| Ref | Part Number | Description |
|---|
| 1 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 1 |
823230506 |
SET SCREW Price: $2.99 |
| 1B |
30715 |
SHAFT & LEV Price: Call Us |
| 2 |
104-3546 |
PULLEY-DRIVEN, LOW Price: $163.56 |
| 2 |
30357 |
SCREW Price: $2.62 |
| 2 |
532009484 |
CONDUIT CLIP T Price: $3.99 |
| 3 |
30726 |
SHUTTER Price: Call Us |
| 3 |
532086777 |
Screw, Hex, Washer Hd., Slotted, Thd. Cutting #10-24 x 1/2 Type D (AYP part number) Price: $1.99 |
| 4 |
119-4775 |
SPINDLE HOUSING ASM Price: $244.67 |
| 4 |
30716 |
SHAFT & LEV Price: Call Us |
| 4 |
874770508 |
BOLT Price: $2.99 |
| 5 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 5 |
817490440 |
BOLT, THD ROLLER 1/4-20 X 2-1/ Price: $2.99 |
| 6 |
104-3554 |
SHAFT-SPINDLE Price: $67.98 |
| 6 |
30717 |
SCREW Price: Call Us |
| 6 |
583753101 |
SHIELD.INNER.FRT.PNT This part replaces 532422920. Price: $32.99 |
| 6A |
650399 |
SCREW This part replaces 630605. Price: $1.20 |
| 7 |
104-8322 |
WASHER-HARDENED Price: $23.22 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 7 |
532170488 |
SCREW.HEX.WSH.SLT.#10-24X.50 Price: $2.99 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 8 |
532167739 |
Price: Call Us |
| 9 |
30714 |
CARB BODY Price: Call Us |
| 9 |
582740701 |
BOLT This part replaces 874760628. Price: $2.99 |
| 10 |
28924 |
SHUTTER Price: Call Us |
| 10 |
532109227 |
PAD IDLER TI Price: $2.99 |
| 11 |
30356 |
GASKET Price: $2.22 |
| 11 |
532009484 |
CONDUIT CLIP T Price: $3.99 |
| 12 |
27108 |
GASKET Price: Call Us |
| 12 |
532009180 |
V BELT STD Price: $19.99 |
| 13 |
812000028 |
RETAINING RING LT Price: $4.99 |
| 13A |
30720 |
INLET NEEDLE Price: Call Us |
| 14 |
30354 |
FLOAT Price: Call Us |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 16 |
27136A |
DRAIN ASSY This part replaces 27136. Price: $5.96 |
| 16 |
812000028 |
RETAINING RING LT Price: $4.99 |
| 17 |
32131 |
FLOAT BOWL This part replaces 30350. Price: $11.15 |
| 17 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 18 |
27136A |
DRAIN ASSY This part replaces 27137. Price: $5.96 |
| 18 |
532161806 |
PULLEY, IDLER Price: $17.99 |
| 19 |
27136A |
DRAIN ASSY This part replaces 27138. Price: $5.96 |
| 19 |
532175377 |
ARM, IDLER Price: $14.99 |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 20 |
874760620 |
BOLT Price: $3.99 |
| 21 |
28945 |
POWER SCREW Price: $18.86 |
| 21 |
532106968 |
SHAFT.IDLER.TILLER Price: $11.99 |
| 22 |
630786 |
SPRING Price: $1.25 |
| 23 |
30355 |
NOZZLE Price: Call Us |
| 24 |
27113 |
SPRING Price: $2.62 |
| 25 |
27554 |
GASKET Price: $1.05 |
| 26 |
27544 |
O RING Price: $1.26 |
| 28 |
30815 |
BAFFLE Price: Call Us |
| 29 |
30817 |
SCREW Price: Call Us |
