| Ref | Part Number | Description |
|---|
| 1 |
532086902 |
CONTROL BAR Price: $5.99 |
| 2 |
532850881 |
HANDLE, UPPER This part replaces 532125338. Price: $32.95 |
| 3 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532157082. Price: $54.99 |
| 4 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532132001. Price: $7.99 |
| 5 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 6 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 7 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $4.99 |
| 8 |
819091214 |
WASHER This part replaces 532053847. Price: $8.99 |
| 9 |
532130640 |
NEEDS DESCRIPTION Price: Call Us |
| 10 |
532130861 |
CABLE.MZR.51.RT.SP./PU. Price: $10.99 |
| 11 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 12 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 13 |
817021008 |
SCREW This part replaces 532085825. Price: $3.99 |
| 14 |
532069180 |
LOCKNUT Price: $2.99 |
| 15 |
532128638 |
NUT WING PM Price: $3.99 |
| 16 |
532007192 |
WIRE TIE This part replaces 532151517. Price: $7.99 |
| 17 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 18 |
532851750 |
GUARD-DISCHARGE Price: $3.33 |
| 19 |
532152510 |
HOUSING Price: $253.99 |
| 20 |
532153027 |
HDLE BRKT ASSY LH Price: $7.99 |
| 21 |
532192983 |
KIT HANDLE BRACKET LH/RH This part replaces 532153026. Price: $27.99 |
| 22 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 23 |
532130491 |
Wheel & Tire Assembly 7.0 x 1-1/2 Price: Call Us |
| 24 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $7.99 |
| 25 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 26 |
532059289 |
STEEL WASHER Price: $3.99 |
| 27 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 532149741. Price: $4.99 |
| 28 |
532154147 |
PROTECTOR Price: $22.99 |
| 29 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 30 |
874930416 |
NEEDS DESCRIPTION Price: $1.51 |
| 31 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 32 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 33 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 34 |
531006063 |
BLADE Price: $30.99 |
| 35 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $14.99 |
| 38 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532140543. Price: $11.99 |
| 39 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 41 |
532145494 |
DECAL MOWER CUT/FINGER Price: $8.99 |
| 42 |
532147354 |
NEEDS DESCRIPTION Price: Call Us |
| 43 |
532851463 |
THROTTLE CONTROL This part replaces 532851462. Price: $6.99 |
| 45 |
532192301 |
BRACKET.SKIRT.BZP This part replaces 532125207. Price: $4.99 |
| 46 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 48 |
532087930 |
GUIDE CLIP PM Price: $5.99 |
| 50 |
532410807 |
BRACKET.ADJ.WHEEL.5POS.ADS This part replaces 532139901. Price: $3.99 |
| 51 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532146630. Price: $3.99 |
| 52 |
532087877 |
KNOB Price: $3.99 |
| 54 |
532145935 |
ARM.AXLE.ASM.BZP This part replaces 532149857. Price: $4.99 |
| 55 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 57 |
532800090 |
HUB CAP Price: $1.26 |
| 58 |
596134901 |
GSPH This part replaces 532061537. Price: $2.99 |
| 59 |
532128415 |
RIVET BLIND Price: $3.99 |
