| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER Price: $188.53 |
| 1 |
580687702 |
LEVER.CONTROL.RH.PNT.BLACK This part replaces 532415542. Price: $19.99 |
| 2 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
580687802 |
LEVER.CONTROL.LH.BLACK This part replaces 532415541. Price: $24.99 |
| 3 |
282-4 |
SHACKLE Price: $32.98 |
| 4 |
32151-48 |
E-RING Price: $1.41 |
| 5 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 5 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 6 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
817060408 |
SCREW Price: $4.99 |
| 7 |
532412677 |
BAIL.CONTROL.INTERLOCK Price: $12.99 |
| 7 |
98-4548-03 |
BRACKET-SPRING, RH Price: $42.16 |
| 8 |
532429098 |
ARM.IMPELLER.ROD.SNOW This part replaces 532199576. Price: $3.99 |
| 8 |
98-4536-03 |
BRACKET-SPRING, LH Price: $42.16 |
| 9 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 9 |
532415546 |
ARM.TRACTION.ROD.YZ Price: $3.99 |
| 10 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
585198802 |
PANEL.CONTROL.SNOW.BLACK This part replaces 532415539. Price: $34.99 |
| 11 |
100-3831-01 |
BRACKET-ROLLER, LH Price: $69.47 |
| 11 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 13 |
32151-61 |
RING-RETAINING Price: $2.39 |
| 13 |
532414517 |
TUBE.HANDLE.PLOW.LH.PNT This part replaces 532415236. Price: $28.99 |
| 14 |
532414516 |
TUBE.HANDLE.PLOW.RH.PNT This part replaces 532415237. Price: $29.99 |
| 14 |
75-5400 |
PIN-ROLLER Price: $26.06 |
| 15 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 15 |
75-5390 |
ROLLER Price: $56.69 |
| 16 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 16 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 17 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 17 |
75-5360 |
PIN-CYLINDER Price: $72.33 |
| 18 |
108-4432 |
CYLINDER-HYD, LIFT This part replaces 93-9311. Price: $730.09 |
| 18 |
532180480 |
ROD.ASM.IMPELLER Price: $24.99 |
| 19 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 19 |
532405740 |
ROD.ASM.TRACTION Price: $27.99 |
| 20 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 21 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 22 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 22 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $5.99 |
| 23 |
532184087 |
TUBE.LOWER.HANDLE.24.BLACK Price: $59.99 |
| 23 |
93-0069-03 |
PIN-REAR Price: $424.34 |
| 24 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 25 |
322-6 |
SCREW-HH Price: $0.45 |
| 25 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 26 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 26 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 27 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 28 |
532412680 |
SPACER CONTROL LEVER Price: $2.99 |
| 30 |
532405879 |
CONSOLE, PANEL Price: $29.99 |
| 31 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 32 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 34 |
817060410 |
SCREW 14-20 X 5/8 Price: $3.99 |
| 36 |
532443215 |
SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
| 37 |
532412675 |
SPRING.INTERLOCK This part replaces 532416288. Price: $4.99 |
| 38 |
532180927 |
RP.HEADLIGHT.FLOOD.SNOW Price: $59.99 |
| 39 |
532178668 |
BEZEL.HEADLIGHT.BLACK Price: $5.99 |
| 42 |
532445291 |
CAM.INTERLOCK.RELEASE This part replaces 532414572. Price: $3.99 |
| 47 |
532196943 |
BRKT.PANEL.RH.INT Price: $8.99 |
| 48 |
532196944 |
BRKT.PANEL.LH.INT Price: $8.99 |
| 532401620 |
BULB.HEADLIGHT.HALOGEN. |
Price: $59.99 532401620 |
