| Ref | Part Number | Description |
|---|
| 1 |
00497400 |
FENDER, (RH) OUTFRONT Price: $131.55 |
| 2 |
00473951 |
PANEL, CONTROL Price: $112.45 |
| 3 |
00616851 |
STIFFENER, FENDER Price: $17.00 |
| 4 |
05901704 |
BLT-HEX .31-18X.75 G5 ZCC This part replaces 05947000. Price: $1.45 |
| 5 |
05901702 |
BLT,HEX .38-16X.75 G5 ZCC This part replaces 05959400. Price: $1.45 |
| 6 |
07400126 |
SCR,TAP .375-16X.50 HWH TR ZCC This part replaces 07412900. Price: $1.45 |
| 8 |
05901715 |
BLT, HEX .50-13X1.00 G5 ZCC This part replaces 05947100. Price: $2.45 |
| 9 |
04315600 |
ASSY,FUEL LINE W/90 DEG FTG Price: $19.45 |
| 10 |
04341100 |
TANK-LH RAPID XZ FUEL This part replaces 04245800. Price: $268.45 |
| 11 |
00672751 |
COVER, TIRE RH Price: $29.95 |
| 12 |
06500910 |
NUT-JAM .375-16 G2 ZCC This part replaces 06535900. Price: $0.95 |
| 13 |
05901724 |
BLT- HEX .38-16X1.25 G5 ZCC This part replaces 05958000. Price: $1.45 |
| 14 |
00672651 |
COVER, TIRE LH Price: $24.95 |
| 15 |
09190300 |
CAP, FUEL - 3.50 RATCHET INLET VENT This part replaces 04237300. Price: $30.95 |
| 16 |
06500810 |
NUT,NYL-FLG .50-13 GF ZCC This part replaces 06500010. Price: $1.45 |
| 18 |
03278800 |
CLAMP, FUEL LINE Price: $0.95 |
| 19 |
06401023 |
WSHR-FLT .375X.875X.083 ZCC This part replaces 06435700. Price: $1.45 |
| 20 |
06500735 |
NUT- SPNLK-FLG .38-16 G5 ZCC This part replaces 06534900. Price: $1.45 |
| 21 |
06300119 |
WSHR-LK-REG .312X.078 ZCC This part replaces 06308600. Price: $0.95 |
| 22 |
04097700 |
CLAMP-HOSE- SPRING .188 Price: $1.45 |
| 24 |
06900437 |
CLAMP, 5/8 INSUL TUBE YWZC Price: Call Us |
| 25 |
05185600 |
VALVE, COMBINATION VENT 3/16 This part replaces 04068910. Price: $16.45 |
| 26 |
04082700 |
GROMMET, REMOTE VENT NITRILE Price: $3.45 |
| 28 |
21539500 |
FILTER, FUEL Price: $15.95 |
| 29 |
03375900 |
HOSE, .188 LOW-PERM BULK GAS Price: $0.95 |
