| Ref | Part Number | Description |
|---|
| 1 |
3217-26 |
NUT-HEX Price: $0.25 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 6 |
119-9364 |
CABLE-BRAKE, LH Price: $169.10 |
| 7 |
3213-1 |
SCREW-HH Price: $1.42 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 8 |
92-0417 |
SPRING-EXT Price: $15.08 |
| 9 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 10 |
42719 |
PAD-PEDAL Price: $25.85 |
| 11 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 12 |
93-6599-03 |
CATCH Price: $185.89 |
| 13 |
93-6598-0P |
BRAKE STRAP ASM. - EMERGENCY, WELDED This part replaces 93-6598-03. Price: $197.74 |
| 14 |
3272-53 |
PIN-COTTER Price: $0.35 |
| 15 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
93-6595 |
EQUALIZER-BRAKE Price: $79.24 |
| 17 |
3256-29 |
WASHER-FLAT Price: $2.59 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 19 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 20 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 21 |
100-8422-0P |
BRACKET-PEDAL, WELDED This part replaces 100-8422-03. Price: $63.76 |
| 22 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
93-6592-03 |
BRACKET Price: $18.07 |
| 24 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $7.99 |
| 25 |
94-7164 |
BEARING Price: $7.53 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 26 |
93-6589 |
SHAFT-BRAKE Price: $247.70 |
| 27 |
42195 |
PIN-CLEVIS Price: $6.11 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
522087 |
ROD-END Price: $43.45 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
119-9365 |
CABLE-BRAKE, RH Price: $169.10 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
107-0340 |
KIT-PEDAL SWITCH This part replaces 99-7407. Price: $57.82 |
| 32 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 33 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532402167 |
HARNESS IGN. DASH Price: $99.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 45 |
529910801 |
AMMETER This part replaces 532425270. Price: $27.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 59 |
596941001 |
Outlets This part replaces 532400303. Price: $11.99 |
| 67 |
532420668 |
NUT.10-32.EXTLOCK Price: $2.99 |
| 68 |
532420641 |
HARNESS.JUMPER.GAUGES Price: $17.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532400724 |
COVER.TERMINAL.BATTERY Price: $3.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 103 |
532421747 |
HARNESS.PIGTAIL.12V.OUTLET. Price: $12.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
