| Ref | Part Number | Description |
|---|
| 1 |
539130853 |
WHEEL ASM - 9" This part replaces 539111503. Price: $69.99 |
| 1 |
94-5033-03 |
BRACKET-SUPPORT, CYLINDER This part replaces 83-9760. Price: $182.59 |
| 2 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 2 |
539130853 |
WHEEL ASM - 9" This part replaces 539111972. Price: $69.99 |
| 3 |
539111886 |
FRONT DECK PLATE, LEFT Price: $5.99 |
| 3 |
61-2990 |
SPACER Price: $33.75 |
| 4 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 4 |
539111888 |
FRONT PLATE, LEFT Price: $17.99 |
| 5 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 5 |
539111887 |
FRONT DECK PLATE, RIGHT Price: $5.99 |
| 6 |
3250-35 |
SCREW-PPH Price: $3.24 |
| 6 |
539111889 |
FRONT PLATE, RIGHT Price: $11.06 |
| 7 |
5-2655 |
CABLE KEEPER Price: $28.04 |
| 7 |
539111873 |
SHOULDER BOLT Price: $5.99 |
| 8 |
5-2653 |
PULLEY ASM Price: $38.12 |
| 8 |
539111894 |
LEVER Price: $7.99 |
| 9 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 9 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 10 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 10 |
539111955 |
WHEEL PLATE, FRONT Price: $5.73 |
| 11 |
539112789 |
AXLE WASHER Price: $1.99 |
| 11 |
84-8440 |
BUSHING Price: $49.87 |
| 12 |
539110267 |
BUSHING Price: $6.99 |
| 12 |
72-4190 |
PIN-GUIDE, CYLINDER Price: $79.12 |
| 13 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 13 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 14 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 14 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 15 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 15 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 16 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 16 |
539976941 |
HCS 3/8C X 1 1/4 GR5 Price: $3.99 |
| 17 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 17 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 18 |
539130853 |
WHEEL ASM - 9" This part replaces 539111971. Price: $69.99 |
| 18 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 19 |
539130853 |
WHEEL ASM - 9" This part replaces 539111502. Price: $69.99 |
| 19 |
83-8590 |
CABLE - LIFT Price: $34.95 |
| 20 |
323-17 |
SCREW-HH Price: $2.05 |
| 20 |
539111513 |
WHEEL MOUNT, LEFT Price: $10.99 |
| 21 |
539111875 |
WHEEL MOUNT, RIGHT Price: $10.99 |
| 22 |
539111519 |
OUTER WHEEL, LEFT Price: $10.99 |
| 22 |
61-3210 |
PULLEY ASM Price: $45.48 |
| 23 |
256-1 |
BUSHING Price: $21.99 |
| 23 |
539111867 |
OUTER WHEEL, RIGHT Price: $17.99 |
| 24 |
539111509 |
PINION GEAR, 11 TOOTH Price: $4.99 |
| 24 |
61-3230 |
SPACER Price: $18.93 |
| 25 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
539111511 |
DRIVEN GEAR, 45 TOOTH Price: $27.99 |
| 26 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 26 |
539111516 |
BUSHING Price: $2.99 |
| 27 |
539111517 |
BEARING, TRANS SHAFT Price: $27.99 |
| 27 |
83-9130 |
CABLE KEEPER Price: $20.60 |
| 28 |
539111547 |
DEBRIS GUARD Price: $3.99 |
| 28 |
63-1400 |
ROD-BELT Price: $17.83 |
| 29 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 29 |
539111872 |
RETAINING RING, 1/2, EXT Price: $2.99 |
| 30 |
5-2656 |
CABLE KEEPER Price: $27.15 |
| 30 |
539111950 |
LEVER Price: $7.99 |
| 31 |
282-4 |
SHACKLE Price: $32.98 |
| 31 |
539115638 |
ZERK, 3/16, DRIVE IN Price: $4.99 |
| 32 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 32 |
539113138 |
WASHER, SPACER Price: $2.99 |
| 33 |
539990362 |
SCREW 1/4 X 5/8 Price: $3.99 |
| 33 |
61-3830 |
CHAIN Price: $14.52 |
| 34 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 34 |
71-1380 |
PIN - SWITCH ACTUATOR Price: $51.88 |
| 35 |
71-1370 |
SPRING Price: $8.21 |
| 36 |
283-78 |
PIN-CLEVIS Price: $9.25 |
| 37 |
76-0020 |
DISCONTINUED Price: Call Us |
| 38 |
237-42 |
O-RING Price: $2.78 |
| 39 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 40 |
237-22 |
O-RING Price: $2.43 |
| 41 |
110-0973 |
HOSE-HYD This part replaces 85-5310. Price: $84.41 |
| 42 |
83-9620 |
DISCONTINUED Price: Call Us |
| 43 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 44 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 45 |
61-2430 |
LIFT HUB WA Price: $116.98 |
| 46 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
