| Ref | Part Number | Description |
|---|
| 1 |
121-6425 |
DECK ASM Price: $5,494.04 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 2 |
874760412 |
Bolt, Hex Hed. 1/4-20 UNC x 3/4 (AYP part number) Price: $3.99 |
| 2 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 3 |
110-9683 |
SHAFT-REAR ROLLER Price: $35.70 |
| 4 |
36-1740 |
ROLLER-DECK Price: $37.03 |
| 7 |
322-29 |
SCREW-HH Price: $2.69 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $11.99 |
| 8 |
93-4803 |
ROLLER-DECK Price: $41.58 |
| 9 |
105-4549 |
SPACER-ROLLER Price: $10.26 |
| 10 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 12 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 13 |
68-6710 |
ROLLER Price: $59.98 |
| 14 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 15 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 16 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 17 |
108-1914 |
PAD-BUMPER Price: $11.14 |
| 18 |
3269-24 |
RIVET Price: $1.79 |
| 19 |
3233-34 |
SCREW-CARR Price: $7.98 |
| 20 |
108-1908 |
SPACER-IDLER Price: $23.93 |
| 21 |
108-4393 |
BELT-HEX Price: $166.54 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
107-4725 |
PULLEY Price: $274.56 |
| 22 |
532004152 |
Bulb Light #1156 (AYP part number) Price: $2.99 |
| 23 |
140-5847 |
PULLEY-IDLER This part replaces 01-268-0160. Price: $98.46 |
| 24 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 25 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $4.99 |
| 26 |
108-1926 |
WASHER Price: $5.30 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
140-7078 |
IDLER ARM ASM This part replaces 108-1930. Price: $49.85 |
| 28 |
532421686 |
CABLE.GROUND.REAR.BATTERY.8G Price: $11.99 |
| 29 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 31 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 32 |
108-1924 |
SPACER-IDLER Price: $11.13 |
| 33 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 33 |
532411933 |
KEY.CHAIN.BLISTER.PACK.GEN.USA Price: $6.99 |
| 34 |
106-7354-01 |
MOUNT-WHEEL, LH Price: $102.99 |
| 34 |
532110712 |
Switch Light Blk Blk Red (AYP part number) Price: $4.99 |
| 35 |
323-23 |
SCREW-HH Price: $2.07 |
| 36 |
98-7912 |
TUBE-SPANNER Price: $12.23 |
| 37 |
1-603299 |
ROLLER-SCALP, ANTI Price: $21.99 |
| 38 |
98-7913 |
TUBE-SPACER Price: $6.81 |
| 39 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 40 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 40 |
585849401 |
HARNESS.DASH.CC.RRBATT.RDYSTRT Price: $27.99 |
| 41 |
3296-45 |
NUT-HEX Price: $3.79 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER Price: $7.99 |
| 46 |
138-1930 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4778. Price: $605.97 |
| 47 |
110-0621-03 |
BLADE-MEDIUM FLOW Price: $38.49 |
| 48 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 49 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 55 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
501133701 |
HARNESS.CHASSIS.RRBATT.RDYSTRT Price: $39.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 102 |
581023401 |
HARNESS.PIGTAIL.VARIATOR.SD Price: $12.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $11.99 |
