| Ref | Part Number | Description |
|---|
| 2 |
580434401 |
DRAWBAR.STGT Price: $99.99 |
| 3 |
532444481 |
APPLIQUE.SUBASM.GT.HUSQ.II Price: $22.99 |
| 5 |
590748822 |
DASH.GT2.UPPER.RND.ELD.CP.498 This part replaces 590740022. Price: $34.99 |
| 10 |
115-4115 |
CRANKCASE ASM Price: $5,667.12 |
| 14 |
587483301 |
KIT.HOOD.ASM.HUSQ.GT.TEX.668 This part replaces 532441177. Price: $74.99 |
| 19 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 20 |
127-0425 |
PLUG This part replaces 98-9598. Price: $4.34 |
| 25 |
98-7487 |
PLUG Price: $3.18 |
| 30 |
98-7562 |
WASHER-PLAIN Price: $0.36 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ Price: $219.99 |
| 40 |
98-9388 |
JOINT-PIPE Price: $31.66 |
| 50 |
98-9544 |
SPRING Price: $0.94 |
| 58 |
532194314 |
BRKT.SUPPORT.FNDR/TANK Price: $17.99 |
| 60 |
98-9543 |
SEAT-VALVE Price: $26.61 |
| 68 |
596030701 |
Screws This part replaces 539990858. Price: $2.99 |
| 70 |
98-9380 |
BALL Price: $0.84 |
| 80 |
98-9540 |
OIL PUMP ROTOR ASM Price: $271.67 |
| 85 |
107-9069 |
COVER-PUMP, OIL Price: $27.77 |
| 90 |
107-9071 |
SCREW Price: $0.36 |
| 100 |
107-9072 |
PIN-STRAIGHT Price: $0.28 |
| 110 |
98-9633 |
GASKET-CASE, GEAR Price: $30.19 |
| 120 |
100-1765 |
BOLT This part replaces 107-9073. Price: $1.59 |
| 125 |
581684801 |
CLIP.FUEL.LINE Price: $2.99 |
| 130 |
105-3797 |
BOLT Price: $1.40 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 140 |
98-9356 |
BOLT Price: $2.06 |
| 146 |
581857901 |
BOLT.RDHD.SHT.SQNK.3/8-16X5/8 Price: $3.99 |
| 150 |
107-9074 |
BOLT Price: $1.43 |
| 150 |
532439774 |
AIR.DUCT.GTV.BLACK Price: $39.99 |
| 151 |
531077401 |
SERVICE KIT PIVOT BRACKET BRAC This part replaces 532436670. Price: $37.99 |
| 152 |
532439870 |
SHIELD.BROWNING.PNT.GT.V2 Price: $14.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 160 |
99-3510 |
BOLT This part replaces 98-9586. Price: $0.80 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532439929. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532194330 |
SUPPORT.TANK.REAR.B/TE Price: $17.99 |
| 170 |
105-3709 |
STUD Price: $1.13 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE Price: $32.99 |
| 176 |
583590601 |
NYLN.SPCR.375 X .75 X .4375.L This part replaces 532447368. Price: $2.99 |
| 177 |
532195228 |
BUSHING STEERING Price: $4.99 |
| 179 |
532168937 |
NUT Price: $2.99 |
| 180 |
582033101 |
KITS.TEX.BOLTED.CHASSIS.445559 This part replaces 593346301. Price: $229.99 |
| 180 |
98-7572 |
NUT Price: $0.32 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 190 |
98-7699 |
WASHER-SPRING Price: $0.44 |
| 191 |
586182801 |
INSERT INFLECT.RH Price: $3.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
532439674 |
CONSOLE.ASM.DECKLIFT.HUSQGT.DL Price: $84.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 200 |
119-8038 |
SEAL-OIL This part replaces 98-9482. Price: $40.16 |
| 204 |
587485801 |
VENT.TOP.ASM.HUSQ.GT2 This part replaces 532435714. Price: $22.99 |
| 210 |
105-3710 |
STUD Price: $1.16 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 220 |
99-3515 |
PLUG-GEARCASE This part replaces 98-9641. Price: $9.00 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 296 |
585420501 |
LED LIGHT.LH Price: $59.99 |
| 297 |
586182901 |
INSERT REFECT LH Price: $3.99 |
| 299 |
585420401 |
LED LIGHT.RH Price: $59.99 |
| 306 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 335 |
532448204 |
COVER.LOWER.DASH.RH.BLACK Price: $24.99 |
| 336 |
532445309 |
COVER-LH.LOWER.DASH.GT2.BLACK Price: $24.99 |
| 350 |
532445143 |
CLIP.X-MAS.TREE Price: $3.99 |
| 351 |
532421734 |
PIN.CLEVIS.375X2.125 Price: $6.99 |
| 352 |
583598001 |
CLEVIS.375X1.25 This part replaces 532448634. Price: $2.99 |
| 353 |
532178062 |
CLIP RETAINER Price: $2.99 |
| 354 |
583597601 |
SUPPORT.BELLCRANK This part replaces 532448619. Price: $20.99 |
| 355 |
583598101 |
BELLCRANK.PIVOT.LOCK.DIFF This part replaces 532448636. Price: $27.99 |
| 356 |
583598601 |
LINK.LOCK.DIFF This part replaces 532448693. Price: $5.99 |
| 357 |
583598501 |
SPRING.COMPRESSION This part replaces 532448684. Price: $4.99 |
| 358 |
580366601 |
GUIDE.SWIVEL Price: $11.99 |
| 359 |
534996001 |
ACTUATOR This part replaces 584393401. Price: $229.99 |
| 360 |
583597501 |
BRACKET ACUATOR This part replaces 532448618. Price: $54.99 |
| 361 |
596564002 |
Screws This part replaces 817490610. Price: $2.99 |
| 362 |
583597901 |
CLEVIS.375 X 2.42 This part replaces 532448633. Price: $3.99 |
| 365 |
583590601 |
NYLN.SPCR.375 X .75 X .4375.L This part replaces 532447368. Price: $2.99 |
| 375 |
586908201 |
BUMPER CLIP-ON. DASH 1" Price: $3.99 |
| 378 |
590849801 |
BUSHING FLANGE; PLASTIC Price: $3.99 |
| 379 |
593206902 |
CHASSIS.PLATE.REINFORCEMNT.431 Price: $4.99 |
