| Ref | Part Number | Description |
|---|
| 1 |
817120616 |
SCREW 3/8-16X1 This part replaces 532120616. Price: $4.99 |
| 1 |
93-1394 |
NUT-SPLINE This part replaces 77-0340. Price: $27.80 |
| 2 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 2 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 3 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 3 |
539976937 |
HCS 5/16-18X2 Price: $2.99 |
| 4 |
108-6475 |
KIT-BEARING HOUSING This part replaces 10-5120. Price: $42.60 |
| 4 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 5 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 6 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
539917033 |
KEY 1/4 SQ X 2-1/2 Price: $2.99 |
| 7 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 7 |
77-1060 |
ADJUST-HOC, RH Price: $88.45 |
| 8 |
539114387 |
SPACER Price: $7.99 |
| 8 |
70-1200-01 |
FRAME-REEL ASM This part replaces 70-1200. Price: $396.13 |
| 9 |
323-7 |
SCREW-HH Price: $0.65 |
| 9 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 10 |
539120812 |
PULLEY IDLER Price: $17.99 |
| 10 |
57-5200 |
GRASS SHIELD ASM Price: $136.52 |
| 11 |
539115270 |
BUSHING Price: $4.99 |
| 12 |
52-3100 |
BOLT-HOC ECCENTRIC, LH Price: $47.11 |
| 12 |
574355802 |
PLATE, ENGINE, ORG Price: $139.99 |
| 13 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 13 |
596437101 |
Screws This part replaces 539108396. Price: $2.99 |
| 14 |
237-84 |
GROMMET Price: $1.12 |
| 14 |
539116350 |
SPRING - 3.50 Price: $7.99 |
| 15 |
57-9910 |
PIVOT SCREW Price: $6.45 |
| 16 |
574882801 |
HCS 7/16-20 X 4 GR5 ZD Price: $3.99 |
| 16 |
77-1080 |
ADJUST-HOC, LH Price: $88.45 |
| 17 |
52-3120 |
ROLLER ASM Price: $180.27 |
| 17 |
539115546 |
WASHER .43X1.38X.25 Price: $3.99 |
| 18 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 18 |
574382001 |
PULLEY, ENGINE 6.5 Price: $99.99 |
| 19 |
52-3180 |
BEARING-ROLLER, FRONT This part replaces 21-8430. Price: $31.50 |
| 19 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 20 |
3246-2 |
SCREW-SET, HSH Price: $0.54 |
| 21 |
12-0460 |
CAPLUG Price: $2.84 |
| 22 |
323-2 |
SCREW-HH Price: $0.68 |
| 23 |
65-8600 |
KNOB-ADJUSTMENT, HEIGHT Price: $43.42 |
| 24 |
253-61 |
SEAL-OIL Price: $9.11 |
| 25 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 26 |
253-96 |
SEAL-OIL Price: $6.85 |
| 27 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 28 |
137-8580 |
ES REEL-SPA 4 BOLT, 11 BLD This part replaces 12-2789. Price: $507.81 |
| 29 |
57-3210 |
SCREW Price: $2.28 |
| 30 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 31 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 33 |
3295-46 |
RIVET Price: $0.34 |
| 35 |
321-5 |
SCREW-HH Price: $0.22 |
| 36 |
104-2065 |
SCREW-HWH This part replaces 32144-73. Price: $0.28 |
| 37 |
57-5210 |
SHIELD FLAP Price: $7.02 |
| 38 |
36-7260 |
BAR-OFF, CUT Price: $24.10 |
| 39 |
52-3110 |
BOLT-HOC SHOULDER, RH Price: $31.65 |
| 40 |
32128-36 |
NUT-HF Price: $1.56 |
| 41 |
3256-22 |
WASHER-FLAT Price: $0.39 |
