| Ref | Part Number | Description |
|---|
| 0 |
632159C |
CARBURETOR This part replaces 632159B. Price: $135.78 |
| 1 |
108-6715 |
GAUGE BAR ASM Price: $148.12 |
| 1 |
530403211 |
Motor Cover Price: $7.99 |
| 1 |
632160 |
SHAFT & LEV Price: $13.61 |
| 2 |
29-9100 |
BRUSH AND HANDLE ASM Price: $58.15 |
| 2 |
530404233 |
Motor Outline Price: $59.99 |
| 2 |
650506 |
SCREW Price: $0.87 |
| 3 |
530404200 |
Assy-Housing Price: $12.99 |
| 3 |
631682 |
SHUTTER Price: $10.04 |
| 4 |
115-0803 |
ROLLER REBUILD TOOL KIT Price: $122.41 |
| 4 |
530015814 |
Screw Price: $1.99 |
| 4 |
631683 |
SHAFT & LEV Price: $12.88 |
| 5 |
125-5610 |
PAPER-REEL, TORO (10 PACK) Price: $6.02 |
| 5 |
27113 |
SPRING Price: $2.62 |
| 5 |
530402879 |
Switch-Momentary Price: $2.99 |
| 6 |
140-5531 |
SHIM-TORO REEL (.002IN) This part replaces 125-5611. Price: $6.67 |
| 6 |
650399 |
SCREW Price: $1.20 |
| 7 |
131-6828 |
INDICATOR-ANGLE Price: $69.10 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 7 |
530053179 |
Lockout Button Price: $1.99 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 8 |
530053181 |
Trigger Price: $1.99 |
| 9 |
31503 |
SPRING Price: $1.23 |
| 9 |
530042091 |
Spring-Trigger Price: $1.99 |
| 10 |
530053067 |
Pinion Price: $1.99 |
| 10 |
631684 |
SHUTTER Price: $3.86 |
| 11 |
27109 |
GASKET Price: $1.18 |
| 11 |
530042090 |
Ring-Retainer Price: $1.99 |
| 12 |
530016278 |
Washer-Thrust Price: $1.99 |
| 12 |
632408 |
BAFFLE Price: Call Us |
| 13 |
530053048 |
Gear Drive Price: $17.99 |
| 13 |
631687 |
INLET NEEDLE Price: $17.46 |
| 14 |
27105 |
FLOAT Price: $20.00 |
| 14 |
530053061 |
Housing Cover Price: $11.99 |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 15 |
530016406 |
Screw Price: $1.99 |
| 16 |
530403237 |
Front Handle Price: $3.99 |
| 17 |
29170 |
FLOAT BOWL Price: Call Us |
| 17 |
530015814 |
Screw Price: $1.99 |
| 18 |
530403313 |
Handguard Price: $4.99 |
| 18 |
631713 |
NUT Price: Call Us |
| 19 |
952044370 |
BAR 16" .050 3/8 .041 56DL Price: $24.99 |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 20 |
581562201 |
ACCY P/PP CHN 16" 56DL 3/8 This part replaces 952051211. Price: $19.99 |
| 21 |
530029850 |
Chain Catcher Price: $1.99 |
| 22 |
530015940 |
Screw Price: $1.99 |
| 23 |
530053153 |
Bar Clamp Price: $4.99 |
| 23 |
632330 |
NOZZLE Price: Call Us |
| 24 |
530053068 |
Pin-Bar Adjust Price: $1.99 |
| 25 |
530024419 |
Retainer-Bar Ajdust Price: $1.99 |
| 26 |
530016265 |
Screw-Bar Adjust Price: $3.99 |
| 26 |
632360 |
FUEL JET Price: Call Us |
| 27 |
530015917 |
Nut-Bar Mounting Price: $0.99 |
| 28 |
530042090 |
Ring-Retainer Price: $1.99 |
| 28 |
632039 |
WASHER Price: $3.86 |
| 29 |
530053053 |
Sprocket (3/8 Pitch) Price: $2.99 |
| 29 |
632040 |
WASHER Price: $3.86 |
| 30 |
530016262 |
Washer-Sprocket Price: $1.99 |
| 31 |
530015775 |
Screw Price: $1.99 |
| 32 |
530015814 |
Screw Price: $1.99 |
| 33 |
530403217 |
Cover Access Price: $1.99 |
| 34 |
530150552 |
CAP OIL This part replaces 530053072. Price: $2.99 |
| 38 |
530047663 |
Oil Pickup Ass'y. Price: $1.99 |
| 39 |
530053270 |
Oil Pickup Fitting Price: $1.99 |
| 40 |
530403393 |
Inlet Line Price: $1.99 |
| 41 |
530403311 |
Oil Pump Ass'y. Price: $8.99 |
| 42 |
530015775 |
Screw Price: $1.99 |
| 43 |
530403394 |
Outlet Line Price: $1.99 |
| 44 |
530031163 |
Bar Wrench Price: $4.99 |
