| Ref | Part Number | Description |
|---|
| 1 |
00602500 |
ASSEMBLY, BRAKE Price: $549.95 |
| 2 |
00668251 |
EXTENSION-BRAKE Price: $21.45 |
| 3 |
05901701 |
BLT-HEX .31-18X1.00 G5 ZCC This part replaces 05946900. Price: $1.45 |
| 4 |
00619400 |
ROD, PARKING BRAKE SET (RH) Price: $73.45 |
| 5 |
06700223 |
PIN, HAIR #225 .072X1.09 This part replaces 06714800. Price: $0.45 |
| 6 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 7 |
00962800 |
WMT, PARKING BRAKE PIVOT, RH Price: $23.95 |
| 8 |
06430300 |
WSHR-FL-STL .656X1.250X.10 YZC Price: $3.45 |
| 9 |
05717100 |
RG-RTNG-EXT .500X.050 (SNAP) Price: $2.45 |
| 10 |
07400127 |
SCR,TAP .312-18X.75 HWH TR ZCC This part replaces 07414400. Price: $1.45 |
| 11 |
05901804 |
BLT, HEX .31-18X1.75 G5 ZCC This part replaces 05957400. Price: $2.95 |
| 12 |
05534100 |
BUSHING, FLANGED (WITH HOLE) This part replaces 05534700. Price: $36.95 |
| 13 |
04073900 |
MOTOR, PARKER TF0360LS080AAWN Price: $674.90 |
| 14 |
06500907 |
NUT-LK-TOP-FLG .500-13 GF ZCC This part replaces 06543600. Price: $1.45 |
| 15 |
07067200 |
BOLT, WHEEL MOTOR 1/2-13X2.75 Price: $15.95 |
| 16 |
07400126 |
SCR,TAP .375-16X.50 HWH TR ZCC This part replaces 07412900. Price: $1.45 |
| 17 |
00497851 |
WMT, PARKING BRAKE HOLD DOWN Price: $6.95 |
| 18 |
00604800 |
ROD, O.C. LH BRAKE Price: $61.45 |
| 19 |
06500917 |
NUT-STD .375-16 G2 ZCC This part replaces 06529400. Price: $0.95 |
| 20 |
00698600 |
TRUNNION, PIVOT .38 Price: $71.45 |
| 21 |
05500041 |
BUSHING-FLG .39X.53X.38X1.00 Price: $10.95 |
| 22 |
08300105 |
SPRING, COMPRESSION Price: $8.45 |
| 23 |
05503100 |
BSHG-FLG.500X.750X.750X1.000BR Price: $8.95 |
| 24 |
00491900 |
WMT, PARKING BRAKE Price: $122.45 |
| 25 |
00679500 |
ROD, BRAKE LINK .375-24 UNF Price: $9.95 |
| 26 |
00504900 |
WMT, BRAKE LEVER-LH Price: $9.95 |
| 27 |
00679600 |
TRUNNION, .375-24 UNF Price: $19.45 |
| 28 |
00476300 |
SPCR, FLG .32X.49X.192X1.00 Price: $13.45 |
| 29 |
06536900 |
NUT-JAM CTRLK .75-16 YWZC Price: $5.45 |
| 30 |
00596500 |
LATCH, BRAKE LOCK Price: $25.45 |
| 31 |
03606600 |
SWITCH- DOUBLE POLE N.O./N.O. Price: $15.45 |
| 32 |
06418100 |
WSHR-HDND-STL-THR.515X.97X.062 Price: $3.45 |
| 33 |
06500809 |
NUT,NYL-FLG .31-18 GF ZCC This part replaces 06545400. Price: $1.45 |
| 34 |
00594200 |
ROD, O.C. RH BRAKE Price: $36.95 |
| 35 |
05518400 |
BSHG-FLG .762X1.0X.580X1.48 NY Price: $4.45 |
| 36 |
07000036 |
NUT, PUSH -.75" SHAFT Price: $1.95 |
| 37 |
00616900 |
ROD, PARKING BRAKE SET (LH) Price: $63.95 |
| 38 |
05901837 |
BLT, HWH #10-24X.75 ZCC This part replaces 06116900. Price: $1.95 |
| 39 |
06500915 |
NUT-LK-NYL #10-24 G2 ZCC This part replaces 06536000. Price: $0.45 |
| 40 |
59101100 |
KIT,TIRE/WHEEL W/LUGS 24X12 This part replaces 07100329. Price: $149.95 |
| 41 |
07000143 |
BLT-LUG .50-20X1.38 YWZC Price: $3.45 |
| 42 |
07523000 |
GRIP,HANDLE Price: $5.45 |
| 43 |
05500112 |
BUSHING, SPLIT .75X.81X.20THK Price: $5.95 |
| 44 |
06413400 |
WSHR-HDND-THRST .758X1.23X.031 Price: $2.95 |
| 45 |
06608700 |
KEY-WDRF .19X.75 HRD #9 Price: $0.95 |
| 46 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 47 |
00962700 |
WMT, PARKING BRAKE PIVOT, LH Price: $71.45 |
| 48 |
05981600 |
BLT-HEX .31-18X1.50 GR8YZ EP30 Price: $3.45 |
| 49 |
06300119 |
WSHR-LK-REG .312X.078 ZCC This part replaces 06308600. Price: $0.95 |
| 59101200 |
KIT,TIRE/WHEEL |
W/LUG 24X12 This part replaces 07100328. Price: $149.95 59101200 |
