| Ref | Part Number | Description |
|---|
| 1 |
952030249 |
Spark Plug (RCJ-6Y) Price: Call Us |
| 1 |
BS-807857 |
AIR CLEANER BASE Not Available Price: |
| 2 |
530015953 |
Screw Price: $1.99 |
| 2 |
BS-691982 |
HEX SCREW Not Available This part replaces BS-805406. Price: |
| 3 |
530055191 |
Insulator-Heat Price: $1.99 |
| 3 |
BS-810078 |
NUT, HEX Not Available Price: |
| 4 |
530016387 |
Screw-Muffler-Internal Price: $1.99 |
| 4 |
BS-394018S |
Precleaner This part replaces BS-394018. Price: $25.03 |
| 5 |
530015241 |
Screw Price: $1.99 |
| 5 |
BS-691985 |
AIR CLEANER NUT Not Available This part replaces BS-491875. Price: |
| 6 |
BS-272490S |
Wire Harness (Oil Sending Unit) This part replaces BS-272490. Price: $7.38 |
| 7 |
BS-692081 |
AIR CLEANER GASKET Not Available This part replaces BS-805655. Price: |
| 8 |
530071458 |
Gasket-Baffle (kit) Price: $5.99 |
| 8 |
BS-699959 |
AIR CLEANER COVER Not Available This part replaces BS-807862. Price: |
| 9 |
530071458 |
Gasket-Cylinder (kit) Price: $5.99 |
| 9 |
BS-844932 |
AIR CLEANER PLATE Not Available This part replaces BS-805631. Price: |
| 10 |
530071457 |
Kit-Cylinder Price: $11.99 |
| 10 |
BS-691492 |
HEX SCREW Not Available This part replaces BS-805057. Price: |
| 11 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 11 |
BS-807859 |
AIR CLEANER BRACKET Not Available Price: |
| 12 |
530016357 |
Screw-Ignition Module Price: $1.99 |
| 12 |
BS-805632 |
TUBE-AIR I Not Available Price: |
| 13 |
530035505 |
Ignition Module Price: $29.99 |
| 13 |
BS-844930 |
CARBURETOR SHIELD Not Available This part replaces BS-807797. Price: |
| 15 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 16 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 17 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 18 |
530071615 |
Kit-Crankcase Seal Price: $4.99 |
| 19 |
530055728 |
Bearing-Outer Price: $6.99 |
| 20 |
530015941 |
Retainer Ring-C'chaft Price: $1.99 |
| 21 |
530016190 |
Spacer-Flywheel Price: $2.99 |
| 22 |
530015149 |
Washer Price: $1.99 |
| 23 |
530063575 |
FLYWHEEL This part replaces 530039209. Price: Call Us |
| 26 |
738210101 |
BEARING BALL 6001 This part replaces 530032125. Price: $8.99 |
| 27 |
530012452 |
Assy-Crankshaft Price: $23.99 |
| 28 |
530071458 |
O-ring-C/case (kit) Price: $5.99 |
| 29 |
530012443 |
Cover-Crankcase Price: $5.99 |
| 30 |
530016386 |
Screw This part replaces 530015810. Price: $5.99 |
| 31 |
530071459 |
Foam-219mm (kit) Price: $4.99 |
| 32 |
530029182 |
Eyelet-Flange Price: $1.99 |
| 33 |
530071467 |
Kit-Rope Price: $4.99 |
| 34 |
530054834 |
Handle-Starter Price: $1.99 |
| 35 |
530016326 |
Screw-Rope Price: $1.99 |
| 36 |
530016240 |
Washer-Belleville Price: $1.99 |
| 37 |
530626605 |
Nut Price: $1.99 |
| 38 |
530402043 |
Spring-Return Cover Price: $2.99 |
| 39 |
530049313 |
Inlet Door Price: $4.99 |
| 40 |
530095461 |
Assy-Mulch Blade Price: $5.99 |
| 41 |
530069817 |
Assy-Impeller Price: $12.99 |
| 42 |
530056625 |
Seal-Ring Price: $3.99 |
| 43 |
530016349 |
Screw Price: $1.99 |
| 44 |
530055101 |
Housing-Pulley Price: $6.99 |
| 45 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 46 |
530054425 |
PULLEY, STARTER This part replaces 530071466. Price: $7.35 |
| 47 |
530055102 |
Fan Housing Price: $13.99 |
| 48 |
530016386 |
Screw This part replaces 530015810. Price: $5.99 |
| 49 |
530071459 |
Foam-182mm (kit) Price: $4.99 |
