| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX This part replaces 532406621. Price: $159.99 |
| 1 |
703-1892 |
TRAY ASSY, BATTERY Not Available Price: |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 3 |
925-3161A |
Bulb, Head Lamp This part replaces 725-3161A. Price: $49.01 |
| 4 |
KB-RP201-53710 |
REGULATOR-VOLTAGE Not Available This part replaces KB-19267-64600. Price: |
| 5 |
710-0106 |
Screw, Hex Cap, 1/4-20 X 1.25 Lg Price: $3.66 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
712-3006 |
HEX NUT Price: $4.05 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
925-1375 |
RELAY Not Available This part replaces 725-1375. Price: |
| 9 |
710-0473 |
Screw, Truss Mach, #10-24 X .50 Lg Price: $3.90 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 10 |
936-0147 |
EXTERNAL WASHER #10 Not Available This part replaces 736-0147. Price: |
| 11 |
712-0121 |
Nut, Hex, #10-24 Price: $3.75 |
| 12 |
929-3080 |
VOLTAGE SENSOR W/ADAPTER HARNESS Not Available This part replaces 725-3165. Price: |
| 13 |
KB-15694-65990 |
TIMER-LIGHT Not Available Price: |
| 14 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 15 |
703-1823-0716 |
BATTERY HOLD DOWN (CUB YELLOW-99) Not Available This part replaces 703-1823. Price: |
| 16 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 17 |
710-3103 |
Screw, Hex Cap, 5/16-18 X 2.0 Lg Price: $4.02 |
| 18 |
729-0209 |
CLIP-FUSE HLD MTG Not Available Price: |
| 19 |
729-0207 |
FUSE HOLDER Not Available Price: |
| 20 |
925-1381 |
Fuse, 20 Amp This part replaces 725-1381. Price: $5.38 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
731-3105 |
TRAY, BATTERY Not Available Price: |
| 22 |
725-1543 |
Fuse, 30 Amp (Right side) Price: $3.90 |
| 23 |
925-04514 |
BATTERY Not Available This part replaces 725-3174. Price: |
| 24 |
759-3653 |
CAP-BATTERY VENT Not Available Price: |
| 25 |
925-3199 |
POS BATTERY CABLE Not Available This part replaces 725-3199. Price: |
| 26 |
725-3192 |
CABLE-NEG BATTERY KUBOTA Not Available Price: |
| 27 |
725-3210 |
CABLE-GROUND Not Available Price: |
| 28 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 30 |
710-0748 |
SCREW #12-14 x .500 Not Available Price: |
| 31 |
703-2759-0637 |
HEADLIGHT MOUNTING PLATE This part replaces 703-2759. Price: $12.58 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
