05961 |
BALL KNOB Price: $10.28 |
| 37 |
723-04039 |
ROD END 5/16 ID Price: $50.42 |
| 38 |
723-05004 |
END ROD- 5/16 (LH) Price: $45.13 |
| 39 |
726-0211 |
U-Nut 5/16-18 Thd. This part replaces 926-0211. Price: $3.90 |
| 40 |
726-0272 |
CLAMP Price: $6.24 |
| 41 |
731-13191A |
HANDLE LOCK (RH) Price: $8.98 |
| 42 |
731-13192A |
HANDLE LOCK (LH) Price: $8.98 |
| 43 |
731-13313 |
NEUTRAL LOCK ROLLER Price: $4.38 |
| 44 |
732-04629 |
EXTENSION SPRING Price: $25.15 |
| 45 |
732-04826A |
EXTENSION SPRING Price: $3.49 |
| 46 |
732-05587 |
NEUTRAL LOCK SPRING Price: $4.88 |
| 47 |
732-05590 |
TRACKING SPRING Price: $5.72 |
| 48 |
736-0264 |
Fl-Wash. .344" I.D. x .625" O.D. This part replaces 936-0264. Price: $5.99 |
| 49 |
736-04511 |
FLAT WASHER Price: $2.94 |
| 50 |
736-05239 |
FLAT WASHER (0.526X1.250X0.048) Price: $4.88 |
| 51 |
736-3072 |
WASHER Price: $4.11 |
| 52 |
736-3081 |
FLAT WASHER ID-.320 x .598 Price: $3.08 |
| 53 |
738-04185 |
SHOULDER SCREW Price: $7.45 |
| 54 |
738-04535 |
SHOULDER SCREW Price: $5.62 |
| 55 |
738-05270 |
BELLCRANK SPACER Price: $4.25 |
| 56 |
738-05280 |
NEUTRAL LOCK SPACER Price: $4.25 |
| 57 |
738-0966A |
SHOULDER SCREW .50X.925 Price: $4.08 |
| 58 |
738-0974 |
Shoulder Screw .375 X .380 X 1/4-20 This part replaces 938-0974. Price: $9.59 |
| 59 |
741-0353 |
Bearing (15" x 6" w/Bronze Brg.) This part replaces 941-0353. Price: $10.44 |
| 60 |
741-04206A |
SLEEVE BEARING .623 x .5025 x .250 Price: $3.07 |
| 61 |
741-04425 |
BALL BEARING .25 x .625 SPCL Price: $13.08 |
| 62 |
941-3073 |
FLANGE BEARING .375X.580X.250 Price: $4.66 |
| 63 |
946-05341B |
CHOKE CABLE Price: $60.60 |
| 64 |
946-05434 |
THROTTLE CABLE Price: $79.04 |
| 65 |
747-06958A |
TRANSMISSION CONTROL ROD Price: $18.48 |
| 66 |
747-06959A |
CONTROL LEVER ROD Price: $11.38 |
| 67 |
747-06960 |
CONTROL TRACKNG ROD Price: $26.33 |
| 68 |
948-0108 |
FLANGE BEARING .503ID Price: $7.64 |
| 69 |
750-04477A |
IDLER BRACKET SPACER .340X.750X.330 Price: $4.53 |
| 70 |
750-06752 |
SPACER (.322 x .625 x 1.8) Price: $6.53 |
| 71 |
750-06811 |
TRANSMISSION SPACER Price: $4.25 |
