| Ref | Part Number | Description |
|---|
| 1 |
532850735 |
CONTROL BAR/BLACK This part replaces 532850758. Price: $4.69 |
| 2 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532850724. Price: $4.99 |
| 3 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532132001. Price: $7.99 |
| 4 |
532166268 |
UPPER HANDLE This part replaces 532125295. Price: $20.88 |
| 5 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532125293. Price: $54.99 |
| 6 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 7 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 8 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 9 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 10 |
532851671 |
CABLE ASSEMBLY Price: $12.99 |
| 11 |
874250434 |
SCREW.1/4-20.CROSS.RECESS. This part replaces 532085692. Price: $3.99 |
| 12 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 13 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532063688. Price: $9.99 |
| 14 |
532850845 |
HUB CAP Price: $3.99 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 16 |
532428450 |
KIT.O-RING/WASHER This part replaces 532057143. Price: $3.99 |
| 17 |
532435276 |
WHEEL.8X1.75.CF5SPK.RAD.BLACK This part replaces 532800333. Price: $24.99 |
| 18 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532084921. Price: $7.99 |
| 19 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 20 |
532125066 |
SELECTOR SPRING Price: $4.99 |
| 21 |
532701037 |
SELECTOR KNOB This part replaces 532132800. Price: $4.99 |
| 22 |
532800754 |
AXLE ARM ASSY This part replaces 532125061. Price: $5.74 |
| 24 |
532036953 |
SCREW Price: $3.15 |
| 25 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532084920. Price: $3.99 |
| 26 |
532140058 |
BRACKET WHL ADJ This part replaces 532800370. Price: $4.99 |
| 27 |
532800368 |
WHL ADJ BRKT LF/RR Price: $5.99 |
| 28 |
532125449 |
HANDLE BRACKET ASS'Y (RIGHT) Price: $7.33 |
| 29 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 30 |
532125448 |
HANDLE BRACKET ASS'Y (LEFT) Price: $7.33 |
| 31 |
874760424 |
Bolt, Hex 1/4-20 x 1-1/2 This part replaces 532085436. Price: $2.42 |
| 32 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 33 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 34 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532055187. Price: $4.99 |
| 35 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 36 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 37 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 38 |
532145106 |
BLADE.20.MULCH.(50DK,6020MD) This part replaces 532751646. Price: $17.99 |
| 39 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $14.99 |
| 42 |
532751649 |
ROD.SKIRT.14.06.MULCHER.20 Price: $3.99 |
| 43 |
532140544 |
REAR DEFLECTOR This part replaces 532751648. Price: $10.99 |
| 44 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 45 |
532700417 |
THROTTLE CONTROL Price: $17.99 |
| 46 |
532085723 |
WASHER PM Price: $2.99 |
| 48 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 50 |
532800547 |
TRIM PLATE Price: $7.15 |
| 51 |
532150406 |
BOLT 3/8-16X1-1/8 This part replaces 532850998. Price: $4.99 |
| 52 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 532700666 |
OPER |
MANUAL 51M (ENGLISH) Price: $2.90 532700666 |
| 532700667 |
OPER |
MANUAL 51M (FRENCH) Price: $2.90 532700667 |
| 532800569 |
ENG |
DECAL NLA Price: $2.52 532800569 |
