| Ref | Part Number | Description |
|---|
| 2 |
532153638 |
GUIDE Price: $6.99 |
| 3 |
532053998 |
WASHER Price: $3.71 |
| 4 |
532165526 |
UPPER HANDLE Price: $26.99 |
| 5 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532159354. Price: $54.99 |
| 7 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 8 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 9 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 10 |
532130861 |
CABLE.MZR.51.RT.SP./PU. Price: $10.99 |
| 11 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $4.99 |
| 13 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 14 |
532128638 |
NUT WING PM Price: $3.99 |
| 15 |
532850778 |
DISCHARGE GUARD Price: $15.99 |
| 16 |
532128415 |
RIVET BLIND Price: $3.99 |
| 17 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 19 |
532087589 |
SPRING PM Price: $3.99 |
| 21 |
532087593 |
BRACKET PM Price: $5.99 |
| 22 |
532147286 |
ROD.HINGE.COMBI-C Price: $6.99 |
| 23 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532140543. Price: $11.99 |
| 24 |
532410807 |
BRACKET.ADJ.WHEEL.5POS.ADS This part replaces 532139901. Price: $3.99 |
| 25 |
532192301 |
BRACKET.SKIRT.BZP This part replaces 532125207. Price: $4.99 |
| 26 |
532170345 |
BRACKET.ASM.HDL.RT.W/HOLE.BLAC This part replaces 532170975. Price: $5.99 |
| 27 |
532170346 |
BRACKET.ASM.HDL.LT.W/HOLE.BLAC This part replaces 532170977. Price: $5.99 |
| 29 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532146630. Price: $3.99 |
| 31 |
532401621 |
SPRING.SELECTOR.5POS.BZP This part replaces 532141730. Price: $4.99 |
| 32 |
532087877 |
KNOB Price: $3.99 |
| 33 |
532145935 |
ARM.AXLE.ASM.BZP This part replaces 532149857. Price: $4.99 |
| 34 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 35 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $7.99 |
| 37 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 39 |
532077400 |
CAP.HUB.BLACK.WALK Price: $4.99 |
| 41 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 532149741. Price: $4.99 |
| 42 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 43 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 44 |
532850999 |
SCREW Price: $4.99 |
| 45 |
532182157 |
CONTROL.THROTL.48.5.INTK.RT.HS This part replaces 532166971. Price: $14.99 |
| 49 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 50 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 51 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 52 |
532145106 |
BLADE.20.MULCH.(50DK,6020MD) Price: $17.99 |
| 53 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $14.99 |
| 55 |
532146026 |
PLATE This part replaces 532139790. Price: $49.99 |
| 57 |
532701313 |
SPACER Price: $9.45 |
| 58 |
532751772 |
PLATE.MULCH.BLACK This part replaces 532125444. Price: $8.99 |
| 59 |
532125205 |
BRACKET NLA This part replaces 532125424. Price: $12.84 |
| 60 |
532125423 |
PLATE Price: $12.99 |
| 61 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532164265. Price: $4.99 |
| 64 |
532111190 |
CABLE CLAMP(ENGINE) Price: $4.99 |
| 66 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
