| Ref | Part Number | Description |
|---|
| 1 |
121472X |
Wheel Steering (AYP part number) Price: Call Us |
| 2 |
154427 |
Axle Asm Stmp Dropped STLT (AYP part number) Price: Call Us |
| 3 |
156483 |
Spindle Asm LH Price: Call Us |
| 4 |
157473 |
Spindle Asm RH Price: Call Us |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 7 |
19272016 |
Washer 27/32 X 1-1/4 X 16 Ga Price: Call Us |
| 7 |
28-1060 |
DISCONTINUED Price: Call Us |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 8 |
28-0930 |
THRUST WASHER Price: $130.68 |
| 9 |
3366R |
Bearing Col Strg Blk Price: Call Us |
| 10 |
156438 |
Link Drag Extended Stamped Price: Call Us |
| 10 |
28-0870 |
DISCONTINUED Price: Call Us |
| 11 |
10040600 |
Washer Lock Hvy Hlcl Spr 3/8 Price: Call Us |
| 11 |
11-5790 |
KEY-SQUARE Price: $17.50 |
| 12 |
28-0940 |
DISCONTINUED Price: Call Us |
| 13 |
154779 |
Bearing Axle STLT/GT Price: Call Us |
| 13 |
28-0860 |
BEARING Price: $82.16 |
| 14 |
28-1050 |
DISCONTINUED Price: Call Us |
| 15 |
73901000 |
Nut Lock Flange 5/8-11 Unc Price: Call Us |
| 16 |
28-1090 |
DISCONTINUED Price: Call Us |
| 17 |
156546 |
Shaft Asm Strg Price: Call Us |
| 17 |
28-1080 |
DISCONTINUED Price: Call Us |
| 18 |
32140-55 |
DISCONTINUED This part replaces 3211-33. Price: Call Us |
| 18 |
57079 |
Washer Thrust 515 x 750 x 033 Price: Call Us |
| 19 |
124035 |
Support Shaft (AYP part number) Price: Call Us |
| 20 |
819091016 |
WASHER This part replaces 532126684. Price: $2.99 |
| 22 |
28-1100 |
COMMUTATOR SERVICE AS Price: $690.95 |
| 22 |
71200410 |
Screw Hex Socket 1/4-20 x 5/8 (AYP part number) Price: Call Us |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $27.99 |
| 25 |
154406 |
Bracket Steering Price: Call Us |
| 27 |
136874 |
Gear Sector Price: Call Us |
| 29 |
17490612 |
Screw Thdrol 3/8-16 x 3/4 Ty-tt Price: Call Us |
| 32 |
139929 |
Rod Tie Ball J Adj VGT (AYP part number) Price: Call Us |
| 33 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga. Price: Call Us |
| 34 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 35 |
73810500 |
Locknut 5/16-24 Unf 3847 Price: Call Us |
| 36 |
155099 |
Bushing Strg (AYP part number) Price: Call Us |
| 37 |
152927 |
Screw Price: Call Us |
| 38 |
126805X |
Insert Cap Strg Wh Au Price: Call Us |
| 39 |
19133808 |
Washer 13/32 X 2-3/8 X 8 Ga Price: Call Us |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
100711L |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1-1/4 X 16 Ga Price: Call Us |
| 44 |
153720 |
Extension Steering Shaft LR/LT (AYP part number) Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 47 |
6855M |
Fitting Grease Price: Call Us |
| 51 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Price: Call Us |
| 54 |
74780520 |
Bolt Fin Hex 5/16-18 Unc x 1-1/4 Price: Call Us |
| 62 |
156594 |
Kit, Steering Assembly Svc Price: Call Us |
| 63 |
74780616 |
Bolt Fin Hex 3/8-16 unc x 1 Gr. 5 Price: Call Us |
| 65 |
154780 |
Spacer Axle Price: Call Us |
| 66 |
154404 |
Bearing Arm Pittman Price: Call Us |
| 67 |
74781044 |
Bolt, Fin Hex 5/8-11 UNC x 2-3/4 Price: Call Us |
