| Ref | Part Number | Description |
|---|
| 1 |
108-2948 |
HYD MOTOR ASM (CW) Price: $1,640.43 |
| 2 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 3 |
144-1381 |
FRONT WHEEL HUB ASM This part replaces 110-6310. Price: $286.28 |
| 4 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 5 |
110-6314 |
SPINDLE Price: $158.31 |
| 6 |
147-3670 |
WHEEL AND TIRE ASM This part replaces 95-0621. Price: $268.49 |
| 7 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 8 |
323-8 |
SCREW-HH Price: $1.20 |
| 9 |
85-8950 |
FLANGETTE-STANDARD Price: $11.06 |
| 10 |
85-8940 |
FLANGETTE-RELUBE Price: $9.50 |
| 11 |
251-352 |
BEARING Price: $47.92 |
| 12 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
88-8350 |
TAB-BEARING Price: $7.12 |
| 14 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 15 |
3274-93 |
SCREW-HSH Price: $3.39 |
| 16 |
340-89 |
FITTING-HYD, 45 DEG Price: $40.22 |
| 17 |
108-8432 |
TUBE ASM Price: $80.09 |
| 18 |
108-8431 |
TUBE ASM Price: $72.81 |
| 19 |
56-7976 |
CLAMP-TUBE Price: $2.44 |
| 20 |
69-9760 |
COVERPLATE Price: $5.38 |
| 21 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 22 |
108-8411 |
TUBE ASM Price: $94.86 |
| 23 |
108-8409 |
TUBE ASM Price: $95.42 |
| 24 |
108-8433 |
HYD HOSE ASM Price: $108.54 |
| 25 |
110-6303 |
HYD HOSE ASM Price: $116.55 |
| 26 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 27 |
108-8455-01 |
BRACKET-CLAMP Price: $13.63 |
| 28 |
3230-6 |
BOLT-CARR Price: $0.59 |
| 29 |
322-7 |
SCREW-HH Price: $0.89 |
| 30 |
130-7873 |
GUIDE-HOSE This part replaces 108-8435. Price: $15.58 |
| 31 |
107-3399 |
ADAPTER-WEIGHT, WHEEL Price: $38.00 |
| 32 |
110-6311 |
STUD Price: $14.32 |
| 33 |
110-6312-03 |
WEIGHT Price: $303.27 |
| 34 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 35 |
322-10 |
SCREW-HH Price: $0.70 |
