| Ref | Part Number | Description |
|---|
| 1 |
983-05142C |
MUFFLER SHIELD ASSEMBLY This part replaces 683-05142C. Price: $71.68 |
| 2 |
710-04683C |
SCREW 3/8-16 x 1 Price: $5.67 |
| 3 |
710-06133 |
SCREW M6-1 x .625 Price: $3.08 |
| 4 |
710-06256 |
SCREW M8-1.25 x .750 Price: $2.72 |
| 5 |
712-3086 |
HEX FLANGE NUT M8X Price: $3.86 |
| 6 |
726-0205 |
HOSE CLAMP 1/20 Price: $3.71 |
| 7 |
736-0148 |
LOCK WASHER 3/8 Price: $3.19 |
| 10 |
747-11833 |
MUFFLER ROD Price: $6.35 |
| 12 |
751-14478A |
EXHAUST PIPE (LH) (KOHLER) Price: $46.12 |
| 13 |
751-14479A |
EXHAUST PIPE (RH) (KOHLER) Price: $40.68 |
| 14 |
951-14503D |
EXHAUST MUFFLER (TWIN) Price: $65.12 |
| 15 |
751-22813-12 |
FUEL HOSE 1/4-12" This part replaces 751-22813-10. Price: $13.74 |
