| Ref | Part Number | Description |
|---|
| 1 |
539130874 |
SEAT for units produced before Serial No. 074439861 This part replaces 539105211. Price: $449.95 |
| 1 |
94-5033-03 |
BRACKET-SUPPORT, CYLINDER This part replaces 83-9760. Price: $182.59 |
| 2 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 2 |
539105539 |
ARM REST CUSHION Price: $158.80 |
| 3 |
539105541 |
SEAT CUSHION Price: $171.22 |
| 3 |
92-7905 |
SWITCH AND BRACKET ASM Price: $293.34 |
| 4 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 4 |
539105951 |
SEAT MOUNT W/DECAL This part replaces 539105283. Price: $72.99 |
| 5 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 5 |
539104525 |
SEAT ROD Price: $9.99 |
| 6 |
3249-3 |
SCREW-PRH Price: $0.34 |
| 6 |
539105039 |
STUD/PLATE MOUNT Price: $4.99 |
| 7 |
5-2655 |
CABLE KEEPER Price: $28.04 |
| 7 |
539990761 |
NUT 1/4C CENTER LOCK This part replaces 539990372. Price: $2.99 |
| 8 |
5-2653 |
PULLEY ASM Price: $38.12 |
| 8 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 9 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 9 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 10 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 10 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 11 |
539104789 |
DECAL, CROWN H Price: $3.10 |
| 11 |
84-8440 |
BUSHING Price: $49.87 |
| 12 |
539105540 |
BACK CUSHION Price: $265.72 |
| 12 |
72-4190 |
PIN-GUIDE, CYLINDER Price: $79.12 |
| 13 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 13 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 14 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 14 |
539105224 |
SEAT BRKT W/DECAL Price: $24.99 |
| 15 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 15 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 16 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 16 |
539105544 |
SEAT RAILS Price: $103.29 |
| 17 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 17 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 18 |
539104392 |
SEAT HARNESS This part replaces 539105545. Price: $14.99 |
| 18 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 19 |
83-8590 |
CABLE - LIFT Price: $34.95 |
| 20 |
323-23 |
SCREW-HH Price: $2.07 |
| 21 |
92-7906 |
DISCONTINUED Price: Call Us |
| 22 |
61-3210 |
PULLEY ASM Price: $45.48 |
| 23 |
256-1 |
BUSHING Price: $21.99 |
| 24 |
61-3230 |
SPACER Price: $18.93 |
| 25 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 26 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 27 |
83-9130 |
CABLE KEEPER Price: $20.60 |
| 28 |
63-1400 |
ROD-BELT Price: $17.83 |
| 29 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 30 |
5-2656 |
CABLE KEEPER Price: $27.15 |
| 31 |
282-4 |
SHACKLE Price: $32.98 |
| 32 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 33 |
61-3830 |
CHAIN Price: $14.52 |
| 34 |
71-1380 |
PIN - SWITCH ACTUATOR Price: $51.88 |
| 35 |
71-1370 |
SPRING Price: $8.21 |
| 36 |
283-78 |
PIN-CLEVIS Price: $9.25 |
| 37 |
76-0020 |
DISCONTINUED Price: Call Us |
| 38 |
237-42 |
O-RING Price: $2.78 |
| 39 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 40 |
237-22 |
O-RING Price: $2.43 |
| 41 |
110-0973 |
HOSE-HYD This part replaces 85-5310. Price: $84.41 |
| 42 |
83-9620 |
DISCONTINUED Price: Call Us |
| 43 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 44 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 45 |
61-2430 |
LIFT HUB WA Price: $116.98 |
| 46 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
