| Ref | Part Number | Description |
|---|
| 1 |
117-0655-03 |
BRACKET-PUMP Price: $298.43 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT This part replaces 532195223. Price: $69.99 |
| 3 |
145-3382 |
PUMP ASM This part replaces 137-4230. Price: $5,506.64 |
| 3 |
596270601 |
Levers This part replaces 532195230. Price: $19.99 |
| 6 |
139-3093 |
AGITATION HOSE ASM This part replaces 132-4309. Price: $414.66 |
| 7 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK Price: $7.99 |
| 8 |
117-8040-03 |
PLATE-MOUNT, MOTOR Price: $29.58 |
| 9 |
117-8045 |
COUPLER Price: $61.81 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 11 |
100-8635 |
FORK Price: $4.91 |
| 13 |
100-6116 |
SCREW-HHF Price: $6.41 |
| 14 |
110-5057 |
CAPSCREW-HHF Price: $2.71 |
| 15 |
108-3745 |
NUT-HHF, WHIZ Price: $1.15 |
| 16 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 17 |
3241-7 |
SCREW-SQH Price: $3.39 |
| 18 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 19 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 21 |
120-0628-03 |
GUARD-SHAFT, PUMP Price: $22.59 |
| 22 |
117-0706 |
HYD MOTOR ASM Price: $793.55 |
| 24 |
106-1990 |
KEY-WOODRUFF Price: $3.81 |
| 27 |
322-14 |
SCREW-HH Price: $1.01 |
| 28 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 29 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 32 |
136-0376-03 |
BRACKET-VALVE, AGITATION Price: $33.11 |
| 33 |
107-3073 |
U-BOLT Price: $14.49 |
| 34 |
33113-012 |
SCREW-HH Price: $0.71 |
| 35 |
136-2286-03 |
MOUNT-PLATE, SUPPORT Price: $15.47 |
| 36 |
132-4302 |
MOUNT-VALVE Price: $38.41 |
| 37 |
131-0249 |
ON/OFF 2-WAY VALVE KIT Price: $220.85 |
| 38 |
131-0264 |
AGITATION THROTTLING HANDLE KIT Price: $28.04 |
| 39 |
132-4310 |
AGIATION SUPPLY HOSE ASM Price: $133.74 |
| 40 |
130-8202 |
TRANSDUCER-PRESSURE Price: $382.14 |
| 41 |
127-9829 |
CLAMP/GASKET KIT Price: $40.32 |
| 43 |
127-1185 |
FITTING-CAP, PORT Price: $22.48 |
| 44 |
138-6262 |
SERVICE KIT - FLOW METER ASM This part replaces 106-1038. Price: $1,138.30 |
| 45 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532195301 |
SPRINGS This part replaces 532195304. Price: $11.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 91 |
589464808 |
LINK ASSY LIFT.REAR LINK.ASM.P This part replaces 532197984. Price: $12.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 98 |
581506902 |
Links This part replaces 532195264. Price: $9.99 |
