| Ref | Part Number | Description |
|---|
| 1 |
114-5422 |
ROLLER-SHOULDER, PLASTIC Price: $525.86 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $3.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
532184130 |
KIT.PULLEY.WEED.TRIMMER This part replaces 532179466. Price: $44.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
532197480 |
O-RING..070X.487.NEOPRENE Price: $3.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 9 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $2.99 |
| 11 |
532170980 |
BOLT.HANDLE.WHEELED.TRIMMER Price: $3.99 |
| 12 |
532191938 |
KNOB, DEFLECTOR Price: $2.99 |
| 15 |
532179751 |
ADJSTR.ASSEM.HANDLE.WHLD.TRIMM Price: $14.99 |
| 16 |
581902101 |
GUIDE.ROPE.BLK.ZINC.CHROM Price: $1.99 |
| 18 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $3.99 |
| 19 |
587564113 |
BAIL.ASM.TRIMMER.421 This part replaces 585645313. Price: $11.99 |
| 20 |
586861201 |
CONTROL.THROTTLE.TRIMMER Price: $22.99 |
| 21 |
532183365 |
SCREW Price: $3.99 |
| 22 |
532447829 |
AXLE.TRIMMER Price: $54.99 |
| 23 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $2.99 |
| 24 |
532169823 |
SPACER.AXLE.STRING.TRIMMER Price: $3.99 |
| 25 |
532088348 |
WASHER PM Price: $3.99 |
| 26 |
581010305 |
WHEEL.12 X 1.75.5SPK.RAD3.YELL Price: $32.99 |
| 27 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $2.99 |
| 28 |
584954101 |
CABLE.DRIVE.TRIMMER Price: $17.99 |
| 31 |
532426297 |
BRACKET, AXLE Price: $2.99 |
| 33 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532132004. Price: $1.99 |
| 34 |
581912601 |
T-KNOB.NEW ROPE GUIDE Price: $1.99 |
| 36 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.99 |
| 37 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 38 |
532851074 |
WASHER,HARDEN Price: $2.99 |
| 41 |
532448336 |
TUBE.AXLE.TRIMMER.BLACK Price: $9.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
