| Ref | Part Number | Description |
|---|
| 1 |
110-4100 |
HOSE-FUEL This part replaces 23-2140. Price: $28.86 |
| 1 |
142930 |
Housing, Lower Price: Call Us |
| 2 |
142931 |
Assembly, Upper Housing Price: Call Us |
| 2 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 3 |
142932 |
Seal, Lip Price: Call Us |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 4 |
110-9662 |
HOSE-FUEL This part replaces 51-0670. Price: $31.52 |
| 4 |
142928 |
Ring, Wire Retaining Price: Call Us |
| 5 |
132-8621 |
BATTERY CORROSIVE This part replaces 83-9000. Price: $292.68 |
| 5 |
142933 |
Ring, Retaining Price: Call Us |
| 6 |
142934 |
Bearing, Shaft Ball Price: Call Us |
| 6 |
93-6775 |
CABLE-BATTERY, POS Price: $111.66 |
| 7 |
142935 |
Bearing, Cradle Price: Call Us |
| 7 |
94-5980 |
CABLE-BATTERY, NEG Price: $92.64 |
| 8 |
142936 |
Bearing, Thrust 30 x 52 x 13 Price: Call Us |
| 8 |
56-2520 |
FITTING-SHUT OFF, FUEL Price: $31.19 |
| 9 |
142937 |
Swashplate, Variable Price: Call Us |
| 9 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 10 |
56-2230 |
HOSE-FUEL Price: $3.66 |
| 11 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 12 |
83-8720 |
TANK-FUEL Price: $576.65 |
| 13 |
142938 |
Block, Cylinder Assembly Price: Call Us |
| 13 |
75-4703 |
HOSE Price: $16.06 |
| 14 |
142939 |
Arm, Trunnion Price: Call Us |
| 14 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 15 |
142940 |
Seal, Lip Price: Call Us |
| 15 |
63-8410 |
WASHER Price: $1.76 |
| 16 |
323-5 |
SCREW-HH Price: $0.41 |
| 17 |
142941 |
Guide, Slot Price: Call Us |
| 17 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 18 |
142942 |
Shaft, Motor Price: Call Us |
| 18 |
83-9240 |
BRACKET-BATTERY Price: $32.49 |
| 19 |
142943 |
Bearing, Thrust 42 x 68 x 16 Price: Call Us |
| 19 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 21 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 22 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 23 |
142944 |
Block, Cylinder Assembly Price: Call Us |
| 23 |
3234-18 |
SCREW-HHF Price: $0.87 |
| 24 |
142945 |
Seal, Lip 10 x 25 x 7 Price: Call Us |
| 24 |
323-10 |
SCREW-HH Price: $0.89 |
| 25 |
142946 |
Actuator, Bypass Price: Call Us |
| 25 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 26 |
142947 |
Center Section Assembly Kit Price: Call Us |
| 26 |
94-3698-01 |
WEIGHT - REAR This part replaces 94-3698. Price: $168.51 |
| 27 |
142948 |
Seal, Lip 26 x 42 x 8 Price: Call Us |
| 28 |
142949 |
Ring, Retaining Price: Call Us |
| 29 |
142950 |
Washer 26 x 35 x 1 Price: Call Us |
| 34 |
142951 |
Oil Filter Element Price: Call Us |
| 35 |
142952 |
Arm, Bypass Price: Call Us |
| 36 |
142953 |
Ring, Retaining Price: Call Us |
| 37 |
142954 |
Arm, Actuating Price: Call Us |
| 38 |
142955 |
Pin, Actuating Price: Call Us |
| 39 |
142956 |
Bolt 5/16-24 x 1-3/4 Price: Call Us |
| 40 |
142957 |
Locknut, Hex 5/16-24 UNJC Price: Call Us |
| 41 |
142958 |
Brake Rotor/Stator Kit Price: Call Us |
| 43 |
142884 |
Washer 7/16 x 7/8 x .060 Price: Call Us |
| 44 |
142959 |
Differential Assembly Price: Call Us |
| 52 |
142960 |
Washer 3/4 x 1.5 x .03 Price: Call Us |
| 53 |
142961 |
Seal .75 x 1.25 x .250 Price: Call Us |
| 54 |
142962 |
O-Ring .103 x 2.987 ID Price: Call Us |
| 56 |
142963 |
Shaft, Input Price: Call Us |
| 58 |
142964 |
Bolt 1/4-20 x 1.38 Price: Call Us |
| 59 |
142965 |
Pin .5 OD x .43 ID x .750 Price: Call Us |
| 62 |
142966 |
Arm, Control Price: Call Us |
| 63 |
142967 |
Puck, Dampener Price: Call Us |
| 64 |
142920 |
Set Screw Price: Call Us |
| 65 |
142968 |
Bolt #8-32 x .875 Price: Call Us |
| 68 |
142969 |
Spring Price: Call Us |
| 69 |
142970 |
Socket Set Screw Price: Call Us |
| 83 |
142971 |
Jack Shaft Assembly Price: Call Us |
| 85 |
142972 |
Jack Shaft Price: Call Us |
| 88 |
142973 |
Capscrew Price: Call Us |
| 89 |
142974 |
Washer Price: Call Us |
| 90 |
142975 |
Sleeve Bearing Price: Call Us |
| 91 |
142976 |
Seal, Wiper Price: Call Us |
| 92 |
142977 |
Spring, Block Price: Call Us |
| 93 |
142978 |
Washer, Block Thrust Price: Call Us |
| 95 |
142979 |
Strap, Locking Price: Call Us |
| 113 |
142917 |
Cap, Vent Assembly Price: Call Us |
| 114 |
142918 |
Fitting, O-Ring Assembly Price: Call Us |
| 119 |
142980 |
Spacer Price: Call Us |
