HYDRAULIC FRAME

HYDRAULIC FRAME

Parts (74)

RefPart NumberDescription
1 506007902 FRAME, NYDR SUB, BLK Price: $599.99
1 86-5480 NIPPLE-TEST Price: $48.77
2 340-166 FITTING-TEE, HYD Price: $47.31
2 573978301 BELT, "B", 75.5" Price: $49.99
3 340-2 FITTING-STRAIGHT Price: $11.43
3 576035902 ASSEMBLY, RESERVOIR, OIL This part replaces 506120802. Price: $329.99
4 340-77 FITTING-ELBOW, 90 DEG Price: $24.95
4 522805401 FILTER 25 MICRON Price: $27.99
5 354-78 FITTING-STR Price: $49.33
5 506120501 HG_PUMP, 16CC Price: $1,299.99
6 354-79 CAP-DUST Price: $7.81
6 506120401 HG_PUMP, 16CC Price: $1,399.99
7 104-3797 FITTING-STRAIGHT Price: $26.85
7 510283701 Idler This part replaces 510283702. Price: $34.99
8 119-0011 PRESSURE TRANSDUCER ASM Price: $341.50
8 576035902 ASSEMBLY, RESERVOIR, OIL Price: $329.99
9 340-139 FITTING-ELBOW 90 Price: $117.76
9 577437201 SPRING, PUMP Price: $6.99
10 340-7 FITTING-STRAIGHT Price: $14.00
10 574398502 SHIELD, PULLEY, BLK Price: $29.99
11 340-82 FITTING-ELBOW, 90 DEG Price: $20.57
11 510254502 SHIELD DUST This part replaces 510254501. Price: $3.99
12 596394601 Shields This part replaces 539114662. Price: $2.99
12 AU8SA60404 FITTING-STRAIGHT Price: $29.49
13 125-1528 FITTING-STR Price: $56.36
13 539101177 KEY 5 MM SQ X 25 MM Price: $4.99
14 340-105 FITTING-ELBOW, 90 DEG Price: $39.67
14 522842701 Controls This part replaces 522559201. Price: $27.99
15 522842801 LINKAGE, CONTROL, RR Price: $79.99
16 510013601 LINE, RT A Price: $84.99
17 510013701 LINE, RT B Price: $69.99
18 510013801 LINE, LT A Price: $149.99
19 510013901 LINE, LT B Price: $79.99
20 510014001 LINE, CHARGE Price: $179.99
21 510014501 LINE, CASE Price: $139.99
22 510010701 LINE, SUCTION Price: $24.99
23 575872301 FILTER HEAD Price: $37.99
24 539101237 FITTING, STRAIGHT F6400-8-8-0 This part replaces 539101239. Price: $7.99
25 539101237 FITTING, STRAIGHT F6400-8-8-0 Price: $7.99
26 539101242 ELBOW, 90 DEGREE Price: $29.99
27 539102590 BALL JOINT, RIGHT HANDED Price: $19.99
28 539109149 TURNBUCKLE, 3/8 Price: $39.99
29 539103316 STRAIGHT FITG Price: $9.99
30 548058201 CAP HYDRAULIC CAP This part replaces 522805301. Price: $32.99
31 522805001 TUBE, ANTI-SPLASH Price: $99.99
32 510041603 ARM, IDLER, STEEL, W/BGS Price: $49.99
33 510206301 PIVOT, BEARING Price: $3.99
34 525435601 PIVOT, IDLER Price: $5.99
35 576573703 Brackets This part replaces 576573701. Price: $12.99
36 576577601 RUBBER, VIBRATION, 1/2" Price: $7.99
37 595901601 GSPW Bolts This part replaces 539990316. Price: $2.99
38 539100413 RHSNB 3/8-16 X 1-1/4 Price: $2.99
39 596581801 Bolts This part replaces 539130235. Price: $2.99
40 596030801 Bolts This part replaces 539102933. Price: $3.99
41 596582501 Bolts This part replaces 539990072. Price: $2.99
42 593337201 SCREW HEXAGON HEAD WITH COLLAR This part replaces 539113226. Price: $2.99
43 539103433 HCS 1/2C X 3 1/4 Price: $5.99
44 539101332 HCS 1/2C X 2 3/4 Price: $4.99
45 525544802 Screws This part replaces 525544801. Price: $2.99
46 525834202 Screws This part replaces 525834201. Price: $3.99
47 525544002 Bolts This part replaces 525544001. Price: $3.99
48 539102717 SCREW 5/16C X 5/8 SQ HEAD Price: $2.99
49 539105168 NUT 9/16-18 JIC CAP Price: $2.99
50 596040901 Hardware This part replaces 539990223. Price: $2.99
51 596029901 Hardware This part replaces 539108732. Price: $2.99
52 521996502 GSPW Nuts This part replaces 521996501. Price: $2.99
53 594944401 NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99
54 596230801 Nuts This part replaces 539200282. Price: $2.99
55 596583501 Washers This part replaces 539990613. Price: $2.99
56 521991102 NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99
57 596581701 Washers This part replaces 539115528. Price: $2.99
59 595316401 Washers This part replaces 539109554. Price: $2.99
60 596564801 Washers This part replaces 539990052. Price: $1.99
61 596134901 GSPH This part replaces 539990692. Price: $2.99
