| Ref | Part Number | Description |
|---|
| 1 |
720-0274 |
Handle Grip This part replaces 1703539. Price: $9.99 |
| 2 |
1750796 |
BUMPER-RUB Not Available Price: |
| 3 |
736-3020 |
Flat Washer .271 ID x .630 OD This part replaces 1107381. Price: $5.94 |
| 4 |
1111601 |
SCREW-HH Not Available Price: |
| 5 |
712-0291 |
Hex Lock Nut, 1/4-20 This part replaces 1734398. Price: $3.93 |
| 6 |
1745672001 |
HANDLE-CONTROL (LH) Not Available Price: |
| 7 |
1771728 |
NYLINER BEARING .187 DIA Price: $7.01 |
| 8 |
1754177010 |
HANDLEBAR (RH) Not Available Price: |
| 9 |
1745673001 |
HANDLE-CONTROL (RH) Not Available Price: |
| 10 |
1749977001 |
CABLE BRACKET Not Available Price: |
| 11 |
1752500 |
EXTENSION SPRING Not Available Price: |
| 12 |
1754128 |
Thread Forming Screw, 1/4-20 x 3/4 Not Available Price: |
| 14 |
1104435 |
KEY-WOODRUFF 1/8 x 5/8 Not Available Price: |
| 15 |
1740121 |
SHEAVE-PTO Not Available Price: |
| 16 |
1103441 |
SCR-SET HX Not Available Price: |
| 17 |
1108852 |
KEY-.187 SQ x .75 Not Available Price: |
| 18 |
1903631 |
Set Screw, 5/16-18 x 5/16 Price: $3.15 |
| 19 |
1771238 |
ENGINE PULLEY ZP 4 Not Available Price: |
| 20 |
1754175 |
BELT COVER Not Available Price: |
| 21 |
710-0425 |
Screw, Machine, #10-24, 0.625 This part replaces 1115815. Price: $4.21 |
| 22 |
1729440 |
PULLEY-IDL Not Available Price: |
| 23 |
736-0169 |
L-Wash. 3/8" I.D." This part replaces 1100243. Price: $3.33 |
| 24 |
712-3017 |
HEX NUT 3/8-16 GR5 This part replaces 1186231. Price: $3.90 |
| 25 |
182087 |
Link-Offset Price: Call Us |
| 26 |
1751017 |
STOP-IDLER ARM ZP Not Available Price: |
| 27 |
1918462 |
Idler Arm Price: Call Us |
| 28 |
1724492 |
SCREW Not Available Price: |
| 29 |
936-0119 |
LOCK WASHER 5/16 This part replaces 1100242. Price: $4.29 |
| 30 |
1748659 |
SPACER-.5X Not Available Price: |
| 31 |
1111608 |
SCREW-HH Not Available Price: |
| 32 |
1715538 |
BUSHING-NYLINER .5X.5 Not Available Price: |
| 33 |
1740102 |
TORSION SPRING Not Available Price: |
| 34 |
1100257 |
FLAT WASHER Not Available Price: |
| 35 |
736-0262 |
FLAT WASHER .385X.870X.090 This part replaces 1100255. Price: $3.66 |
| 36 |
1774473 |
Drive Chain #41 Price: Call Us |
| 38 |
1200033 |
Key-hi Pro Not Available Price: |
| 40 |
1740139010 |
BRACKET-REINFORCEMENT Not Available Price: |
| 41 |
1766984 |
SCREW-FLANGE LOCK Not Available Price: |
| 42 |
720-0312 |
Foam Grip This part replaces 1737041. Price: $4.06 |
| 43 |
1774124010 |
HANDLE-SHIFT 42027 Not Available Price: |
| 44 |
1186327 |
SCREW-FLAN Not Available Price: |
| 45 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces 1186391. Price: $3.95 |
| 46 |
1748617001 |
Doubler Plate Assembly Price: Call Us |
| 47 |
1749291010 |
COVER-REAR Not Available Price: |
| 48 |
1757862 |
DECAL-SHIFT Not Available Price: |
| 49 |
1739463 |
FLAT WASHER Not Available Price: |
| 50 |
1739470 |
Bearing Not Available Price: |
| 51 |
1773892010 |
ASSM-FRAME 42027 Not Available Price: |
| 52 |
1750799 |
RUBBER PAD Not Available Price: |
| 53 |
1749299010 |
ASSM-FRAME COVER Not Available Price: |
| 54 |
1724760 |
CLEVIS PIN Not Available Price: |
| 55 |
1717897 |
PIN-CLIP Not Available Price: |
| 60 |
1750704 |
BELT GUIDE Not Available Price: |
| 61 |
1100044 |
Hex hd. Screw, 5/16-18 x 3/4 Price: $3.76 |
| 62 |
1740127 |
SHEAVE-TRANS Not Available Price: |
| 63 |
1733185 |
SCREW-SET SQ HD 5/16 Not Available Price: |
| 64 |
710-04049 |
Flange Screw, 5/16-18,.625, Gr5 This part replaces 1186328. Price: $4.11 |
| 65 |
1759447 |
Belt Guide Price: Call Us |
| 66 |
1100351 |
COTTER PIN Not Available Price: |
| 69 |
1710566 |
Flat Idler Price: $15.00 |
| 70 |
1918456 |
DRIVE BELT Not Available Price: |
| 71 |
1771750 |
Brake Arm Price: Call Us |
| 72 |
712-0147 |
U-Type Speed Nut This part replaces 1185986. Price: $6.01 |
| 73 |
710-0412 |
Screw, 1/4-28 x 3/4 This part replaces 1100002. Price: $4.95 |
| 74 |
936-0329 |
Lock Washer This part replaces 1100241. Price: $3.90 |
| 76 |
1748443 |
IDLER ARM Not Available Price: |
| 77 |
1758184 |
AXLE Not Available Price: |
| 79 |
710-0157 |
HEX SCREW 5/16-24 x .75 This part replaces 1100004. Price: $3.90 |
| 80 |
1758259 |
BELT GUIDE Not Available Price: |
| 82 |
726-0175 |
CLAMP Not Available This part replaces 1754159. Price: |
| 94 |
1771728 |
Nyliner Bearing Price: $7.01 |
| 95 |
1185585 |
GROMMET-FLIP Not Available Price: |
| 96 |
736-0159 |
Washer This part replaces 1100254. Price: $3.71 |
| 98 |
1918465 |
Decal, Logo - Model 42046 Price: Call Us |
| 100 |
710-0606 |
Hex Bolt 1/4-20 x 1.50 This part replaces 1100811. Price: $4.67 |
| 101 |
1754176010 |
HANDLEBAR (LH) Not Available Price: |
| 109 |
1748393 |
SCREW-CARR Not Available Price: |
| 202 |
GW-97092 |
Loctite 242, 0.02 oz. Tube Not Available This part replaces 1757032. Price: |
| 204 |
1760190 |
ASSM-WHEEL Not Available Price: |
| 207 |
1774122 |
BRACKET-SHIFT FORMED Not Available Price: |
| 208 |
1773817 |
DECAL-INSTR 42027 Not Available Price: |
| 1918466 |
DECAL-CONTROL |
PANE Not Available Price: 1918466 |
