| Ref | Part Number | Description |
|---|
| 1 |
5108 |
VALVE This part replaces 232-31. Price: $6.29 |
| 1 |
587834801 |
DECK.SVC.54" Price: $449.99 |
| 2 |
324-4 |
SCREW-HH Price: $0.95 |
| 3 |
3253-22 |
WASHER-LOCK Price: $2.09 |
| 4 |
5-3177 |
WASHER Price: $1.97 |
| 5 |
3248-4 |
DISCONTINUED Price: Call Us |
| 6 |
5-2570 |
DISCONTINUED Price: Call Us |
| 7 |
5-0786 |
KEY Price: $13.87 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 9 |
38-7080 |
DISCONTINUED Price: Call Us |
| 10 |
32108-20 |
SCREW Price: $0.61 |
| 11 |
3272-15 |
PIN-COTTER Price: $0.47 |
| 11 |
532187256 |
BLADE.BAGGING.54" Price: $17.99 |
| 12 |
40-7520 |
DISCONTINUED Price: Call Us |
| 12 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $17.99 |
| 13 |
3257-23 |
KEY-WOODRUFF Price: $6.79 |
| 13 |
532187291 |
SHAFT ASM MANDREL Price: $17.99 |
| 14 |
40-7530 |
DISCONTINUED Price: Call Us |
| 14 |
532187281 |
HOUSING.MANDREL.4PT. Price: $22.99 |
| 15 |
38-6990 |
DISCONTINUED Price: Call Us |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 16 |
3247-2 |
SCREW-SET, HSH Price: $0.68 |
| 16 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 17 |
5-3956 |
DISCONTINUED Price: Call Us |
| 18 |
38-7110 |
DISCONTINUED Price: Call Us |
| 18 |
872140505 |
BOLT Price: $2.99 |
| 19 |
321-2 |
SCREW-HH Price: $2.79 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $1.99 |
| 20 |
3274-34 |
SCREW-HSFH Price: $3.73 |
| 21 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 23 |
3-2461 |
DISCONTINUED Price: $5.02 |
| 24 |
353-704 |
DISCONTINUED Price: Call Us |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
237-61 |
O-RING Price: $6.87 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $1.99 |
| 26 |
5-3271 |
DISCONTINUED Price: Call Us |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
5-3275 |
DISCONTINUED Price: Call Us |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $54.99 |
| 28 |
5-3278 |
DISCONTINUED Price: Call Us |
| 29 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 31 |
32151-21 |
DISCONTINUED Price: Call Us |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 32 |
3-9358 |
DISCONTINUE Price: Call Us |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $7.99 |
| 33 |
3245-32 |
SCREW-HSH Price: $3.59 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
3257-30 |
KEY-WOODRUFF Price: $5.35 |
| 34 |
873680600 |
LOCKNUT Price: $1.99 |
| 35 |
252-6 |
BEARING-NEEDLE Price: $10.72 |
| 36 |
3-9362 |
DISCONTINUED Price: Call Us |
| 37 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 38 |
5-3914 |
DISCONTINUED Price: Call Us |
| 39 |
323-32 |
SCREW-HH Price: $1.29 |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATIONARY.LH This part replaces 532197380. Price: $22.99 |
| 40 |
281-1 |
PLUG-PIPE, SQH Price: $4.56 |
| 41 |
5-1665 |
DISCONTINUED Price: Call Us |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $1.99 |
| 42 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 43 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 43 |
532196065 |
ARM.IDLER Price: $11.99 |
| 44 |
321-8 |
SCREW-HH Price: $0.34 |
| 45 |
321-6 |
SCREW-HH Price: $0.25 |
| 46 |
237-82 |
DISCONTINUED Price: Call Us |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 47 |
587686701 |
BELT.DECK.DRIVE.BELT.54 This part replaces 532196103. Price: $44.99 |
| 48 |
5-3268 |
DISCONTINUED Price: Call Us |
| 49 |
253-44 |
SEAL-OIL Price: $24.63 |
| 49 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 50 |
32121-41 |
PIN-ROLL Price: $6.19 |
| 50 |
872110616 |
BOLT Price: $3.99 |
| 51 |
5-3277 |
DISCONTINUED Price: Call Us |
| 52 |
3-9357 |
DISCONTINUED Price: Call Us |
| 52 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $14.99 |
| 53 |
3-9356 |
DISCONTINUED Price: Call Us |
| 54 |
3-9355 |
DISCONTINUE Price: Call Us |
| 55 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 56 |
38-0430 |
SWITCH Price: $54.52 |
| 57 |
40-7420 |
DISCONTINUED Price: Call Us |
| 58 |
40-7450 |
DISCONTINUED Price: Call Us |
| 58 |
532187342 |
BAFFLE.RIGHT.54" Price: $12.99 |
| 59 |
237-7 |
O-RING Price: $8.82 |
| 59 |
532187344 |
BAFFLE.LEFT.54" Price: $14.99 |
| 60 |
2412-98 |
CLAMP-HOSE This part replaces 2412-33. Price: $1.39 |
| 60 |
532187607 |
BAFFLE CENTER 54" MOWER Price: $17.99 |
| 61 |
40-7460 |
DISCONTINUED Price: Call Us |
| 62 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 63 |
323-5 |
SCREW-HH This part replaces 323-33. Price: $0.41 |
| 64 |
281-3 |
PLUG-PIPE, SQH Price: $3.92 |
| 65 |
3-8863 |
DISCONTINUED Price: Call Us |
| 66 |
3220-7 |
NUT-JAM Price: $4.09 |
| 67 |
5-3927 |
DISCONTINUED Price: Call Us |
| 68 |
40-7030 |
DISCONTINUED Price: Call Us |
| 69 |
5-2643 |
COSHAFT WA Price: $417.01 |
| 70 |
3-8952 |
DISCONTINUE Price: Call Us |
| 71 |
253-142 |
SEAL Price: $50.28 |
| 72 |
38-3260 |
DISCONTINUED Price: Call Us |
| 73 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 74 |
3220-17 |
NUT-JAM, LH Price: $6.25 |
| 75 |
5-3928 |
DISCONTINUED Price: Call Us |
| 76 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 78 |
323-10 |
SCREW-HH Price: $0.89 |
| 79 |
3218-3 |
NUT-JAM Price: $0.25 |
| 80 |
5-2638 |
DISCONTINUED Price: Call Us |
| 81 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 82 |
3-9011 |
DISCONTINUED Price: Call Us |
| 83 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 84 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 85 |
322-1 |
SCREW-HH Price: $0.22 |
| 86 |
251-221 |
DISCONTINUED Price: Call Us |
| 87 |
71-1360 |
BEARING This part replaces 251-219. Price: $36.88 |
| 88 |
251-220 |
DISCONTINUED Price: Call Us |
| 89 |
3245-31 |
SCREW-HSH Price: $12.15 |
| 90 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 91 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 92 |
5-2635 |
DISCONTINUED Price: Call Us |
| 93 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 94 |
3-9024 |
DISCONTINUED Price: Call Us |
| 95 |
327-20 |
DISCONTINUED Price: Call Us |
| 96 |
38-7840 |
DISCONTINUED Price: Call Us |
| 97 |
3296-24 |
NUT-HEX Price: $4.44 |
| 97 |
532178515 |
WASHER Price: $2.99 |
| 98 |
3220-5 |
NUT-JAM Price: $0.65 |
| 98 |
532196105 |
SPRING, DECK DRIVE Price: $4.99 |
| 99 |
3242-2 |
SCREW-SQH Price: $1.29 |
| 100 |
3-8943 |
DISCONTINUED Price: Call Us |
| 101 |
5-2651 |
DISCONTINUED Price: Call Us |
| 102 |
5-3281 |
DISCONTINUED Price: Call Us |
| 103 |
3-6998 |
DISCONTINUED Price: $2.00 |
| 104 |
5-2648 |
DISCONTINUED Price: Call Us |
| 105 |
5-2646 |
DISCONTINUED Price: Call Us |
| 106 |
5-2652 |
DISCONTINUED Price: Call Us |
| 107 |
3274-19 |
SCREW-HSH Price: $1.42 |
| 108 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 109 |
323-8 |
SCREW-HH Price: $1.20 |
| 111 |
5-1336 |
KEY-SQUARE Price: $8.92 |
| 112 |
5-2647 |
SPROCKET Price: $139.78 |
| 113 |
3296-36 |
DISCONTINUED Price: Call Us |
| 113 |
872110508 |
BOLT CRT Price: $2.99 |
| 114 |
217-74 |
BOLT-WHEEL Price: $4.87 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $12.99 |
| 115 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 116 |
532193406 |
BOLT.SHOULDER.3/8-16X3-5/8. Price: $1.99 |
| 117 |
532174873 |
WHEEL. GUAGE RALLY Price: $7.99 |
| 120 |
819132012 |
WASHER Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $2.99 |
| 185 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 187 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 188 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 189 |
532195185 |
ARM.SUSPENSION.MOWER Price: $11.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $5.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X Price: $8.99 |
| 196 |
872140620 |
BOLT Price: $3.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 532187255 |
54" |
MULCH BLADE Price: $14.99 532187255 |
| 532416405 |
COUPLING.QUICK |
CONNECT Price: $5.99 532416405 |
