| Ref | Part Number | Description |
|---|
| 1 |
322-9 |
SCREW-HH Price: $3.09 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $219.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
75-6410 |
YOKE SHAFT Price: $249.64 |
| 3 |
75-6420 |
YOKE Price: $911.70 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
302-58 |
FITTING-STRAIGHT Price: $0.81 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
43-3220 |
CAPSCREW-HH Price: $0.82 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
75-4630 |
COUPLER-DRIVELINE Price: $344.51 |
| 8 |
43-2740 |
GASKET ME 660042 Price: $8.23 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
43-2750 |
NUT MM 409671 Price: $18.31 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 10 |
63-7440 |
SOLENOID Price: $480.88 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 11 |
75-1070 |
DISCONTINUED Price: Call Us |
| 12 |
322-4 |
SCREW-HH Price: $0.35 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 14 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
42-9110 |
GASKET Price: $29.21 |
| 15 |
532121749 |
WASHER Price: $2.99 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 16 |
75-4490-03 |
MUFFLER BRKT ASM This part replaces 75-4490. Price: $46.04 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
67-2340 |
BOLT W/WASHER Price: $2.19 |
| 19 |
2412-81 |
CLAMP-R Price: $3.39 |
| 20 |
43-0090 |
SCREW-HH Price: $8.05 |
| 21 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 22 |
75-0940-03 |
FLYWHEEL GUARD ASM This part replaces 75-0940. Price: $277.79 |
| 23 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 24 |
62-3820 |
FITTING-GREASE Price: $9.52 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
54-9180 |
U-JOINT KIT Price: $58.18 |
| 26 |
54-9040 |
YOKE-END Price: $246.14 |
