| Ref | Part Number | Description |
|---|
| 1 |
237-65 |
O-RING Price: $2.50 |
| 1 |
532429667 |
KIT.CONTROL.SPEED.SELECTOR.SNO This part replaces 532198875. Price: $74.99 |
| 2 |
340-14 |
FITTING-HYD, 45 DEG Price: $42.29 |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 3 |
532197763 |
DRIVE PLATE WELDMENT Price: $54.99 |
| 3 |
92-5691 |
HOSE-HYD Price: $113.74 |
| 4 |
237-22 |
O-RING Price: $2.43 |
| 4 |
532197764 |
SHAFT.HEX.SHORT Price: $11.99 |
| 5 |
340-69 |
ELBOW-BULKHEAD, 45 DEG Price: $31.67 |
| 5 |
597412801 |
BEARING HOUSING ASSY TRUNNION This part replaces 532175344. Price: $29.99 |
| 6 |
583607301 |
RING.RETAINING. This part replaces 812000012. Price: $2.99 |
| 6 |
92-5689 |
FORWARD TUBE ASM Price: $333.88 |
| 7 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872270505. Price: $2.99 |
| 7 |
92-5690 |
REVERSE TUBE ASM Price: $313.01 |
| 8 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 8 |
92-5693-01 |
BRACKET-BULKHEAD This part replaces 92-5693. Price: $31.76 |
| 9 |
532182504 |
SPACER, BEARING Price: $5.99 |
| 9 |
92-5692 |
U-BOLT Price: $40.59 |
| 10 |
340-70 |
NUT-LOCK Price: $2.10 |
| 10 |
532184077 |
LEVER.SHIFTER.PLATE.BLACK Price: $9.99 |
| 11 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 11 |
532175349 |
BRACKET, SHIFTER SUPPORT This part replaces 532184076. Price: $4.99 |
| 12 |
532178695 |
PIN, PIVOT LEVER Price: $4.99 |
| 12 |
92-5698 |
HOSE ASM Price: $262.64 |
| 13 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 13 |
92-5688 |
HOSE ASM Price: $119.23 |
| 14 |
532403300 |
ROD.CLUTCH.YELLOW.ZINC(VT) Price: $9.99 |
| 14 |
92-5686 |
HOSE ASM Price: $275.50 |
| 15 |
111-5088-03 |
JOINT-BALL, STEERING CYLINDER This part replaces 92-4725. Price: $198.95 |
| 15 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 16 |
237-79 |
O-RING Price: $5.46 |
| 16 |
532184075 |
PLATE.DRIVE.MOUNTING.BLACK Price: $14.99 |
| 17 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 17 |
92-4799 |
FITTING-TEE, HYD Price: $159.71 |
| 18 |
532191080 |
PULLEY.TRACTION.7.75 Price: $49.99 |
| 18 |
92-4726 |
TUBE-TRACTION Price: $402.37 |
| 19 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 19 |
92-4728 |
TUBE-FRONT Price: $133.35 |
| 20 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 20 |
92-5677 |
TUBE-TRACTION Price: $331.48 |
| 21 |
874950512 |
SCREW 5/16-18 X .750 Price: $3.99 |
| 21 |
92-4748 |
ADAPTER-HYD, TEE Price: $131.52 |
| 22 |
237-58 |
O-RING Price: $2.18 |
| 22 |
532414557 |
SPRING.TRACTION.IDLER This part replaces 532181044. Price: $4.99 |
| 23 |
532179095 |
SPRING.RETURN Price: $3.99 |
| 23 |
66-5560 |
U-BOLT Price: $12.01 |
| 24 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 24 |
532178828 |
SPRING, BRAKE Price: $4.99 |
| 25 |
532410877 |
PAN.BOTTOM.PLASTIC Price: $19.99 |
| 25 |
92-5696 |
FITTING-ELBOW, 90 DEG Price: $110.05 |
| 26 |
237-80 |
O-RING Price: $6.10 |
| 26 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 27 |
340-94 |
ADAPTER Price: $36.83 |
| 28 |
237-42 |
O-RING Price: $2.78 |
| 29 |
92-2982 |
CONTROL BLOCK ASM Price: $2,640.21 |
| 30 |
92-5687 |
HOSE ASM Price: $113.74 |
| 31 |
340-88 |
FITTING-STRAIGHT Price: $11.24 |
| 32 |
237-78 |
O-RING Price: $3.85 |
| 33 |
322-3 |
SCREW-HH Price: $0.79 |
| 34 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 35 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 36 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 37 |
3217-6 |
NUT-HEX Price: $1.19 |
| 39 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 40 |
86-6460-01 |
BRACKET-BLOCK This part replaces 86-6460. Price: $63.44 |
| 41 |
322-6 |
SCREW-HH Price: $0.45 |
| 42 |
92-4727 |
TUBE-REAR Price: $133.27 |
| 43 |
92-5669 |
HARNESS - SWITCH Price: $51.35 |
| 44 |
69-9740 |
SWITCH Price: $125.46 |
| 45 |
323-9 |
SCREW-HH This part replaces 322-45. Price: $1.29 |
| 46 |
2412-107 |
CLAMP-R Price: $2.65 |
| 47 |
99-8741-01 |
BRACKET-SUPPORT, HOSE This part replaces 99-8741. Price: $32.79 |
