| Ref | Part Number | Description |
|---|
| 1 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 1 |
532404981 |
PLUNGER.ASM.LIFT.LVR.BLK.17.32 Price: $11.99 |
| 2 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 2 |
532159471 |
SHAFT ASM R HANDLE Price: $39.99 |
| 3 |
3220-3 |
NUT-HJ Price: $0.28 |
| 3 |
532105767 |
PIN GROOVE Price: $2.99 |
| 4 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
819211621 |
WASHER Price: $3.99 |
| 6 |
532120183 |
BEARING.NYLON Price: $2.99 |
| 7 |
532125631 |
GRIP, HANDLE This part replaces 532109413. Price: $3.99 |
| 7 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 8 |
82-5190-03 |
PEDAL-TRACTION Price: $140.00 |
| 9 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 10 |
63-9751 |
DISCONTINUED Price: Call Us |
| 11 |
3218-2 |
NUT-JAM Price: $0.25 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $14.99 |
| 12 |
322-4 |
SCREW-HH Price: $0.35 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $7.99 |
| 13 |
3274-19 |
SCREW-HSH Price: $1.42 |
| 13 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 14 |
88-1160-03 |
DISCONTINUED Price: Call Us |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $8.99 |
| 15 |
92-1367 |
LEVER-TRACTION Price: $84.25 |
| 16 |
32128-20 |
NUT-HF Price: $0.99 |
| 16 |
873350800 |
NUT Price: $1.99 |
| 17 |
323-9 |
SCREW-HH Price: $1.29 |
| 17 |
532175689 |
TRUNNION Price: $2.99 |
| 18 |
539101331 |
NUT.1/2C.NYLOC This part replaces 873800800. Price: $1.99 |
| 18 |
82-4960 |
PAD-FOOT, BRAKE Price: $27.27 |
| 19 |
532139868 |
ARM.REAR.SUSPENSION Price: $11.99 |
| 19 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 20 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 20 |
532194209 |
PIN.COTTER.7/16.BOW TI Price: $1.99 |
| 21 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 22 |
76-9680 |
HUB-BRAKE Price: $54.35 |
| 23 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 24 |
92-5804-01 |
PEDAL-BRAKE, LH Price: $97.16 |
| 25 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 26 |
63-8410 |
WASHER Price: $1.76 |
| 27 |
92-5805 |
PEDAL-BRAKE, RH Price: $133.73 |
| 28 |
92-2586-01 |
LEVER-BRAKE Price: $75.15 |
| 29 |
32121-25 |
PIN-ROLL Price: $0.61 |
| 30 |
66-1140 |
HUB-ADJUSTMENT Price: $15.52 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $3.99 |
| 31 |
92-5806-01 |
SHAFT-BRAKE Price: $107.68 |
| 32 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 33 |
322-21 |
SCREW-HH Price: $4.29 |
| 34 |
76-9030 |
BRAKE SUPPORT ASM Price: $116.55 |
| 35 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 36 |
323-12 |
SCREW-HH Price: $1.14 |
| 38 |
93-9423 |
DECAL-SAFETY Price: $62.79 |
| 42 |
93-9414 |
DECAL - WARNING Price: $15.33 |
