| Ref | Part Number | Description |
|---|
| 1 |
72-9300 |
Cover R.H Price: Call Us |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
72-9230-01 |
BASE-CASE, GEAR This part replaces 72-9230. Price: $176.88 |
| 3 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 4 |
51-3960 |
DECAL Price: $24.99 |
| 5 |
32128-20 |
NUT-HF Price: $0.99 |
| 6 |
72-9240-01 |
BRACKET-EXTENSION This part replaces 72-9240. Price: $23.69 |
| 7 |
322-4 |
SCREW-HH Price: $0.35 |
| 8 |
68-9890-01 |
COVER-GEARBOX, FRONT This part replaces 68-9890. Price: $47.21 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
63-9750 |
MOUNT Price: $18.92 |
| 10 |
68-8560-03 |
BRACKET-GEARBOX This part replaces 68-8560. Price: $57.56 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 11 |
63-8410 |
WASHER Price: $1.76 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 13 |
93-6697 |
DECAL-LUBE This part replaces 70-2560. Price: $11.38 |
| 14 |
108-1370 |
GEARBOX REPLACEMENT KIT This part replaces 68-6810. Price: $862.61 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15 |
532400021 |
TANK.FUEL.SIDE-FILL.3.NON-EPA Price: $99.99 |
| 16 |
323-4 |
SCREW-HH Price: $1.02 |
| 17 |
63-9900 |
GEARBOX PULLEY ASM Price: $135.09 |
| 18 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 19 |
27-6140 |
BUSHING-LOCK, TAPER Price: $84.79 |
| 20 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
119-4762-01 |
COVER-BELT, LH This part replaces 72-9340. Price: $114.44 |
| 24 |
3296-28 |
NUT-LOCK, NI This part replaces 32128-7. Price: $0.61 |
| 25 |
3245-9 |
SCREW-SET, HSH Price: $0.81 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
