| Ref | Part Number | Description |
|---|
| 2 |
86-8101-01 |
JOINT-BALL, LH This part replaces 86-8101-03. Price: $64.64 |
| 3 |
324-19 |
SCREW-HH Price: $1.29 |
| 4 |
283-55 |
PIN-CLEVIS Price: $11.14 |
| 5 |
95-6231 |
CHAIN-HOC Price: $14.75 |
| 6 |
104-0108 |
U-BOLT Price: $7.10 |
| 7 |
3217-9 |
NUT-HH Price: $0.37 |
| 8 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 9 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 10 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 11 |
100-3031 |
RH LIFT ARM ASM Price: $640.71 |
| 12 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
140-6337 |
PIN ASM This part replaces 100-3017. Price: $55.25 |
| 14 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 15 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 16 |
105-7456 |
PIN-PIVOT Price: $21.24 |
| 17 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 18 |
107-4304 |
HYD CYLINDER ASM Price: $637.96 |
| 19 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 20 |
120-5575 |
PIN This part replaces 100-3020. Price: $24.69 |
| 21 |
323-7 |
SCREW-HH Price: $0.65 |
| 22 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 23 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 24 |
21-3001 |
NUT-JAM Price: $10.04 |
| 25 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 26 |
140-5809 |
SUPPORT-HUB This part replaces 93-4583-01. Price: $40.20 |
| 27 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 28 |
87-7480 |
WASHER Price: $1.26 |
| 29 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 30 |
104-3542 |
SPIDER Price: $67.38 |
| 31 |
104-3541 |
HUB-SPIDER Price: $130.30 |
| 33 |
127-3694 |
HYD MOTOR ASM This part replaces 99-5489. Price: $968.32 |
| 34 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 35 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 36 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 38 |
115-0282 |
PROXIMITY SENSOR ASM Price: $155.22 |
| 39 |
119-5312 |
PLATE-SENSING, FRONT Price: $8.84 |
| 40 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 41 |
119-5311 |
MOUNT-SWITCH, FRONT Price: $17.27 |
| 42 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 43 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 44 |
3230-16 |
SCREW-CARR Price: $1.79 |
| 45 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 46 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 47 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 50 |
100-3032 |
LH LIFT ARM ASM Price: $640.71 |
