| Ref | Part Number | Description |
|---|
| 2 |
483356 |
Throttle Cable Price: Call Us |
| 6 |
04002-10 |
Bolt, Metric Hex Head M10-1.25 x 25LG Price: Call Us |
| 7 |
424580 |
Clamp Price: Call Us |
| 8 |
04011-06 |
Screw, Self Tapping Price: Call Us |
| 9 |
424485 |
Bracket, Control Mount Price: Call Us |
| 10 |
483811 |
Muffler, Kubota This part replaces 483353. Price: Call Us |
| 11 |
483387 |
Gasket, Muffler Price: Call Us |
| 13 |
481811 |
Oil Pressure Sender Price: Call Us |
| 14 |
483433 |
Elbow, 45 Degree Price: Call Us |
| 15 |
04019-04 |
Nut, Serrated Flange 5/16-18 Price: Call Us |
| 16 |
451862 |
Mounting Bracket Weldment LH Price: Call Us |
| 17 |
483351 |
ISO Mount Price: Call Us |
| 18 |
424452 |
Plate, Rear Engine Mount Price: Call Us |
| 19 |
424448 |
Plate, Engine Mount LH Price: Call Us |
| 20 |
424449 |
Plate, Engine Mount RH Price: Call Us |
| 21 |
04025-02 |
Nut, Metric Hex M8-1.25 Price: Call Us |
| 22 |
04030-03 |
Lockwasher, 5/16" Spring Price: Call Us |
| 24 |
451863 |
Mounting Bracket Weldment RH Price: Call Us |
| 25 |
04106-01 |
Capscrew, Metric M6-1.0 x 16 Price: Call Us |
| 26 |
04030-02 |
Lockwasher, 1/4" Spring Price: Call Us |
| 27 |
483512 |
Foam, Radiator Screen Price: Call Us |
| 28 |
424624 |
Debris Screen Track LH Price: Call Us |
| 30 |
424623 |
Debris Screen Track RH Price: Call Us |
| 31 |
424497 |
Bracket, Air Cleaner Mount Price: Call Us |
| 33 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 35 |
48136-09 |
Clamp, 2-1/4" Max. Dia. Price: Call Us |
| 36 |
483343 |
Hose, Air Intake Price: Call Us |
| 37 |
04021-22 |
Nut, Elastic Stop 5/16-18 Grade 8 Price: Call Us |
| 38 |
04030-03 |
Lockwasher, 5/16" Spring Price: Call Us |
| 39 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 40 |
04001-19 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 41 |
04002-01 |
Bolt, Metric Hex Head M8-1.25 x 30LG Price: Call Us |
| 42 |
04030-03 |
Lockwasher, 5/16" Spring Price: Call Us |
| 43 |
04002-03 |
Bolt, Metric Hex Head M8-1.25 x 25LG Price: Call Us |
| 45 |
04002-12 |
Bolt, Metric Hex Head M8-1.25 x 20LG Price: Call Us |
| 46 |
424633 |
Latch, Hood Price: Call Us |
| 47 |
04009-07 |
Bolt, Shoulder 5/16-18 x 1/2" Price: Call Us |
| 48 |
483507 |
Spring, Hood Latch Price: Call Us |
| 49 |
424634 |
Lock, Hood Latch Price: Call Us |
| 50 |
04041-07 |
Flatwasher, 3/8-.391 x .938 x .105 Price: Call Us |
| 51 |
04021-04 |
Nut, Center Lock, 5/16-18(32) Price: Call Us |
| 52 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" Price: Call Us |
| 53 |
04041-07 |
Flatwasher, 3/8-.391 x .938 x .105 Price: Call Us |
| 54 |
04041-11 |
Flatwasher, 3/8-.406 x 1.50 x 7 Gauge Price: Call Us |
| 55 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 56 |
04017-16 |
Bolt, Hex Head Serr. Flange 5/16-18 x 3/4" Price: Call Us |
| 57 |
04003-12 |
Bolt, Carriage 5/16-18 x 3/4" Price: Call Us |
| 58 |
04019-03 |
Nut, Serrated Flange 5/16-18 Price: Call Us |
| 59 |
483513 |
Foam, Radiator Screen Upper Price: Call Us |
| 60 |
04017-16 |
Bolt, Hex Head Serr. Flange 5/16-18 x 3/4" Price: Call Us |
| 61 |
04019-03 |
Nut, Serrated Flange 5/16-18 Price: Call Us |
| 62 |
04001-176 |
Bolt, Hex Head 5/16-18 x 1-3/4" Grade 8 Price: Call Us |
| 63 |
04040-04 |
Flatwasher, SAE 5/16-.344 x .688 x .065 Price: Call Us |
