| Ref | Part Number | Description |
|---|
| 1 |
137-6103 |
SHORT REAR ROLLER ASM (2.5IN DIA)(18IN) This part replaces 112-1708. Price: $357.70 |
| 1 |
530059759 |
Assy-Throttle Cable Price: $9.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
530057541 |
Hsg.-Throttle (RH) Price: $7.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
530016406 |
Screw Price: $1.99 |
| 4 |
530015814 |
Screw Price: $1.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
530054183 |
Assy.-Wire Price: $4.99 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 6 |
530059760 |
Hsg. Throttle (LH) Price: $6.99 |
| 7 |
112-1704 |
PLASTIC WIEHLE ROLLER ASM Price: $495.75 |
| 7 |
530069572 |
Kit-Switch Price: $4.99 |
| 8 |
530049107 |
TRIGGER RED This part replaces 545077601. Price: $1.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
530058583 |
Assy-Handle This part replaces 530057546. Price: $4.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
530015786 |
Bolt Price: $1.99 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
530016344 |
Screw Price: $1.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
530071788 |
Kit-Lower Shaft Price: $37.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
530052286 |
Limiter-Line Price: $1.54 |
| 16 |
530015814 |
Screw Price: $1.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 18 |
530015820 |
Bolt Price: $1.99 |
| 19 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 21 |
537419303 |
Housing Price: $6.99 |
| 22 |
537419901 |
Adapter Price: $5.99 |
| 23 |
537338801 |
Spring P25 Price: $2.99 |
| 24 |
545080801 |
Assy-Wound Spool Price: $3.99 |
| 25 |
545003365 |
Kit-Cover and Eyelet This part replaces 537419701. Price: $8.99 |
| 26 |
545003365 |
Kit-Cover and Eyelet This part replaces 537419401. Price: $8.99 |
| 27 |
537419601 |
Knob P25 Price: $3.99 |
