| Ref | Part Number | Description |
|---|
| 1 |
310577 |
Hood Price: Call Us |
| 1 |
59-7600 |
PLUG Price: $28.97 |
| 2 |
25086 |
Shoulder Bolt, 5/16-18 Thd. Price: Call Us |
| 2 |
59-7610 |
RING Price: $2.89 |
| 3 |
1498 |
Nut, Hx, Ctrlk, 5/16-18 Thd. Price: Call Us |
| 4 |
306858 |
Lens, Headlight Price: Call Us |
| 5 |
314885 |
Assembly, Foot Pad L.H. Price: Call Us |
| 5 |
59-7640 |
RING Price: $1.37 |
| 6 |
307437 |
Heat Shield Price: Call Us |
| 6 |
59-7650 |
RING Price: $1.29 |
| 7 |
300303 |
Screw, Hx Hd, Plastite 1/4 Dia. x 3/4 In. Price: Call Us |
| 7 |
60-5950 |
WASHER Price: $11.55 |
| 8 |
305804 |
Low Fuel Sensor Price: Call Us |
| 8 |
305820 |
Tank, Gas 1.5 Gal W/Sensor Price: Call Us |
| 9 |
12501 |
Cap, Fuel Price: Call Us |
| 10 |
309461 |
Bracket, Hood L.H. Price: Call Us |
| 11 |
56030 |
Screw, Hx Hd, 5/16 -18 x 3/4 In. Price: Call Us |
| 12 |
309460 |
Bracket, Hood R.H. Price: Call Us |
| 13 |
310670 |
Front Axle W/Bearings Price: Call Us |
| 13 |
59-7720 |
WASHER Price: $3.39 |
| 14 |
180075 |
Screw, Hx Hd, 5/16-18 x 5/8 In. Price: Call Us |
| 14 |
AU114313A1 |
O-RING This part replaces 59-7780. Price: $2.40 |
| 15 |
58-6370 |
WASHER Price: $40.36 |
| 15 |
706 |
Grease Fitting Price: Call Us |
| 16 |
302303 |
Bearing, Spindle Price: Call Us |
| 17 |
36625 |
E-Ring Price: Call Us |
| 17 |
59-7750 |
WASHER Price: $1.49 |
| 18 |
1499 |
Nut, Hx, Ctrlk, 3/8-16 Thd. Price: Call Us |
| 18 |
59-7760 |
WASHER Price: $1.51 |
| 19 |
305340 |
Spindle, R. H. Price: Call Us |
| 19 |
59-7770 |
SPRING Price: $25.75 |
| 20 |
120382 |
Washer, Split, Lock 3/8 In. Price: Call Us |
| 21 |
120369 |
Nut, Hx, 3/8-24 Thd. Price: Call Us |
| 22 |
317019 |
Steering Arm, Upper Price: Call Us |
| 23 |
996416 |
Washer, Flat, 25/64 In. Price: Call Us |
| 24 |
300328 |
Assembly, Tie Rod Price: Call Us |
| 25 |
305339 |
Spindle, L.H. Price: Call Us |
| 26 |
180134 |
Screw, Hx Hd, 3/8-16 x 2-1/2 In. Price: Call Us |
| 27 |
306103 |
Support Bracket, Front Axle Price: Call Us |
| 28 |
122207 |
Screw, Hx Hd, 3/8-16 x 3 In. Price: Call Us |
| 29 |
2483 |
Washer, Spring Price: Call Us |
| 30 |
55273 |
Nut, Hx, Wd Fl Lk 5/16-18 Thd. Price: Call Us |
| 31 |
642 |
Washer, Flat, 3/4 In. Price: Call Us |
| 32 |
24167 |
Valve Stem Price: Call Us |
| 32 |
301140 |
Tire, Rear Price: Call Us |
| 32 |
312739 |
Wheel/With Bearing Price: Call Us |
| 32 |
314416 |
Bearing Price: Call Us |
| 33 |
302907 |
Drag Link Price: Call Us |
| 34 |
124925 |
Nut, Hx, Jam, 3/8-24 Thd. Price: Call Us |
| 35 |
306569 |
Hubcap, Front Price: Call Us |
| 36 |
306669 |
Clip, Hubcap Price: Call Us |
| 37 |
314888 |
Assembly, Foot Pad R.H. Price: Call Us |
| 38 |
304702 |
Dash, Lower Price: Call Us |
| 39 |
45263 |
Screw, Tap, 5/16-18 x 3/8 In. Price: Call Us |
| 40 |
995346 |
Screw, Self-Tap, 1/4-20 x 1/2 In. Price: Call Us |
| 41 |
305280 |
Cover Price: Call Us |
| 42 |
303228 |
Bushing, Upper Steering Price: Call Us |
| 43 |
309199 |
Dash, Upper Price: Call Us |
| 44 |
303132 |
Steering Wheel Price: Call Us |
| 45 |
456378 |
Pin, Spring, 1/4 x 2 In. Price: Call Us |
| 46 |
305850 |
Screw, Tap, 1/4-20 x 1/2 In. Price: Call Us |
| 47 |
120854 |
Screw, Hx Hd, 1/4-20 x 5/8 In. Price: Call Us |
| 48 |
120392 |
Washer, Flat, 9/32 In. Price: Call Us |
| 49 |
1502 |
Nut, Hx, Ctrlk, 1/4-20 Thd. Price: Call Us |
| 50 |
302307 |
Shaft, Steering Price: Call Us |
| 51 |
302524 |
Pin, Dowel Price: Call Us |
| 52 |
302314 |
Pinion, Steering Price: Call Us |
| 53 |
302498 |
Bearing, Flange Price: Call Us |
| 54 |
309195 |
Plate, Electric Clutch Price: Call Us |
| 55 |
2968 |
Washer, Flat, 1/2 In. Price: Call Us |
| 56 |
20864 |
E-Ring Price: Call Us |
| 57 |
57158 |
Ball, Joint, 3/8 Thd. Price: Call Us |
| 58 |
311087 |
Ratchet Fastener Price: Call Us |
| 59 |
307112 |
Plug, Front Axle Price: Call Us |
| 60 |
308115 |
Foam, Hood Baffle Price: Call Us |
| 61 |
47453 |
Wide Trim 18" Price: Call Us |
| 62 |
306856 |
Grille Price: Call Us |
| 63 |
300440 |
Belt Guide Price: Call Us |
| 64 |
312085 |
Screw, #4-24 x 1/2 In. Price: Call Us |
| 65 |
306857 |
Clip, Tinnerman Price: Call Us |
| 66 |
311728 |
Decal, Gunsight Cent. Steer Wheel Price: Call Us |
| 67 |
300302 |
Screw, #10 x 1/2 In. Price: Call Us |
| 68 |
312904 |
Bracket, Stop Price: Call Us |
| 69 |
316634 |
Decal, Pin Stripe R.H Price: Call Us |
| 70 |
53652 |
Screw, Hex Fl, 5/16-18 x 3/4 In. Price: Call Us |
| 71 |
138538 |
Washer, Internal Tooth Price: Call Us |
| 72 |
316635 |
Decal, Pin Stripe L.H. Price: Call Us |
| 73 |
311730 |
Decal, Wheel 4 Steer Husq. Price: Call Us |
| 74 |
307772 |
Decal Oper Instr ERO Top Frame Price: Call Us |
| 75 |
307280 |
Decal, Dash, Chg, Oil, Fuel, All Systems Price: Call Us |
| 76 |
311724 |
Decal, Fender Rear, Hood, Husq. Price: Call Us |
