| Ref | Part Number | Description |
|---|
| 1 |
687-05180-0638 |
DETHATCHER FRAME ASSEMBLY (MTD RED) Not Available Price: |
| 2 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 3 |
710-05074 |
SCREW 1/4-20 x 1.0 Price: $2.90 |
| 4 |
710-0597 |
SCREW 1/4-20 X1.00 GR5 Price: $3.66 |
| 5 |
911-1146 |
CASTER AXLE Price: $11.60 |
| 6 |
712-0397A |
WING NUT Price: $3.71 |
| 7 |
712-04064 |
FLANGE LOCK NUT Price: $3.64 |
| 8 |
731-10490 |
HANDLE Price: $34.32 |
| 9 |
732-05402A |
DETHATCHER SPRING Price: $8.49 |
| 10 |
732-05404 |
DETHATCHER RETAINING WIRE Not Available Price: |
| 11 |
735-05069 |
BUMPER PAD Price: $5.14 |
| 12 |
738-04502 |
SHOULDER SCREW 1/4-20 x .50 Price: $3.75 |
| 13 |
938-0958 |
SHOULDER SPACER Price: $3.70 |
| 14 |
738-1226 |
Shoulder Screw This part replaces 938-1226. Price: $6.73 |
| 15 |
787-03195-0637 |
SUPPORT BRACKET Price: $10.29 |
