| Ref | Part Number | Description |
|---|
| 1 |
532125603 |
This part replaces 532144927. Price: $145.99 |
| 2 |
874760412 |
Bolt Hex Hd 1/4-20 unc x 3/4 Price: $3.99 |
| 8 |
532186491 |
Box Battery Price: $11.99 |
| 10 |
108-1402 |
GEAR CASE ASM Price: $859.88 |
| 16 |
532176138 |
Switch Interlock Push-In Price: $11.99 |
| 20 |
127-0425 |
PLUG This part replaces 98-9598. Price: $4.34 |
| 21 |
532183759 |
Harness Asm Light W/4152j Price: $28.99 |
| 22 |
532004152 |
Bulb Light #1156 Price: $2.99 |
| 23 |
108-3841 |
FILTER-OIL This part replaces 104-5167. Price: $10.81 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $6.99 |
| 25 |
532146148 |
Cable Battery 6 Ga. 22" red w/16 wire Price: $11.99 |
| 26 |
532175158 |
Fuse 20 AMP Price: $3.99 |
| 27 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 28 |
532145491 |
Cable Ground black Price: $6.99 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $7.99 |
| 30 |
532175566 |
Switch Ignition Delta Push-In This part replaces 532189687. Price: $9.99 |
| 30 |
98-7487 |
PLUG Price: $3.18 |
| 33 |
532140401 |
Key Ign Molded Generic Price: $3.69 |
| 40 |
532188024 |
Harness Ign. Price: $100.99 |
| 41 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 871110408. Price: $1.99 |
| 42 |
532154336 |
Cover, Terminal Red This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532178861. Price: $14.99 |
| 45 |
532122822 |
Ammeter Price: $11.99 |
| 46 |
532169642 |
HOUR METER This part replaces 532169635. Price: $109.99 |
| 50 |
532174651 |
Switch PTO Price: $22.99 |
| 50 |
98-9544 |
SPRING Price: $0.94 |
| 60 |
98-9543 |
SEAT-VALVE Price: $26.61 |
| 70 |
98-9380 |
BALL Price: $0.84 |
| 80 |
98-9540 |
OIL PUMP ROTOR ASM Price: $271.67 |
| 85 |
107-9069 |
COVER-PUMP, OIL Price: $27.77 |
| 89 |
532169639 |
Bracket Snap-In Hourmeter Price: $3.99 |
| 90 |
107-9072 |
PIN-STRAIGHT Price: $0.28 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $2.99 |
| 100 |
107-9071 |
SCREW Price: $0.36 |
| 110 |
98-9633 |
GASKET-CASE, GEAR Price: $30.19 |
| 120 |
100-1765 |
BOLT This part replaces 107-9073. Price: $1.59 |
| 130 |
105-3797 |
BOLT Price: $1.40 |
| 140 |
98-9356 |
BOLT Price: $2.06 |
| 150 |
107-9074 |
BOLT Price: $1.43 |
| 160 |
99-3510 |
BOLT This part replaces 98-9586. Price: $0.80 |
| 170 |
105-3709 |
STUD Price: $1.13 |
| 180 |
98-7572 |
NUT Price: $0.32 |
| 190 |
98-7699 |
WASHER-SPRING Price: $0.44 |
| 200 |
119-8038 |
SEAL-OIL This part replaces 98-9482. Price: $40.16 |
| 230 |
105-3710 |
STUD Price: $1.16 |
