Rear Lift Assembly
Parts (14)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 112-3267-03 | REAR LIFT FRAME ASM Price: $673.44 |
| 2 | 115-7782 | ELECTRIC ACTUATOR ASM Price: $1,504.19 |
| 3 | 92-2739 | PIN-CLEVIS Price: $8.48 |
| 4 | 92-2762 | PIN-HAIR Price: $1.09 |
| 5 | 110-5052 | SCREW-HHF Price: $1.22 |
| 6 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 7 | 3290-378 | TIE-CABLE Price: $0.79 |
| 8 | 94-1742 | SWITCH Price: $57.99 |
| 9 | 99-7431 | FUSE-THERMAL, 15 AMP Price: $20.85 |
| 22 | 117-4992-03 | PLATE-ACTUATOR, LH Price: $15.93 |
| 23 | 117-4993-03 | PLATE-ACTUATOR, RH Price: $16.70 |
| 24 | 3234-6 | SCREW-HHF Price: $3.19 |
| 25 | 32128-49 | NUT-HHF Price: $1.04 |
| 26 | 100-6541 | PIN-CLEVIS Price: $24.99 |
