| Ref | Part Number | Description |
|---|
| 1 |
SGH08011 |
HEAD-TINE, ADAPTER This part replaces SGH08011-03. Price: $233.73 |
| 2 |
532801784 |
Control Bar (AYP part number) Price: $3.33 |
| 2 |
SG715706 |
SHANK-ADAPTER Price: $16.94 |
| 3 |
532125271 |
Upper Handle (AYP part number) Price: $3.33 |
| 4 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532063601. Price: $1.99 |
| 5 |
532130861 |
Engine Zone Control Cable Price: $8.99 |
| 6 |
532085723 |
Washer (AYP part number) Price: $2.99 |
| 7 |
532700417 |
Throttle Control This part replaces 532132536. Price: $12.99 |
| 8 |
874250434 |
Machine Screw 1/4-20 x 2-1/8 (AYP part number) This part replaces 532085692. Price: $2.99 |
| 9 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532063688. Price: $6.99 |
| 10 |
532083816 |
Screw #10 x 5/8 (AYP part number) Price: $3.99 |
| 12 |
532128732 |
Rear Door Kit (AYP part number) Price: $3.33 |
| 13 |
817021008 |
Screw, Hex Hd. Tap #10-24 x 1/2 (AYP part number) This part replaces 532750097. Price: $1.99 |
| 14 |
532087930 |
Housing Cable Guide (AYP part number) Price: $5.99 |
| 15 |
532851552 |
Self-tapping Screw #10-24 x .625 (AYP part number) Price: $2.99 |
| 17 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $4.99 |
| 18 |
532086344 |
Screw (AYP part number) Price: $3.99 |
| 20 |
532084596 |
Engine Pulley (AYP part number) Price: $22.99 |
| 21 |
532087677 |
Hi Pro Key #505 (AYP part number) Price: $3.99 |
| 22 |
532059708 |
Set Screw 1/4-20 x 5/16 (AYP part number) Price: $3.99 |
| 23 |
532133040 |
Baffle, Rear (AYP part number) This part replaces 532125348. Price: $4.99 |
| 24 |
532140540 |
Rear Deflector (AYP part number) This part replaces 532128796. Price: $14.99 |
| 25 |
532125347 |
Side Baffle (AYP part number) Price: $8.18 |
| 26 |
532125366 |
Back Plate (AYP part number) Price: $3.33 |
| 27 |
532128415 |
Pop Rivet (AYP part number) Price: $2.99 |
| 28 |
532054583 |
Screw Hex Head 1/4-20 x 1/2 (AYP part number) Price: $3.99 |
| 29 |
532125346 |
Discharge Baffle (AYP part number) Price: $7.99 |
| 30 |
532194788 |
GUIDE.ROPE.STD.BLK.ZIN This part replaces 532132001. Price: $3.99 |
| 31 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $3.99 |
| 32 |
532125377 |
Lower Handle (AYP part number) Price: $3.33 |
| 33 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532131959. Price: $6.99 |
| 34 |
532051793 |
Hairpin Cotter (AYP part number) Price: $3.99 |
| 35 |
532077400 |
Hubcap (AYP part number) Price: $3.99 |
| 36 |
532850724 |
Grip, Handle, Foam, Corduroy (AYP part number) Price: $11.99 |
| 37 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $2.99 |
| 38 |
532134781 |
Wheel & Tire Assembly 9.00 x 2.00 Price: $3.33 |
| 39 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532084921. Price: $3.99 |
| 40 |
532062335 |
Belleville Washer (AYP part number) Price: $6.99 |
| 41 |
532125169 |
Axle Arm (AYP part number) Price: $6.99 |
| 42 |
532125168 |
Selector Spring (AYP part number) Price: $2.99 |
| 43 |
532701037 |
SELECTOR KNOB This part replaces 532132800. Price: $2.99 |
| 45 |
532084920 |
Spacer (AYP part number) Price: $1.99 |
| 46 |
532139901 |
Wheel Adjusting Bracket (AYP part number) This part replaces 532850904. Price: $5.99 |
| 47 |
532055187 |
Self-tapping Screw 5/16-18 x 3/4 (AYP part number) Price: $3.99 |
| 48 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 532063124. Price: $2.99 |
| 50 |
532125193 |
Handle Bracket (Right) (AYP part number) Price: $3.33 |
| 51 |
532125305 |
Handle Bracket (Left) (AYP part number) Price: $3.33 |
| 52 |
873680600 |
LOCKNUT This part replaces 532751592. Price: $1.99 |
| 53 |
532070505 |
Carriage Bolt 5/16-18 x 5/8 Price: Call Us |
| 54 |
532125078 |
Engine Washer (AYP part number) Price: $3.99 |
| 55 |
532150406 |
BOLT 3/8-16X1-1/8 This part replaces 532850998. Price: $3.99 |
| 57 |
532132255 |
Front Baffle (AYP part number) This part replaces 532125345. Price: $17.99 |
| 58 |
532075449 |
Speed Nut (U Type) (AYP part number) Price: $3.99 |
| 59 |
532851084 |
Hex Head Machine Screw 3/8-24 x 1-3/8 Gr. 8 Price: $2.99 |
| 60 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 61 |
532851074 |
Hardened Washer (AYP part number) Price: $2.99 |
| 62 |
532134768 |
Blade 22" (AYP part number) Price: $17.99 |
| 63 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532851514. Price: $11.99 |
| 64 |
532134857 |
Lawn Mower Housing Kit (Inc.17) Price: $3.33 |
| 68 |
532088652 |
Screw, Hinge (AYP part number) Price: $3.99 |
| 69 |
532166649 |
PLUG.MULCH.22RD This part replaces 532125368. Price: $17.99 |
| 70 |
532132612 |
Shield, Debris (AYP part number) Price: Call Us |
