| Ref | Part Number | Description |
|---|
| 1 |
04020-09 |
Nut, Hex, 5/8-11 Price: Call Us |
| 2 |
43592 |
Spacer, Cutter Blade This part replaces 43278. Price: Call Us |
| 3 |
04001-01 |
Bolt, Hex Head, 1/4-20 x 3/4 Gr.5 Price: Call Us |
| 4 |
48926 |
Taper Hub, 1.125 Bore Price: Call Us |
| 5 |
482744 |
Pulley, 5.75 OD Taper Bore This part replaces 48924. Price: Call Us |
| 6 |
482744 |
Pulley, 5.75 OD Taper Bore This part replaces 48924. Price: Call Us |
| 7 |
48923 |
Pulley, 5.75 Double Groove Price: Call Us |
| 8 |
04050-05 |
Retaining Ring, .75 Ext "E" Price: Call Us |
| 9 |
48100-02 |
Bushing, Oilite - 1.125 ID Price: Call Us |
| 10 |
48114-04 |
Grease Fitting Price: Call Us |
| 12 |
04021-09 |
Locknut, Elastic Stop, 3/8-16 Price: Call Us |
| 13 |
04041-12 |
Flat Washer, 3/8 (.375 x 1.50 x .060) Price: Call Us |
| 14 |
43277 |
Spacer, J-Hook Price: Call Us |
| 15 |
483215 |
Pulley, 5" Dia. Idler This part replaces 48269. Price: Call Us |
| 16 |
04041-07 |
Flatwasher, 3/8 (.391 x .938 x .105) Price: Call Us |
| 17 |
04001-54 |
Bolt, Hex Head, 3/8-16 x 3 Price: Call Us |
| 18 |
45720 |
Pivot, Idler Arm Price: Call Us |
| 19 |
44107 |
J-Hook Price: Call Us |
| 20 |
43077 |
Spacer, J-Hook Price: Call Us |
| 21 |
04001-46 |
Bolt, Hex Head, 3/8-16 x 2-1/4 Price: Call Us |
| 22 |
45037 |
Idler Pivot Price: Call Us |
| 23 |
04041-08 |
Flatwasher, 3/4 (.776 x 1.25 x .059) Price: Call Us |
| 24 |
04019-03 |
Serr. Fl. Hex Nut, 5/16-18 Price: Call Us |
| 25 |
48100-05 |
Bushing, Oilite - 3/4 ID Price: Call Us |
| 27 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Price: Call Us |
| 28 |
04050-02 |
Retaining Ring, .75 Ext "E" Price: Call Us |
| 29 |
44078 |
Pull Rod, Idler Price: Call Us |
| 30 |
45818 |
Belt Cover, RH Price: Call Us |
| 31 |
45815 |
Belt Cover, LH Price: Call Us |
| 32 |
04029-03 |
Wingnut, Plastic, 3/8-16 Price: Call Us |
| 33 |
481214 |
Gearbox, Deck Drive Price: Call Us |
| 34 |
481213 |
Drive Shaft Price: Call Us |
| 35 |
04063-01 |
Key, 1/4 x 1/4 x 1-1/4 Price: Call Us |
| 37 |
48141 |
Tapered Hub, 1.00 Bore Price: Call Us |
| 38 |
481295 |
Belt, Cutter Deck Price: Call Us |
| 39 |
48089 |
Belt, Cutter Deck Price: Call Us |
| 40 |
46868 |
Cutter Deck with Decals Price: Call Us |
| 41 |
461663 |
Spindle Assembly This part replaces 46631. Price: Call Us |
| 42 |
43589 |
Shaft, Spindle This part replaces 43298. Price: Call Us |
| 43 |
481024 |
Seal, 2.00 OD x 1.50 Bore Price: Call Us |
| 44 |
481022 |
Bearing Assembly Price: Call Us |
| 45 |
48114-04 |
Grease Fitting Price: Call Us |
| 46 |
48677 |
Relief Fitting, Cutter Spindle Price: Call Us |
| 47 |
43644 |
Spindle Housing This part replaces 43294. Price: Call Us |
| 48 |
43312 |
Spacer, Outside Price: Call Us |
| 49 |
43296 |
Spacer, Inside Price: Call Us |
| 50 |
481025 |
Seal, 2.00 OD x 1.625 OD Price: Call Us |
| 51 |
43297 |
Spindle Bushing, Bottom Price: Call Us |
| 52 |
481035 |
Nut, 1-1/16-18 UNEF-2B Price: Call Us |
| 53 |
04063-08 |
Key, 1/4 x 1/4 x 2 Price: Call Us |
| 54 |
481160 |
Blade, 24-1/2" Price: Call Us |
| 55 |
04040-10 |
Washer, 5/8 (.688 x 1.75 x .134) Price: Call Us |
| 56 |
04001-41 |
Bolt, Hex Head, 5/8-11 x 9-1/2 Gr.5 Price: Call Us |
| 57 |
48038 |
Roller Price: Call Us |
| 58 |
04001-10 |
Bolt, Hex Head, 5/16-18 x 1-1/4 Price: Call Us |
| 59 |
04001-08 |
Bolt, Hex Head, 5/16-18 x 3/4 Price: Call Us |
| 60 |
04030-03 |
Lockwasher, 5/16 Price: Call Us |
| 61 |
04040-15 |
Flatwasher, 5/16 (.375 x .875 x .083) Price: Call Us |
| 62 |
45944 |
Shaft, Roller This part replaces 45046. Price: Call Us |
| 63 |
421820 |
Cover, Belt - Front Price: Call Us |
| 64 |
04017-16 |
Serr. Fl Hex Head Capscrew, 5/16-18 x 3/4 Price: Call Us |
| 65 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 66 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr.5 Price: Call Us |
| 67 |
04001-09 |
Bolt, Hex Head, 5/16-18 x 1.0 Price: Call Us |
| 68 |
04021-10 |
Hex Locknut, Elastic Stop, 5/16-18 Price: Call Us |
| 69 |
482245 |
Spring, Discharge Chute This part replaces 481050. Price: Call Us |
| 70 |
461292 |
Discharge Chute, Advantage This part replaces 46726. Price: Call Us |
| 71 |
04001-108 |
Bolt, Hex Head, 5/16-18 x 4-1/4 Price: Call Us |
| 72 |
48181 |
Pulley, Idler Price: Call Us |
| 73 |
04012-06 |
Set Screw, Hex Socket, 3/8-16 x 1/2 Price: Call Us |
