Starter
Parts (46)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 3216-6 | SCREW-HH Price: $17.98 |
| 1 | 530015814 | Screw Price: $1.49 |
| 2 | 545135806 | Assy - Engine Cover Price: $11.99 |
| 3 | 119-4162 | SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 3 | 530015880 | Screw Price: $1.99 |
| 4 | 545134001 | Shield - Baffle Price: $3.99 |
| 4 | 86-2010 | PIN-HOC Price: $91.17 |
| 5 | 3290-256 | PIN-HAIR Price: $1.01 |
| 5 | 545099101 | Baffle Price: $6.99 |
| 6 | 3296-15 | NUT-LOCK, NI Price: $1.75 |
| 6 | 530016391 | Screw Price: $1.99 |
| 7 | 545081852 | Kit - Starter Pulley Price: $9.99 |
| 8 | 100-2588 | V-BELT, B-SECTION Price: $83.09 |
| 8 | 545008011 | KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 9 | 545107101 | Tube - Starter Rope Price: $5.99 |
| 9 | 92-7758 | RH WING DECK ASM Price: $2,599.65 |
| 10 | 530054834 | Handle - starter Price: $1.99 |
| 10 | 92-9727 | HOC CAP ASM Price: $78.05 |
| 11 | 545081833 | Kit - Rope Price: $3.99 |
| 11 | 86-2600-01 | WASHER-GUIDE, BELT Price: $5.77 |
| 12 | 69-1510 | SPACER Price: $4.48 |
| 13 | 302-5 | FITTING-GREASE Price: $0.59 |
| 13 | 545128201 | Protector - Switch Price: $1.99 |
| 14 | 545099001 | Bearing Price: $3.99 |
| 15 | 32128-54 | NUT-HF Price: $5.25 |
| 15 | 530626605 | Nut Price: $1.99 |
| 16 | 32128-29 | NUT-LOCK, FLANGE Price: $1.63 |
| 16 | 545113801 | Trigger - Throttle Price: $6.99 |
| 18 | 530015814 | Screw Price: $1.49 |
| 19 | 545100801 | Door- Vac Price: $8.99 |
| 20 | 545115601 | Spring - Vac Door Price: $2.99 |
| 21 | 545144501 | Knob - Blower Price: $2.99 |
| 21 | 86-1440 | WASHER-FLAT Price: $2.10 |
| 22 | 530016406 | Screw - Handle Vac Price: $1.99 |
| 23 | 530092322 | Washer - Lock Price: $1.99 |
| 24 | 545109901 | Washer - Impeller Price: $1.99 |
| 25 | 545113601 | Assy-Impeller Price: $4.99 |
| 26 | 545113701 | Spacer - Flywheel Price: $2.99 |
| 27 | 530015197 | Nut Price: $1.99 |
| 28 | 530016386 | Screw This part replaces 530015810. Price: $5.99 |
| 30 | 545101201 | Handle - Vac Price: $8.99 |
| 32 | 530095646 | Assy - Fuel Pickup Price: $2.69 |
| 33 | 530069247 | Kit - Fuel Line (carb/purge) Price: $3.69 |
| 34 | 530069216 | Kit - Fuel Line (tank/purge) Price: $3.99 |
| 35 | 530057973 | Assy - Fuel Cap w/retainer Price: $7.99 |
| 36 | 530016445 | Screw - Fuel Tank Retainer Price: $1.99 |
