| Ref | Part Number | Description |
|---|
| 1 |
603-0043 |
SPINDLE AS Not Available Price: |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
738-3102 |
Bolt, Shoulder Price: $18.82 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
603-0218 |
PLATE-IDLER MTG Not Available Price: |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
619-3022 |
HOUSING-SPINDLE Not Available Price: |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
703-2178 |
COVER PLATE (RH) Not Available Price: |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
703-2179 |
PLATE COVER Not Available Price: |
| 8 |
703-2184 |
Cup, Top Spindle Price: $9.99 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
703-2185-0637 |
Cup, Bottom Spindle This part replaces 703-2185. Price: $11.96 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $17.99 |
| 10 |
710-0560 |
Bolt, Carriage, 3/8-16 X 1.75 Lg Price: $5.94 |
| 10 |
76-5260 |
DISCONTINUED Price: Call Us |
| 11 |
710-3005 |
Screw, Hex Cap, 3/8-16 X 1.25 Lg GR5 Price: $3.61 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 12 |
710-3178 |
CARRIAGE BOLT 3/8-16 x .75 Price: $3.93 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
710-3252 |
BOLT-BLADE Not Available Price: |
| 14 |
710-3253 |
BOLT, HEX HD BLADE, 3/4-16 x 9.5 Not Available Price: |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 15 |
711-3342 |
SHAFT-BLADE SPINDL Not Available Price: |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 16 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 17 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350-03. Price: $166.30 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 17 |
712-3019 |
Nut, Hex, 7/16-14 GR5 Price: $5.94 |
| 18 |
712-3078 |
Nut, Hex Flange, 3/4-16 Price: $9.13 |
| 19 |
921-0385 |
Seal, Oil This part replaces 721-3038. Price: $23.79 |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 20 |
932-3009 |
Spring, Torsion This part replaces 732-3009. Price: $21.40 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
736-0171 |
Washer, Lock, 7/16 Price: $3.86 |
| 21 |
92-7520 |
THROTTLE CABLE ASM Price: $70.09 |
| 22 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 22 |
936-0206 |
Washer, Spec .378 x 1.0 x .125 Thk This part replaces 736-0206. Price: $3.93 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
736-3014 |
Washer, Flat, .781 X 2.0 X .105 Thk Price: $3.89 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 24 |
936-3015 |
Washer, Flat, .469 x .875 x .105 This part replaces 736-3015. Price: $3.89 |
| 24 |
98-2352-03 |
FRAME-SEAT Price: $456.00 |
| 25 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 25 |
737-0280 |
GREASE FITTING (SLOTTED) Price: $6.84 |
| 26 |
70-1480 |
RELAY Price: $105.19 |
| 26 |
737-3004 |
Fitting, Lube, 90 Degree 1/4-28 Tapper Thd Price: $10.22 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
| 27 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 27 |
741-3063 |
Bearing, Sleeve Price: $15.66 |
| 28 |
48-7880 |
NUT-HEX Price: $0.25 |
| 28 |
941-3050 |
Cup Bearing This part replaces 741-3050. Price: $20.74 |
| 29 |
48-7890 |
NUT-HEX Price: $0.25 |
| 29 |
941-3051 |
Cone Bearing This part replaces 741-3051. Price: $42.82 |
| 30 |
52-2900 |
WASHER-PLASTIC Price: $0.75 |
| 30 |
741-3052 |
SPACER-BRG CUP 2 Not Available Price: |
| 31 |
75-3680-03 |
ROD-SEAT Price: $38.90 |
| 32 |
750-3073 |
BEARING SPACER CUP Not Available Price: |
| 32 |
93-7598 |
LEVER-THROTTLE This part replaces 93-7598-03. Price: $39.13 |
| 33 |
233-42 |
KNOB Price: $12.88 |
| 33 |
750-3082 |
SEAL RING Not Available Price: |
| 34 |
954-3045 |
Belt, Spindle A-Sect x 122.0 This part replaces 754-3045. Price: $55.95 |
| 35 |
954-3066 |
Belt, PTO B0Sect x 62.04 This part replaces 754-3066. Price: $54.10 |
| 36 |
756-3005 |
Pulley, Flat Idler Price: $42.56 |
| 37 |
756-3058 |
V-PULLEY 5.07 OD 1.25 SPLINED ID Not Available Price: |
| 37 |
98-8110 |
DECAL-CLIP Price: $47.91 |
| 45 |
92-7396-03 |
MOUNT-CABLE Price: $12.51 |
| 46 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 47 |
52-5910 |
RING-RETAINING Price: $3.64 |
| 49 |
98-2354-03 |
LATCH-SEAT Price: $41.34 |
| 50 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 51 |
32128-25 |
NUT-HF Price: $3.19 |
| 52 |
66-4190-03 |
SPRING-IDLER, CLUTCH Price: $7.20 |
| 53 |
98-8108 |
DECAL-REAR MANIFOLD Price: $41.51 |
| 54 |
63-9920 |
DISCONTINUED Price: Call Us |
| 55 |
85-6910 |
DECAL-RATING, NOISE Price: $7.03 |
| 56 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 57 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
