| Ref | Part Number | Description |
|---|
| 1 |
3269-5 |
RIVET-POP Price: $1.29 |
| 1 |
582733302 |
PLATE.PNT.ENGINE.PZ/PZT.EDIP Price: $59.99 |
| 2 |
539113437 |
CLUTCH, 150 FT/LBS Price: $399.99 |
| 2 |
95-8707 |
COVER-DASH Price: $194.77 |
| 3 |
532178151 |
GASKET This part replaces 586839701. Price: $4.99 |
| 3 |
95-8763 |
BRACKET-HOLD DOWN, COVER Price: $13.94 |
| 4 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 4 |
539118911 |
PIPE NIPPLE 3/8 X 3 Price: $5.99 |
| 5 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 5 |
522837001 |
PLUG, DRAIN 3/8 NPTF Price: $2.99 |
| 6 |
510019801 |
PULLEY, ENGINE Price: $49.99 |
| 6 |
95-8764-0P |
SUPPORT-MAGNET This part replaces 95-8764-03. Price: $35.03 |
| 7 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 7 |
539119680 |
ADAPTER, OIL DRAIN Price: $17.99 |
| 8 |
95-8765 |
BRACKET-STRIKE, MAGNET Price: $9.32 |
| 9 |
539105308 |
KEY 1/4 SQ X 1.0 Price: $3.99 |
| 9 |
58-4250 |
CATCH-MAGNETIC Price: $39.31 |
| 10 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 10 |
539910210 |
KEY 1/4 SQ X 2 Price: $4.99 |
| 11 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 12 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 12 |
539109618 |
O-RING Price: $3.99 |
| 13 |
525313902 |
Spacers This part replaces 525313901. Price: $14.99 |
| 13 |
95-8684 |
PAD-BUMPER Price: $27.13 |
| 14 |
3289-4 |
SCREW-FH Price: $3.27 |
| 14 |
597180803 |
Stop This part replaces 522676702. Price: $11.99 |
| 15 |
104-4628 |
LINK-BRAKE, PARKING Price: $18.33 |
| 15 |
505280001 |
TIE WRAP, 8-3/8", W/CLIP Price: $2.99 |
| 16 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 16 |
581332805 |
Bolts This part replaces 581332801. Price: $2.99 |
| 17 |
574233802 |
Hardware This part replaces 574233801. Price: $2.99 |
| 17 |
94-3829 |
PIN-CLEVIS Price: $2.10 |
| 18 |
104-4817 |
LEVER-BRAKE Price: $143.45 |
| 19 |
596436601 |
Screws This part replaces 539104867. Price: $1.99 |
| 19 |
87-4710 |
SPACER-BRAKE, PARKING Price: $4.27 |
| 20 |
32105-9 |
SCREW Price: $0.54 |
| 20 |
595901501 |
Bolts This part replaces 539990208. Price: $3.99 |
| 21 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 21 |
95-8900 |
SWITCH Price: $95.42 |
| 22 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 23 |
3256-21 |
WASHER-FLAT Price: $0.25 |
| 23 |
539102593 |
WASHER, 3/8 DISC SPRING SPEC Price: $2.99 |
| 24 |
3296-9 |
NUT-HEX Price: $0.25 |
| 24 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 25 |
321-10 |
SCREW-HH Price: $1.29 |
| 25 |
539125626 |
BLADE WASHER Price: $6.99 |
| 26 |
3272-6 |
PIN-COTTER Price: $0.25 |
