| Ref | Part Number | Description |
|---|
| 1 |
68-6820 |
DISCONTINUED Price: Call Us |
| 2 |
68-6910-03 |
RH STEERING ARM ASM This part replaces 68-6910. Price: $213.93 |
| 3 |
3296-4 |
NUT-LOCK This part replaces 3296-43. Price: $0.25 |
| 4 |
3220-5 |
NUT-JAM Price: $0.65 |
| 5 |
3210-7 |
SCREW-HH Price: $0.61 |
| 5 |
532401823 |
DASH.HUSQ.UPR.ELE.SVMD Price: $49.99 |
| 6 |
302-55 |
FITTING-GREASE Price: $3.09 |
| 7 |
108-1340-03 |
ROD END-BALL JOINT This part replaces 68-6870. Price: $163.94 |
| 8 |
105-7835 |
SEAL This part replaces 71-4760. Price: $2.76 |
| 9 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 10 |
32136-13 |
NUT-SHH Price: $2.85 |
| 11 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 12 |
71-4530-03 |
DISCONTINUED This part replaces 71-4750. Price: Call Us |
| 13 |
67-1750 |
BUSHING Price: $0.92 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532401824. Price: $149.99 |
| 14 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 15 |
68-6990-03 |
DISCONTINUED This part replaces 68-6990. Price: Call Us |
| 16 |
33115-025 |
SCREW-HH This part replaces 48-7780. Price: $0.61 |
| 17 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM This part replaces 532400297. Price: $129.99 |
| 18 |
68-6930-03 |
LH STEERING ARM ASM This part replaces 68-6930. Price: $159.13 |
| 19 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 20 |
71-4740-03 |
RH TIE ROD END ASM This part replaces 71-4740. Price: $163.79 |
| 21 |
323-9 |
SCREW-HH Price: $1.29 |
| 22 |
231-122 |
TIRE-4-PLY Price: $126.99 |
| 23 |
71-4450 |
BOLT-LUG Price: $3.29 |
| 24 |
217-106 |
WHEEL-8 INCH Price: $141.58 |
| 25 |
5108 |
VALVE This part replaces 232-31. Price: $6.29 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 26 |
93-6697 |
DECAL-LUBE This part replaces 70-2560. Price: $11.38 |
| 27 |
48-7960 |
NUT Price: $1.40 |
| 28 |
71-4690 |
SCREW-HH Price: $3.65 |
| 29 |
32151-87 |
RING-RETAINING Price: $1.22 |
| 30 |
71-4590 |
WASHER-THRUST Price: $3.32 |
| 31 |
71-4580 |
BEARING Price: $80.51 |
| 32 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 33 |
71-4570-03 |
HOUSING-CLUTCH, ROLLER This part replaces 71-4570. Price: $367.36 |
| 34 |
253-155 |
SEAL-OIL Price: $14.36 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 35 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 36 |
284-3 |
PLUG Price: $7.14 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ This part replaces 532401825. Price: $219.99 |
| 37 |
76-4690-03 |
COUPLING-AXLE This part replaces 76-4690. Price: $318.79 |
| 38 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 39 |
3274-64 |
SCREW-HSH This part replaces 3274-8. Price: $1.02 |
| 40 |
68-6880 |
CLUTCH CABLE BRKT *B Price: $70.92 |
| 41 |
56-2460 |
WASHER-FLAT Price: $3.32 |
| 42 |
5-1226 |
WASHER Price: $3.90 |
| 43 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 58 |
532194314 |
BRKT.SUPPORT.FNDR/TANK Price: $17.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 99 |
532406642 |
ROD.BYPASS.HYDRO.0510/0610.GT This part replaces 532198253. Price: $14.99 |
| 130 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 139 |
532171873 |
BOLT, SHOULDER 5/16-18 Price: $4.99 |
| 150 |
532198513 |
AIR.DUCT.TEXGT.HUSQ.SV Price: $37.99 |
| 152 |
532196390 |
SHIELD.BROWNING.WTEXLT Price: $17.99 |
| 156 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532401826. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532196826 |
SUPPORT.TANK.REAR.W/TEX Price: $22.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
582033001 |
KITS.WELD.CHASSIS.195477X431 This part replaces 532401559. Price: $249.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR This part replaces 532194787. Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 184 |
532195780 |
SPACER.FENDER Price: $5.99 |
| 185 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 196 |
532400299 |
RP CONSOLE.ASM.DECKLFT.W/ Price: $69.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532198904. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 215 |
532198043 |
COVER.CHASSIS.FRONT.WE Price: $4.99 |
| 216 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $7.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 221 |
532198909 |
REFLECTOR.LH.TEX GT HU Price: $14.99 |
