| Ref | Part Number | Description |
|---|
| 1 |
104-5269 |
FAN Price: $287.64 |
| 1 |
170551 |
Control Th/ch Flag Price: Call Us |
| 1 |
KH-24-009-160-S |
CLOSURE PLATE ASSEMBLY Not Available This part replaces KH-24-009-87. Price: |
| 2 |
114-3989 |
FAN CLUTCH ASM This part replaces 93-1430. Price: $498.92 |
| 2 |
17720408 |
Screw Hex Thd Cut 1/4-20 x 1/2 Price: Call Us |
| 2 |
KH-24-755-121-S |
Kit, tube w/dipstick This part replaces KH-24-038-03. Price: $34.44 |
| 3 |
98-1242 |
ADAPTER-FAN Price: $147.55 |
| 3 |
KH-24-755-121-S |
Kit, tube w/dipstick This part replaces KH-24-123-04. Price: $34.44 |
| 4 |
137352 |
Muffler Exhaust B&S Price: Call Us |
| 4 |
52-6290 |
SCREW-HSH Price: $1.09 |
| 4 |
KH-12-144-02 |
Shaft, Governor Gear Price: $4.23 |
| 5 |
322-2 |
SCREW-HH Price: $0.69 |
| 5 |
KH-24-448-01-S |
TAB-LOCKING Not Available This part replaces KH-52-448-02. Price: |
| 7 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
KH-12-380-01 |
Pin, Governor Regulating Price: $3.13 |
| 8 |
KH-25-086-395-S |
SCREW Not Available This part replaces KH-M-0645025. Price: |
| 9 |
KH-M-631005 |
FLAT WASHER Not Available Price: |
| 11 |
KH-24-153-01 |
O-Ring, Oil Pick-Up Price: $2.29 |
| 12 |
KH-24-381-01 |
PICK UP-OIL Not Available Price: |
| 13 |
165291 |
Gasket Eng 1 313 Id Tin Plated Price: Call Us |
| 13 |
KH-12-050-01-S |
Oil Filter This part replaces KH-12-050-08. Price: $20.50 |
| 14 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 14 |
KH-24-136-09-S |
OIL FILTER NIPPLE This part replaces KH-24-136-01. Price: $5.50 |
| 15 |
KH-25-155-02 |
CONNECTOR- Not Available Price: |
| 16 |
KH-24-153-08 |
O-Ring, Oil Passage Price: $5.66 |
| 18 |
KH-24-086-17-S |
Screw, hex. flange M8x1.25x45 This part replaces KH-24-086-16. Price: $2.29 |
| 19 |
KH-25-099-27-S |
Oil Pressure Switch This part replaces KH-52-099-06. Price: $15.50 |
| 20 |
98-3824 |
SWITCH-TEMP Price: $134.61 |
| 21 |
98-3825 |
SWITCH-TEMP Price: $151.07 |
| 22 |
114-5095 |
ENGINE-KUBOTA DSL This part replaces 104-5259. Price: $11,571.64 |
| 23 |
169837 |
Shield BRN/DBR Guard Price: Call Us |
| 26 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 27 |
33014-00 |
NUT-HEX Price: $0.25 |
| 29 |
137180 |
Kit Spark Arrestor (Flat Scrn) Price: Call Us |
| 29 |
98-3817 |
SOLENOID KIT Price: $522.93 |
| 31 |
184900 |
Tank Fuel Front Price: Call Us |
| 32 |
140527 |
Cap Asm Fuel Price: Call Us |
| 33 |
123487X |
Clamp Hose Price: Call Us |
| 33 |
98-1293-03 |
BRACKET-LINE Price: $27.85 |
| 35 |
2412-83 |
CLAMP-CABLE Price: $9.85 |
| 36 |
43-5940 |
WASHER-LOCK, SPRING Price: $0.70 |
| 37 |
137040 |
Line Fuel 20" Price: Call Us |
| 37 |
42-9250 |
BOLT Price: $1.63 |
| 38 |
181654 |
Plug Drain Oil Price: Call Us |
| 38 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 39 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 40 |
124028X |
Bushing Snap Nyl Blk Fuel Line Price: Call Us |
| 44 |
17670412 |
Screw Thdrol 1/4-20 x 3/4 Price: Call Us |
| 45 |
17000612 |
Screw Hex Wsh Thdrol 3/8-16 Price: Call Us |
| 46 |
19091416 |
Washer 9/32 x 7/8 x 16 Ga. Price: Call Us |
| 72 |
183906 |
Screw Scocket Head 5/16-18 x 1 Price: Call Us |
| 78 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
