| Ref | Part Number | Description |
|---|
| 1 |
84005416 |
CRADLE Price: $172.24 |
| 2 |
84006607 |
PANEL-BOTTOM Price: Call Us |
| 3 |
84002939 |
FOOT-RUBBER Price: $7.73 |
| 4 |
84006606 |
PANEL-SIDE Price: Call Us |
| 5 |
84006617 |
PANEL-BATTERY Price: Call Us |
| 6 |
84002976 |
SCREW Price: $2.94 |
| 7 |
84002910 |
SCREW Price: $3.28 |
| 8 |
84006620 |
HUBCAP Price: Call Us |
| 9 |
771593 |
E-RING Price: $3.39 |
| 10 |
319940GS |
WHEEL Price: $47.05 |
| 11 |
84002909 |
AXLE Price: $11.65 |
| 12 |
709938 |
NUT-M10 FLANGE LOCK Price: $5.82 |
| 13 |
84002954 |
TRAP-DRAIN Price: $6.46 |
| 14 |
807084 |
SCREW This part replaces 706865. Price: $2.92 |
| 15 |
84006622 |
PANEL-ACCESS Price: Call Us |
| 16 |
84002917 |
GROMMET Price: $3.17 |
| 17 |
84006605 |
PANEL-BACK Price: Call Us |
| 18 |
91526GS |
MACHINE SCREW, Phllps Pn Hd Price: $3.09 |
| 19 |
84002951 |
CONTROLLER-IGNITION Price: $36.85 |
| 20 |
84002960 |
ASSY-HANDLE Price: $192.80 |
| 21 |
84002968 |
BRACKET Price: $5.50 |
| 22 |
84002969 |
BUSHING Price: $5.50 |
| 23 |
191364GS |
SCREW Price: Call Us |
| 24 |
84002982 |
NUT-SPECIAL Price: $2.96 |
| 25 |
84002961 |
SCREW Price: $2.22 |
| 26 |
707168 |
FILTER-FUEL TANK Price: $3.85 |
| 27 |
84006629 |
DECAL Price: Call Us |
| 29 |
84002468 |
DECAL Price: $8.38 |
| 31 |
84002946 |
GAUGE-FUEL Price: $26.49 |
| 32 |
316506GS |
WASHER-FLAT Price: Call Us |
| 33 |
590644 |
SCREW This part replaces 706866. Price: $3.36 |
| 36 |
84002943 |
GROMMET-FUEL Price: $5.82 |
| 37 |
84006625 |
CAP, FUEL Price: $18.75 |
| 38 |
84001051 |
DECAL Price: $10.48 |
| 39 |
84006632 |
DECAL Price: Call Us |
| 40 |
84006631 |
DECAL Price: Call Us |
| 41 |
84001068 |
DECAL Price: $9.32 |
| 42 |
84006610 |
PANEL-TOP, FUEL TRAY Assembly Price: Call Us |
| 43 |
84002949 |
CLAMP Price: $2.96 |
| 44 |
315017GS |
HOSE, Vapor (cut to fit) Price: $26.64 |
| 45 |
84006612 |
PLATE, Mounting, Fuel Switch Price: Call Us |
| 46 |
84006614 |
BOLT, Hex Flangebolt, M6 x 16 Price: Call Us |
| 47 |
84006613 |
BOLT, Hex Flangebolt, M5 x 12 Price: Call Us |
| 48 |
84002959 |
VALVE-FUEL Price: $10.65 |
| 49 |
84004882 |
BODY, Fuel Selector Price: $3.06 |
| 50 |
84004881 |
SPRING Price: $2.64 |
| 51 |
84006615 |
SCREW, Self Tapping Price: Call Us |
| 52 |
84004880 |
WHEEL-FUEL SELECTOR Price: $2.43 |
| 53 |
84004883 |
ROCKER ARM-FUEL SELECTOR Price: $2.00 |
| 54 |
84006624 |
ASSEMBLY, Choke Cable Price: Call Us |
| 55 |
84004879 |
SWITCH Price: $6.03 |
| 56 |
84004878 |
COVER Price: $2.37 |
| 57 |
84002925 |
KNOB-FUEL VALVE Price: $2.96 |
| 58 |
84002926 |
SCREW Price: $2.75 |
| 59 |
84006616 |
COVER, Fuel Knob Price: Call Us |
| 60 |
706357 |
FUNNEL Price: $30.04 |
