| Ref | Part Number | Description |
|---|
| 0 |
640278A |
CARBURETOR This part replaces 640278. Price: $77.00 |
| 1 |
106-1367 |
SKID ASM Price: $1,934.60 |
| 1 |
530400757 |
Motor Hsg. Set Price: $19.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
106-1290-03 |
DOOR ASM Price: $110.54 |
| 2 |
534935801 |
Motor Ass'y. Price: $3.33 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 3 |
534494601 |
Washer Price: $1.99 |
| 4 |
32128-20 |
NUT-HF Price: $0.99 |
| 4 |
534526802 |
Fan Price: $2.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
534900825 |
Shaft Adapter Price: $3.33 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 5 |
92-3700 |
MAGNET-DOOR Price: $20.72 |
| 6 |
237-102 |
GROMMET Price: $62.07 |
| 6 |
534100711 |
Flex Shaft/Bearing Ass'y. Kit Price: $13.84 |
| 6 |
640070 |
SHUTTER Price: $1.25 |
| 7 |
107-2858 |
PIVOT-LUG Price: $33.94 |
| 7 |
534904001 |
Tube Ass'y. Price: $17.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
3234-40 |
SCREW-HF Price: $3.38 |
| 8 |
534790300 |
Screw Price: $3.33 |
| 9 |
534958900 |
Warning Label (Not a serviceable part) Price: $3.33 |
| 10 |
107-2859 |
BRACKET-MOUNT, FRONT Price: $33.22 |
| 10 |
530400762 |
Motor Hsg. Label (Not a serviceable part) Price: $3.33 |
| 10 |
630973 |
SHAFT & LEV Price: $5.16 |
| 11 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 11 |
534799500 |
Screw Price: $1.99 |
| 11 |
632045 |
SPRING Price: $1.25 |
| 12 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 12 |
534829600 |
Screw Price: $3.33 |
| 13 |
534336600 |
P.C. Bridge Price: $3.33 |
| 14 |
534904702 |
Harness Ass'y. (Incl. 13 & 15) Price: $27.99 |
| 14 |
640150 |
SHUTTER Price: $1.55 |
| 15 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 15 |
534982000 |
Switch Price: $4.99 |
| 16 |
325-6 |
SCREW-HH Price: $1.42 |
| 16 |
534805300 |
Wire Mount Board Price: $3.33 |
| 16 |
631807 |
FUEL FITTING Price: $6.03 |
| 17 |
32153-5 |
NUT-HEX Price: $1.59 |
| 17 |
534790700 |
Trigger Spring Price: $1.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
534904904 |
Trigger Price: $1.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
530400758 |
Trigger Hsg. Set Price: $3.33 |
| 20 |
105-9482-03 |
JACK STAND ASM Price: $67.88 |
| 20 |
534790301 |
Screw Price: $3.33 |
| 20 |
640027 |
FUEL JET Price: $2.60 |
| 20A |
640053 |
CAP Price: $0.81 |
| 21 |
100-4523 |
PIN-HITCH Price: $13.08 |
| 21 |
534903100 |
Screw Price: $1.99 |
| 22 |
106-1345-03 |
BASE-PUMP Price: $119.99 |
| 22 |
534828701 |
Washer Price: $3.33 |
| 23 |
108-3496-03 |
BRACKET-PUMP, RH Price: $128.98 |
| 23 |
530347898 |
Knob Price: $2.99 |
| 24 |
108-3497-03 |
BRACKET-PUMP, LH Price: $128.98 |
| 24 |
534790500 |
Nut Price: $1.99 |
| 25 |
108-3703-03 |
ANGLE-BOOM MOUNT, RH Price: $71.31 |
| 25 |
530400759 |
Spindle Hsg. Set Price: $17.99 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 26 |
108-3704-03 |
ANGLE-BOOM MOUNT, LH Price: $71.31 |
| 26 |
534788905 |
Tubing Sleeve Price: $1.99 |
| 27 |
534636002 |
Felt Washer Price: $1.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 28 |
534246702 |
Retaining Ring Price: $1.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
32128-49 |
NUT-HHF Price: $1.04 |
| 29 |
534982200 |
Switch Insulator Price: $1.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
534907305 |
Cutting Head Ass'y. Price: $19.36 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
534905501 |
Guard Ass'y. Price: $3.33 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
530400795 |
Spindle Head Ass'y. (Incl. 12, 20, 24-27, & 30) Price: $41.92 |
| 33 |
534134706 |
Tie Strap Price: $1.99 |
| 34 |
534914801 |
Handle Ass'y. (Incl. 20,22,23 & 35) Price: $7.99 |
| 35 |
534352400 |
Screw Price: $1.99 |
| 35 |
640259 |
PRIMER Price: $6.16 |
| 36 |
534270100 |
Hanger Price: $1.99 |
| 36 |
632735 |
NOZZLE Price: $4.95 |
| 37 |
534036644 |
Cover Price: $1.84 |
| 37 |
632547 |
O RING Price: $1.49 |
| 37 |
92-2667-03 |
BRACKET-MOUNT Price: $14.23 |
| 38 |
534907903 |
Spool w/Line Price: $7.02 |
| 38 |
70-2041 |
TRIM Price: $5.30 |
| 39 |
534014475 |
Cam Price: $2.99 |
| 40 |
2412-126 |
R-CLAMP Price: $2.51 |
| 40 |
534899200 |
Arm Price: $3.33 |
| 40 |
640050 |
NUT Price: $5.16 |
| 41 |
119-0686-03 |
LH CYLINDER MOUNT ASM Price: $91.37 |
| 41 |
534908501 |
Spring Price: $1.99 |
| 42 |
119-0688-03 |
RH CYLINDER MOUNT ASM Price: $87.44 |
| 42 |
534900200 |
Line Shield Price: $3.33 |
| 43 |
110-5050 |
SCREW-HHF Price: $2.59 |
| 43 |
534014477 |
Housing Head Price: $3.33 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 44 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 44 |
534900301 |
Drive Adaptor Price: $6.99 |
| 45 |
534400701 |
Push Nut Price: $1.99 |
| 46 |
534908700 |
Washer Price: $1.99 |
| 47 |
534136401 |
Screw Price: $1.99 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
534228700 |
Screw Price: $1.99 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 49 |
534207101 |
Endbell Ass'y. (Drive) Price: $3.33 |
| 50 |
534228800 |
Washer Price: $1.99 |
| 51 |
534227001 |
Field Ass'y. Price: $24.99 |
| 52 |
534246700 |
Retaining Ring Price: $0.99 |
| 53 |
534944001 |
Armature Ass'y. Price: $3.33 |
| 54 |
534228802 |
Washer Price: $0.99 |
| 55 |
534238903 |
Washer Price: $1.99 |
| 56 |
534227501 |
Endbell Ass'y. (Brush) Price: $3.33 |
| 57 |
534226000 |
Insulator Price: $3.33 |
| 58 |
534227800 |
Brush Price: $3.16 |
| 59 |
534228000 |
Spring Brush Price: $1.99 |
| 60 |
534227700 |
Brush Holder Price: $3.33 |
| 61 |
534450400 |
Brush Holder Ass'y. (Incl. 58-60) Price: $12.32 |
