| Ref | Part Number | Description |
|---|
| 1 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 1 |
690156 |
CYLINDER ASSEMBLY Price: Call Us |
| 2 |
399265 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 2 |
98-7612 |
FILTER-FUEL Price: $10.48 |
| 3 |
104-5215 |
PUMP-FUEL, ELECTRIC Price: $264.12 |
| 3 |
291675 |
SEAL, OIL Price: Call Us |
| 4 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 4 |
494238 |
BASE, ENGINE Price: Call Us |
| 5 |
110-4100 |
HOSE-FUEL This part replaces 23-2140. Price: $28.86 |
| 5 |
690188 |
HEAD, CYLINDER Price: Call Us |
| 6 |
62-7650 |
GASKET Price: $4.28 |
| 7 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 7 |
692410 |
GASKET Price: Call Us |
| 8 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 8 |
495735 |
BREATHER ASSY Price: Call Us |
| 9 |
27803 |
GASKET, VALVE COVER Price: Call Us |
| 9 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 10 |
110-4104 |
HOSE-FUEL This part replaces 93-2042. Price: $8.95 |
| 10 |
94621 |
SCREW, STEMS Price: Call Us |
| 11 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 11 |
281246 |
TUBE, BREATHER Price: Call Us |
| 12 |
110-4106 |
HOSE-FUEL This part replaces 104-0077. Price: $30.05 |
| 12 |
271916 |
GASKET, CRANKCASE COVER 1/64" Price: Call Us |
| 12 |
271996 |
GASKET, CRANKCASE COVER .009" Price: Call Us |
| 12 |
271997 |
GASKET, CRANKCASE COVER .005" Price: Call Us |
| 13 |
354-22 |
FITTING-BARBED Price: $4.64 |
| 13 |
94728 |
SCREW, CYLINDER HEAD Price: Call Us |
| 14 |
354-21 |
FITTING-BARBED Price: $6.88 |
| 15 |
354-20 |
FITTING-TEE Price: $12.61 |
| 15 |
94239 |
PLUG, OIL DRAIN Price: Call Us |
| 15A |
91488 |
PLUG, PIPE Price: Call Us |
| 16 |
110-4103 |
HOSE-FUEL This part replaces 98-9338. Price: $18.01 |
| 16 |
690136 |
CRANKSHAFT Price: Call Us |
| 17 |
110-4109 |
HOSE-FUEL This part replaces 104-0076. Price: $11.24 |
| 18 |
66-8121 |
STANDPIPE Price: $23.18 |
| 19 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 20 |
291675 |
SEAL, OIL Price: Call Us |
| 20 |
46-6560 |
BUSHING Price: $2.94 |
| 21 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 22 |
105-7933 |
TANK-FUEL Price: $275.80 |
| 22 |
95187 |
SCREW Price: Call Us |
| 23 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 23 |
693557 |
FLYWHEEL Price: Call Us |
| 23A |
492326 |
FLYWHEEL & RING GEAR ASSY, MAGNETO Price: Call Us |
| 24 |
222698 |
KEY, FLYWHEEL Price: Call Us |
| 24 |
63-8410 |
WASHER Price: $1.76 |
| 25 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 25 |
692271 |
PISTON, ASSEMBLY Price: Call Us |
| 25 |
692272 |
PISTON ASSEMBLY Price: Call Us |
| 25 |
692273 |
PISTON ASSEMBLY Price: Call Us |
| 25 |
692274 |
PISTON ASSEMBLY Price: Call Us |
| 26 |
690162 |
RING SET, PISTON Price: Call Us |
| 26 |
690164 |
RING SET, PISTON Price: Call Us |
| 26 |
690166 |
RING SET, PISTON Price: Call Us |
| 26 |
690168 |
RING SET, PISTON Price: Call Us |
| 26 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 27 |
2412-146 |
CLAMP-HOSE Price: $1.46 |
| 27 |
263129 |
LOCK, PISTON PIN Price: Call Us |
| 28 |
240-9 |
GROMMET Price: $3.25 |
| 28 |
498319 |
PIN, PISTON, STD SIZE Price: Call Us |
| 28 |
498320 |
PIN ASSY., PISTON, .005" OVERSIZE Price: Call Us |
| 29 |
499940 |
ROD ASSEMBLY, CONNECTING Price: Call Us |
| 29 |
692419 |
CONNECTING ROD Price: Call Us |
| 30 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 31 |
321-4 |
SCREW-HH Price: $0.99 |
| 32 |
692852 |
SCREW Price: Call Us |
| 33 |
110-4124 |
HOSE-FUEL This part replaces 47-7430. Price: $11.57 |
| 33 |
495856 |
VALVE, EXHAUST Price: Call Us |
| 34 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 34 |
495857 |
VALVE, INTAKE Price: Call Us |
| 35 |
104-9339 |
BRACKET-PUMP, FUEL Price: $8.04 |
| 35 |
262811 |
SPRING, VALVE Price: Call Us |
| 37 |
224502 |
GUARD, FLYWHEEL Price: Call Us |
| 40 |
224641 |
RETAINER, VALVE SPRING Price: Call Us |
| 43 |
490815 |
GOVERNOR GEAR Price: Call Us |
| 45 |
262411 |
TAPPET, VALVE Price: Call Us |
| 46 |
692421 |
CAMSHAFT Price: Call Us |
| 48 |
692706 |
SHORTBLOCK Price: Call Us |
| 50 |
690193 |
MANIFOLD, INTAKE Price: Call Us |
| 51 |
693138 |
INTAKE GASKET Price: Call Us |
| 51A |
273650 |
GASKET, INTAKE Price: Call Us |
| 53 |
690227 |
STUD Price: Call Us |
| 54 |
95160 |
SCREW Price: Call Us |
| 73 |
224948 |
SCREEN, FLUSH ROTATING Price: Call Us |
| 74 |
94821 |
SCREW, SEMS Price: Call Us |
| 75 |
225136 |
WASHER, SPRING Price: Call Us |
| 78 |
49626 |
SCREW Price: Call Us |
| 87 |
491323 |
SEAL, GOVERNOR Price: Call Us |
| 93 |
281346 |
BUSHING, THROTTLE SHAFT Price: Call Us |
| 94 |
498030 |
VALVE, IDLE, ADJUSTMENT Price: Call Us |
| 95 |
94098 |
SCREW, THROTTLE Price: Call Us |
| 98 |
495800 |
SCREW, IDLE SPEED Price: Call Us |
| 104 |
231789 |
PIN, FLOAT HINGE Price: Call Us |
| 105 |
231855 |
VALVE ASSY, INLET NEEDLE Price: Call Us |
| 106 |
231854 |
INLET VALVE SEAT Price: Call Us |
| 108 |
224558 |
VALVE, CHOKE Price: Call Us |
| 108A |
224540 |
VALVE, CHOKE Price: Call Us |
| 117 |
232118 |
JET, MAIN (STANDARD) Price: Call Us |
| 117 |
232119 |
JET, MAIN (HIGH ALTITUDE) Price: Call Us |
| 121 |
690191 |
CARBURETOR OVERHAUL KIT Price: Call Us |
| 125 |
690194 |
CARBURETOR Price: Call Us |
| 127 |
PARTS |
IMAGE REFER TO PARTS IMAGE Price: Call Us PARTS IMAGE |
| 130 |
224539 |
VALVE, THROTTLE Price: Call Us |
| 131 |
494379 |
SHAFT & LEVER, THROTTLE Price: Call Us |
| 133 |
494381 |
FLOAT, CARBURETOR Price: Call Us |
| 137 |
281165 |
GASKET, FLOAT BOWL Price: Call Us |
| 141 |
495097 |
SHAFT Price: Call Us |
| 141A |
495931 |
SHAFT & LEVER, CHOKE Price: Call Us |
| 142 |
232117 |
NOZZLE, CARBURETOR Price: Call Us |
| 146 |
94196 |
KEY, TIMING GEAR Price: Call Us |
| 163 |
281106 |
O-RING, AIR CLEANER Price: Call Us |
| 165 |
693148 |
NUT Price: Call Us |
| 171 |
281051 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 177 |
270920 |
SEAL, OIL FILLER CAP Price: Call Us |
| 186 |
493496 |
ELBOW, FUEL PIPE Price: Call Us |
| 187 |
492790 |
HOSE, FUEL Price: Call Us |
| 188 |
94929 |
SCREW, SELF-TAPPING Price: Call Us |
| 192 |
492160 |
SCREW ASSY, ROCKER ARM Price: Call Us |
| 209 |
260695 |
SPRING, GOVERNOR Price: Call Us |
| 216 |
262766 |
LINK, CHOKE Price: Call Us |
| 216A |
262767 |
LINK, GOVERNOR Price: Call Us |
| 222 |
495611 |
PLATE, GOVERNOR CONTROL Price: Call Us |
| 227 |
493935 |
LEVER ASSY, GOVERNOR Price: Call Us |
| 231 |
4098 |
SCREW Price: Call Us |
| 232 |
262785 |
SPRING, GOVERNOR LINK Price: Call Us |
| 238 |
262836 |
CAP, VALVE Price: Call Us |
| 240 |
394358 |
FILTER, FUEL Price: Call Us |
| 265 |
221535 |
CLAMP Price: Call Us |
| 276 |
281164 |
WASHER, FLOAT BOWL SCREW Price: Call Us |
| 287 |
94903 |
SCREW, HEX HEAD Price: Call Us |
| 294 |
810104 |
ADJUSTER, ROCKER ARM Price: Call Us |
| 304 |
692417 |
BLOWER HOUSING Price: Call Us |
| 305 |
94863 |
SCREW Price: Call Us |
| 306 |
225020 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
94930 |
SCREW Price: Call Us |
| 309 |
497595 |
MOTOR, STARTING, 12 VOLT Price: Call Us |
| 309 |
693054 |
MOTOR, STARTER Price: Call Us |
| 309 |
693551 |
MOTOR, STARTER Price: Call Us |
| 310 |
94003 |
BOLT Price: Call Us |
| 311 |
497608 |
BRUSH SET Price: Call Us |
| 318 |
94734 |
SCREW Price: Call Us |
| 333 |
495859 |
ARMATURE, MAGNETO Price: Call Us |
| 334 |
94731 |
SCREW, SEMS Price: Call Us |
| 337 |
491055 |
PLUG, SPARK Price: Call Us |
| 358 |
690189 |
GASKET SET Price: Call Us |
| 363 |
19203 |
PULLER, FLYWHEEL Price: Call Us |
| 383 |
89838 |
WRENCH SPARK PLUG Price: Call Us |
| 404 |
94927 |
WASHER, GOVERNOR LEVER Price: Call Us |
| 423 |
95163 |
SCREW Price: Call Us |
| 455 |
222561 |
CUP, SCREEN MOUNTING Price: Call Us |
| 462 |
225137 |
WASHER, FLAT Price: Call Us |
| 467 |
493903 |
KNOB, AIR CLEANER Price: Call Us |
| 474 |
393474 |
STATOR, ALTERNATOR, DUAL CIRCUIT Price: Call Us |
| 493 |
224968 |
BRACKET, BLOWER HOUSING, FRONT Price: Call Us |
| 493A |
224969 |
BRACKET, BLOWER HOUSING, REAR Price: Call Us |
| 503 |
806000 |
STRAP, STARTER Price: Call Us |
| 505 |
231978 |
NUT, HEX Price: Call Us |
| 510 |
693699 |
DRIVE, STARTER Price: Call Us |
| 510A |
497606 |
DRIVE, STARTER Price: Call Us |
| 513 |
398003 |
CLUTCH ASSEMBLY Price: Call Us |
| 523 |
495230 |
CAP AND DIPSTICK, OIL FILLER Price: Call Us |
| 524 |
281370 |
SEAL, FILLER TUBE Price: Call Us |
| 525 |
496113 |
TUBE, OIL FILLER Price: Call Us |
| 535 |
496894 |
CARTRIDGE, AIR CLEANER Price: Call Us |
| 544 |
497603 |
ARMATURE, STARTER Price: Call Us |
| 552 |
491986 |
BUSHING, GOVERNOR CRANK Price: Call Us |
| 556 |
93621 |
SCREW, SEMS Price: Call Us |
| 562 |
94907 |
BOLT, GOVENOR LEVEL Price: Call Us |
| 579 |
92278 |
NUT, HEX Price: Call Us |
| 601 |
93053 |
CLAMP, HOSE, GREEN Price: Call Us |
| 614 |
93306 |
COTTER, HAIR PIN Price: Call Us |
| 616 |
495157 |
CRANK, GOVERNOR, 1/4" DIAMETER Price: Call Us |
| 634 |
494453 |
SEAL, SPRING ASSY. Price: Call Us |
| 634A |
494455 |
SEAL, SPRING ASSY. Price: Call Us |
| 635 |
280872 |
ELBOW, SPARK PLUG Price: Call Us |
| 646 |
224546 |
BRACE, AIR CLEANER Price: Call Us |
| 654 |
94010 |
LOCKNUT, AIR CLEANER MOUNTING Price: Call Us |
| 663 |
94929 |
SCREW, SELF-TAPPING Price: Call Us |
| 663A |
94704 |
SCREW, AIR CLEANER Price: Call Us |
| 667 |
94010 |
LOCKNUT, AIR CLEANER MOUNTING Price: Call Us |
| 668 |
691323 |
SPACER Price: Call Us |
| 692 |
262715 |
SPRING, CHOKE Price: Call Us |
| 695 |
693109 |
SCREW Price: Call Us |
| 696 |
94863 |
SCREW Price: Call Us |
| 696A |
94822 |
SCREW, SEMS Price: Call Us |
| 697 |
94951 |
SCREW, HEX HEAD Price: Call Us |
| 718 |
230192 |
PIN, DOWEL Price: Call Us |
| 726 |
399676 |
GEAR, RING Price: Call Us |
| 727 |
490324 |
COVER, STARTER Price: Call Us |
| 729 |
281390 |
CLIP, WIRE Price: Call Us |
| 729A |
225170 |
RETAINER, WIRE Price: Call Us |
| 741 |
262932 |
GEAR, TIMING Price: Call Us |
| 757 |
213998 |
LINK, COUNTERWEIGHT Price: Call Us |
| 758 |
499994 |
COUNTERWEIGHT Price: Call Us |
| 759 |
230787 |
PIN, COUNTERWEIGHT Price: Call Us |
| 761 |
94593 |
SCREW, COUNTERWEIGHT Price: Call Us |
| 783 |
693713 |
GEAR, PINION Price: Call Us |
| 783A |
693059 |
GEAR, PINION Price: Call Us |
| 783B |
693058 |
GEAR, PINION Price: Call Us |
| 789 |
497708 |
WIRE ASSY Price: Call Us |
| 801 |
497626 |
CAP, DRIVE Price: Call Us |
| 802 |
497607 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 803 |
497604 |
HOUSING, STARTER Price: Call Us |
| 830 |
94555 |
STUD, ROCKER ARM Price: Call Us |
| 847 |
496415 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 851 |
224110 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 868 |
499236 |
SEAL, VALVE Price: Call Us |
| 871 |
262835 |
BUSHING, GUIDE (INTAKE & EXHAUST) Price: Call Us |
| 875 |
693686 |
BASE, CLEANER Price: Call Us |
| 877 |
393456 |
DIODE & CONNECTOR ASSY Price: Call Us |
| 878 |
393362 |
HARNESS, ALTERNATOR Price: Call Us |
| 914 |
94863 |
SCREW Price: Call Us |
| 921 |
225511 |
HOUSING, BLOWER Price: Call Us |
| 934 |
94627 |
SCREW, SEMS 3/4" Price: Call Us |
| 940 |
94906 |
SCREW Price: Call Us |
| 947 |
497672 |
SOLENOID Price: Call Us |
| 958 |
494768 |
VALVE, SHUT-OFF Price: Call Us |
| 967 |
272403 |
ELEMENT, AIR CLEANER Price: Call Us |
| 968 |
692139 |
COVER, CLEANER Price: Call Us |
| 975 |
495933 |
BOWL ASSEMBLY, CARBURETOR Price: Call Us |
| 977 |
690192 |
GASKET SET, CARBURETOR Price: Call Us |
| 987 |
281166 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 1005 |
281400 |
FAN, FLYWHEEL Price: Call Us |
| 1006 |
224413 |
RETAINER, FAN Price: Call Us |
| 1019 |
690180 |
LABEL KIT Price: Call Us |
| 1022 |
272475 |
GASKET, COVER Price: Call Us |
| 1023 |
691192 |
COVER, ROCKER Price: Call Us |
| 1024 |
499054 |
PUMP, OIL Price: Call Us |
| 1026 |
494432 |
ROD, PUSH, INTAKE Price: Call Us |
| 1026A |
495136 |
ROD, PUSH, EXHAUST Price: Call Us |
| 1029 |
224554 |
ARM, ROCKER Price: Call Us |
| 1033 |
690190 |
VALVE, OVERHAUL KIT Price: Call Us |
| 1034 |
495248 |
GUIDE ASSEMBLY, PUSH ROD Price: Call Us |
| 1036 |
692468 |
LABEL KIT, EMISSION Price: Call Us |
| 1044 |
94673 |
SCREW, SHOULDER, HEX HEAD Price: Call Us |
| 1051 |
263080 |
RETAINER Price: Call Us |
| 1058 |
273683 |
OWNER'S MANUAL Price: Call Us |
| 1090 |
497605 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 1091 |
281364 |
CAP, LIMITER Price: Call Us |
| 7329 |
4625 |
SCREW Price: Call Us |
